Hioki CT6845 Instruction Manual

CT6845
CT6845-05
AC/DC CURRENT PROBE
Instruction Manual
Warranty
Warranty malfunctions occurring under conditions of normal use in
conformity with the Instruction Manual and Product Precautionary
Markings will be repaired free of charge. This warranty is valid for
a period of one (1) year from the date of purchase. Please contact
the distributor from which you purchased the product for further
information on warranty provisions.
Introduction
Thank you for purchasing the HIOKI Model CT6845, CT6845-05 AC/
DC Current Probe. To obtain maximum performance from the device,
please read this manual first, and keep it handy for future reference.
Inspection
When you receive the device, inspect it carefully to ensure that
no damage occurred during shipping. In particular, check the
accessories and cables. If damage is evident, or if it fails to operate
according to the specifications, contact your dealer or Hioki
representative.
Precautions during Shipment
Handle the device carefully so that it is not damaged due to a
vibration or shock.
Safety
This device is designed to conform to IEC 61010 Safety Standards,
and has been thoroughly tested for safety prior to shipment.
However, using the instrument in a way not described in this
manual may negate the provided safety features. Before using the
instrument, be certain to carefully read the following safety notes.
Mishandling during use could result in injury or death,
as well as damage to the device. Be certain that you
understand the instructions and precautions in the
manual before use.
