VariabLe FreQUency driVe (VFd) – FaULt codeS
These codes will be shown on the VFD diagnostic device screen
(non networked) or on the computer monitor (networked).
FAULT CODES
P-dEF
O-1
1 _ t-trp
O1 - b
OL-br
PS -trp
0_Volt
U_Volt
O-t
U-t
Th-Flt
SC -trp
P-LOSS
Spin-F
dAtA-F
4-20 F
SC -Flt
FAULtY
September 2011
DESCRIPTION
Output over current condition.
Excess load on the motor. Over
temperature on the heatsink.
Driver has tripped on overload after
delivering > 100% of value in P02 for
a period of time.
Brake channel over current
Brake resistor overload
Internal power stage fault
Over voltage on DC bus
Under voltage on DC bus
Heatsink over temperature
Under temperature
Faulty thermistor on heatsink
Comms loss trip
Input phase loss trip
Spin start failed
Internal memory fault
Analog input current out of range
Internal drive fault
Internal drive fault
6011315B — HVLS Fans
CORRECTIVE ACTION
No error – unit ready to configure new
properties
Recycle power. If this does not clear
the fault:
1. Check for wiring errors
2. Check for wire cable
length/damage
If this does not clear fault:
1. Consult T5
Recycle power. If this does not clear
the fault:
1. Check fan unit, ensure there
are no obstructions preventing
movement.
2. Check cable length to ensure it
is not too long.
If this does not clear fault:
Consult technical service.
Consult technical service
Consult technical service
Check wiring to motor, look for ph -ph
or ph-Earth short circuit. Check drive is
not forced into overload.
Supply problem.
If this occurs during operation, check
power supply voltage.
Drive is too hot.
Drive temperature below operating
range. Raise temperature over -10
degrees C.
Consult technical service
Check communication between drive
and remote sources.
Drive intended for three phase has lost
one leg.
Consult technical service
Parameters lost, reload. If repeated,
consult technical service.
Consult technical service
Consult technical service
Consult technical service
