Summary of Contents for Honda XRM125 CFT125 2020

  • Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 3 Congratulations on your purchase of a new The following codes in this manual ● Honda vehicle. Your selection of a Honda indicate the country. makes you part of a worldwide family of The illustrations here in are based on the ●...
  • Page 4 A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...

  • Page 5: Table Of Contents

    Contents Vehicle Safety P. 2 Operation Guide P. 12 Maintenance P. 32 Troubleshooting P. 71 Information P. 88 Specifications P. 100 Index P. 103...

  • Page 6: Vehicle Safety

    Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Safety Precautions..........P. 6 Riding Precautions ..........P. 7 Accessories & Modifications......P. 10 Loading ..............P. 11...

  • Page 7: Safety Guidelines

    Safety Guidelines Safety Guidelines that you and your passenger are both wearing an approved helmet and protective apparel. Follow these guidelines to enhance your safety: Instruct your passenger on holding onto the Perform all routine and regular inspections grab rail or your waist, leaning with you in turns, ●...
  • Page 8 Safety Guidelines Make Yourself Easy to See Keep Your Honda in Safe Condition Make yourself more visible, especially at night, It's important to keep your vehicle properly by wearing bright reflective clothing, positioning maintained and in safe riding condition. yourself so other drivers can see you, signaling...
  • Page 9 Safety Guidelines If you decide to continue riding, first turn the Never run your vehicle inside a garage or other ignition switch to the OFF position, and evaluate enclosure. the condition of your vehicle. Inspect for fluid WARNING leaks, check the tightness of critical nuts and Running the engine of your vehicle bolts, and check the handlebar, control levers, brakes, and wheels.

  • Page 10: Safety Precautions

    Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection Ride cautiously and keep your hands on the ● WARNING handlebar and feet on the footpegs. Keep passenger's hands onto the grab rail Not wearing a helmet increases the ●...

  • Page 11: Riding Precautions

    Riding Precautions Riding Precautions Exercise caution on low traction surfaces. ● The tyres slip more easily on such surfaces and braking distances are Running-in Period longer. During the first 500 km (300 miles) of running, Avoid continuous braking. ● follow these guidelines to ensure your vehicle's Repeated braking, such as when future reliability and performance.
  • Page 12 Riding Precautions Engine Braking Parking Engine braking helps slow your vehicle down Park on a firm, level surface. ● when you release the throttle. For further If you must park on a slight incline or loose ● slowing action, downshift to a lower gear. Use surface, park so that the vehicle cannot engine braking with intermittent use of the move or fall over.
  • Page 13 Riding Precautions Slowly lean the vehicle to the left until its Turn the handlebar fully to the left. weight rests on the side stand. Turning the handlebar to the right reduces stability and may cause the Using the centre stand vehicle to fall.

  • Page 14: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.

  • Page 15: Loading

    Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.

  • Page 16: Operation Guide

    Basic Operation Flow Pre-ride Inspection (P.37) Acceleration Carefully inspect your vehicle to make sure that it is safe to ride. Apply throttle gradually. Obey the speed limit. Shift Change (P.26) Starting the Engine (P.23) Start and warm the engine. Avoid revving the engine. Starting the Vehicle How to use basic features.
  • Page 17 Parking (P.8) Braking Close the throttle and apply the Park on a firm level surface. front and rear brakes together. Use the stand, and lock the The brakelight will indicate that steering. you have applied the brakes. Stopping If pulling off the road, signal early enough to show traffic that you are pulling over, and pull over smoothly.
  • Page 18 Parts Location CFT125MR/MRC Battery (P.49) Fuse box (P.86) Helmet holder Rear brake fluid (P.30) reservoir Throttle grip (P.56) (P.68) Front brake fluid reservoir (P.56) Brakelight switch (P.62) Spark plug (P.51) Rear brake pedal (P.58) Engine oil drain bolt (P.54) Engine oil fill cap/dipstick (P.53) Kickstarter (P.23)
  • Page 19 Helmet holder Headlight unit (P.30) (P.70) Document bag (P.31) Luggage box (P.31) Tool kit (P.31) Seat (P.30) Fuel fill cap (P.28) Drive chain (P.64) Side stand (P.63) Centre stand (P.9) Shift lever (P.26) Crankcase breather (P.69) Continued...
  • Page 20 Parts Location (Continued) CFT125MS Battery (P.49) Fuse box (P.86) Helmet holder (P.30) Throttle grip (P.68) Front brake fluid reservoir (P.56) Brakelight switch (P.62) Spark plug (P.51) Rear brake pedal (P.58) Engine oil drain bolt (P.54) Engine oil fill cap/dipstick (P.53) Kickstarter (P.23)
  • Page 21 Helmet holder Headlight unit (P.30) (P.70) Document bag (P.31) Luggage box (P.31) Tool kit (P.31) Seat (P.30) Fuel fill cap (P.28) Drive chain (P.64) Side stand (P.63) Centre stand (P.9) Shift lever (P.26) Crankcase breather (P.69)
  • Page 22 Instruments Speedometer Gear range Shows proper speed range for each gear. Fuel gauge Needle in the red mark, remaining fuel approximately 1.2 L (0.32 US gal, 0.26 Imp gal). Odometer Total distance ridden.
  • Page 23 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Turn signal indicator PGM-FI (Programmed Fuel Injection) High beam indicator malfunction indicator lamp (MIL) Comes on briefly when the ignition switch is turned to the ON position.
  • Page 24 Switches Start button Horn button Turn signal switch Pressing the switch turns the turn signal off. Headlight dimmer switch • : High beam • : Low beam...
  • Page 25 Ignition switch Turns electrical system Switches the electrical system on/ on for starting/riding. off, locks the steering. Key can be removed when in the OFF or LOCK position. Turns engine off. LOCK Locks steering. Continued...
  • Page 26 Switches (Continued) Steering Lock Locking Turn the handlebars all the way to the left or Lock the steering when parking to help right. prevent theft. Push the key down, and turn the ignition A U-shaped wheel lock or similar device is switch to the LOCK position.
  • Page 27 Starting the Engine Start your engine using the following NOTICE procedure, regardless of whether the engine • If the engine does not start within 5 seconds, turn the ignition switch to the OFF position and wait 10 is cold or warm. seconds before trying to start the engine again to recover battery voltage.
  • Page 28 Starting the Engine (Continued) If you cannot start the engine: Turn the ignition switch to the ON position. Shift the transmission to Neutral ( Open the throttle slightly (about 3 mm (0.1 indicator comes on). in), without freeplay). Using the start button With the throttle completely closed.
  • Page 29 If the engine does not start: Turn the ignition switch to the OFF position. Open the throttle fully. Crank the engine several times with the kickstarter. Repeat the starting procedure. If the engine starts, open the throttle slightly if idling is unstable. If the engine does not start, wait 10 seconds before trying steps a-d again.
  • Page 30 Shifting Gears Your vehicle transmission has four forward gears. The gearshift operation differs when stopping and when moving. When stopping, change can be made from 4th to neutral directly with the 4-step rotary system. Stopping When moving, the forward 4-step return system is used.
  • Page 31 Proper shifting can prevent damaging the Downshifting engine and transmission. Downshifting at speeds higher than those in the table below may overrev the engine and Upshifting can cause damage to the engine and The upper limit speed of each gear is shown transmission.
  • Page 32 Refuelling Fuel type: Unleaded petrol only Lower edge of filler neck Fuel octane number: Your vehicle is Fuel fill cap designed to use Research Octane Number (RON) 91 or higher. Tank capacity: 3.9 L (1.03 US gal, 0.86 Imp gal) Refuelling and Fuel Guidelines (P.9) Arrow marks...
  • Page 33 Closing the Fuel Fill Cap Install and tighten the fuel fill cap firmly by turning it clockwise. Make sure that the arrow marks on the fuel fill cap and fuel tank is aligned. Close the seat. WARNING Petrol is highly flammable and explosive.
  • Page 34 Storage Equipment Helmet Holder Helmet holders The helmet holders are located under the seat. Use the helmet holders only when parked. WARNING Ignition key Riding with a helmet attached to the holder can interfere with your ability to safely operate the vehicle and could lead to a crash in which you can be seriously hurt or killed.
  • Page 35 Luggage Box Document compartment Never exceed the maximum weight limit. Tool kit Maximum Weight: 5 kg (11 lb) Do not store any items that are flammable or susceptible to heat damage. Do not store valuables or fragile articles. Luggage box Document Bag The document bag is in the document compartment in the reverse side of the seat.

  • Page 36: Maintenance

    Maintenance Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. Importance of Maintenance ......P. 33 Other Adjustments..........P. 70 Maintenance Schedule........P. 34 Adjusting the Headlight Aim ......P. 70 Maintenance Fundamentals ......

  • Page 37: Importance Of Maintenance

    Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your vehicle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task, and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance, avoid breakdowns, and reduce air We cannot warn you of every conceivable pollution.

  • Page 38: Maintenance Schedule

    Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your vehicle after each periodic requirements. Keep an accurate record of maintenance is carried out.
  • Page 39 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Clean mechanically skilled. Lubricate Procedures are provided in an official Honda Shop Manual. Replace : Technical. In the interest of safety, have your vehicle serviced by your dealer. Continued...
  • Page 40 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 37 × 1,000 mi Brake Fluid 2 Years Brake Pads Wear (CFT125MR/MRC) Brake Shoes/Pads Wear 57, 61 (CFT125MS) Brake System (CFT125MR/MRC) Brake System (CFT125MS) Brakelight Switch Headlight Aim Lights/Horn...

  • Page 41: Maintenance Fundamentals

    Maintenance Fundamentals Brakes - Check operation; Pre-ride Inspection ● CFT125MR/MRC To ensure safety, it is your responsibility to Front and Rear: check brake fluid level and perform a pre-ride inspection and make sure pads wear. P. 56, P. 57 that any problem you find is corrected. A pre- CFT125MS ride inspection is a must, not only for safety, but Front: check brake fluid level and pads wear.
  • Page 42 Maintenance Fundamentals Replacing Parts Battery Always use Honda Genuine Parts or their Your vehicle has a maintenance-free type equivalents to ensure reliability and safety. battery. You do not have to check the battery electrolyte level or add distilled water. Clean the...
  • Page 43 Maintenance Fundamentals What to do in an emergency WARNING If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool water for at least 15 minutes.
  • Page 44 Always replace the battery with another maintenance-free battery of the same type. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
  • Page 45 Conserving” or “Resource Conserving” on the “Specifications.” P. 101 circular API service symbol. If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MA ●...
  • Page 46 If either has worn or damaged teeth, Wipe up spills immediately and wash thoroughly. have the sprocket replaced by your dealer. Recommended brake fluid: Honda DOT 3 or DOT 4 Brake Fluid or equivalent Normal Worn Damaged (GOOD)
  • Page 47 Maintenance Fundamentals Cleaning and Lubricating After inspecting the slack, clean the chain and sprockets while rotating the rear wheel. Use a dry cloth with high flash-point solvent. Use a soft brush if the chain is dirty. After cleaning, wipe dry and lubricate with the recommended lubricant.
  • Page 48 Maintenance Fundamentals Inspecting for Damage Crankcase Breather Inspect the tyres for Service more frequently when riding in rain, at cuts, slits, or cracks that full throttle, or after the vehicle is washed or exposes fabric or overturned. Service if the deposit level can be cords, or nails or other seen in the transparent section of the drain foreign objects...
  • Page 49 Maintenance Fundamentals Inspecting Tread Depth WARNING Inspect the tread wear indicators. If they Riding on tyres that are excessively become visible, replace the tyres immediately. worn or improperly inflated can cause a crash in which you can be seriously hurt or killed.
  • Page 50 Maintenance Fundamentals Have your tyres replaced by your dealer. WARNING For recommended tyres and air pressure, see Installing improper tyres on your “Specifications.” P. 101 vehicle can adversely affect handling Follow these guidelines whenever you replace and stability, and can cause a crash in tyres.
  • Page 51 Maintenance Fundamentals Air Cleaner This vehicle is equipped with a viscous type air cleaner element. Air blow cleaning or any other cleaning can degrade the viscous element performance and cause the intake of dust. Do not perform the maintenance. Should be serviced by your dealer.

  • Page 52: Tool

    Tool The tool kit is stored in the reverse side of the seat. P. 31 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. Spark plug wrench ● 10 x 14 mm Open end wrench ●...

  • Page 53: Removing & Installing Body Components

    Removing & Installing Body Components Battery Removal Make sure the ignition switch is in the OFF Positive terminal position. Open the seat. P. 30 Remove the battery cover. P. 50 Disconnect the negative - terminal from the battery. Disconnect the positive + terminal from the battery.

  • Page 54: Battery Cover

    Removing & Installing Body Components Battery Cover Battery Cover Removal Open the seat. P. 30 Screw Remove the screw. Remove the battery cover. Installation Install the parts in the reverse order of removal. Battery cover...

  • Page 55: Spark Plug

    Spark Plug Checking Spark Plug Spark plug wrench For the recommended spark plug, see “Specifications.” P. 101 Use only the recommended type of spark plug in the recommended heat range. NOTICE Using a spark plug with an improper heat range can cause engine damage.
  • Page 56 Spark Plug Checking Spark Plug Check the spark plug gap using a wire- Tighten the spark plug: type feeler gauge. If the old plug is good: ● If adjustment is necessary, bend the 1/8 turn after it seats side electrode carefully. If installing a new plug, tighten it twice ●...

  • Page 57: Engine Oil

    Engine Oil Checking the Engine Oil Oil fill cap/dipstick If the engine is cold, idle the engine for 3 Upper level to 5 minutes. Turn the ignition switch to the OFF position and wait for 2 to 3 minutes. Place your vehicle on its centre stand on a firm, level surface.
  • Page 58 Engine Oil Adding Engine Oil Adding Engine Oil NOTICE Overfilling with oil or operating with insufficient oil can cause damage to your engine. Do not mix If the engine oil is below or near the lower different brands and grades of oil. They may level mark, add the recommended engine oil.
  • Page 59 Engine Oil Changing Engine Oil Place your vehicle on its centre stand on a Install a new sealing washer onto the firm, level surface. drain bolt. Tighten the drain bolt. Place a drain pan under the drain bolt. Torque: 24 N·m (2.4 kgf·m, 18 lbf·ft) Remove the oil fill cap/dipstick, drain bolt and sealing washer to drain the oil.

  • Page 60: Brakes

    Brakes Checking Brake Fluid Front Front brake fluid Place your vehicle in an upright position reservoir on a firm, level surface. Check that the brake fluid reservoir Front is horizontal and that the fluid level is above the LOWER level mark. CFT125MR/MRC LOWER level mark Check that the brake fluid reservoir...
  • Page 61 Brakes Inspecting the Brake Pads Inspecting the Brake Pads Front Brake pads Check the condition of the brake pad wear indicators. The pads need to be replaced if a brake pad is worn to the indicator. Wear Inspect the brake pads from below Front indicators the brake caliper.
  • Page 62 Brakes Inspecting the Rear Brake Pedal Freeplay Inspecting the Rear Brake Make sure the brake rod, brake arm, spring and fastener are in good condition. Pedal Freeplay CFT125MS Place your vehicle on its centre stand on a firm, level surface. Measure the distance the rear brake pedal moves before the brake takes hold.
  • Page 63 Brakes Adjusting the Rear Brake Pedal Freeplay Adjusting the Rear Brake Pedal Brake arm pin Freeplay CFT125MS Make sure the cut-out on the adjusting nut is seated on the brake arm pin when adjusting the freeplay. Decrease freeplay Brake arm pin Adjusting nut Increase freeplay Adjusting nut...
  • Page 64 Brakes Adjusting the Rear Brake Pedal Freeplay Push the brake arm to confirm that there After adjustment, confirm the freeplay of the is a gap between the rear brake adjusting brake pedal. nut and brake arm pin. Make sure the brake rod, brake arm, spring Brake arm and fastener are in good condition.
  • Page 65 The rear brake is equipped with a brake wear See your dealer for this service. indicator. Brake panel When the brake service is necessary, see your Arrow dealer. Use only Honda Genuine Parts or its equivalent. Reference mark Brake arm...
  • Page 66 Brakes Adjusting the Brakelight Switch Adjusting the Brakelight Switch Brakelight switch Check the operation of the brakelight switch. Hold the brakelight switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too soon.

  • Page 67: Side Stand

    Side Stand Checking the Side Stand Side stand spring Check that the side stand operates smoothly. If the side stand is stiff or squeaky, clean the pivot area and lubricate the pivot bolt with clean grease. Check the spring for damage or loss of tension.

  • Page 68: Drive Chain

    Drive Chain Inspecting the Drive Chain Do not ride your vehicle if the slack exceeds 50 mm (2.0 in). Slack Check the drive chain slack at several points along the chain. If the slack is not constant at all points, some links may be kinked and binding.
  • Page 69 Drive Chain Adjusting the Drive Chain Slack Adjusting the Drive Chain Slack Rear edge of adjusting slot Rear axle nut Adjusting the chain requires special tools. Lock nut Have the drive chain slack adjusted by your dealer. Shift the transmission to Neutral. Stop the engine.
  • Page 70 Drive Chain Adjusting the Drive Chain Slack Check rear axle alignment by making sure Rear edge of adjusting slot the chain adjuster index marks align with Lock nut the rear edge of the adjusting slots. Both marks should correspond. If the axle is misaligned, turn the right or left adjusting nuts until the marks are aligned and recheck chain slack.
  • Page 71 Drive Chain Adjusting the Drive Chain Slack Checking the Drive Chain Wear If a torque wrench was not used for installation, see your dealer as soon as If the drive chain slack is excessive when the possible to verify proper assembly. rear axle is moved to the furthest limit of Improper assembly may lead to loss of adjustment, the drive chain is worn and must...

  • Page 72: Throttle

    Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly, close automatically, or if the cable is damaged, have the vehicle inspected by your dealer.

  • Page 73: Crankcase Breather

    Crankcase Breather Cleaning the Crankcase Breather Place a suitable container to receive deposits. Remove the crankcase breather tube and drain deposits. Reinstall the crankcase breather tube. Crankcase breather tube...

  • Page 74: Other Adjustments

    Other Adjustments Adjusting the Headlight Aim You can adjust vertical aim of the headlight for proper alignment. Turn the screw in or out as necessary using a Phillips screwdriver. Obey local laws and regulations. Headlight Raise Screw Lower...

  • Page 75: Troubleshooting

    Troubleshooting Engine Will Not Start........P. 72 Warning Indicators On or Flashing....P. 73 PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL)....P. 73 Tyre Puncture ............. P. 74 Electrical Trouble ..........P. 82 Battery Goes Dead ..........P. 82 Burned-out Light Bulb........

  • Page 76: Engine Will Not Start

    Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 23 sequence.

  • Page 77: Warning Indicators On Or Flashing

    Warning Indicators On or Flashing PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) If the indicator comes on while riding, you may have a serious problem with the PGM-FI system. Reduce speed and have your vehicle inspected by your dealer as soon as possible.

  • Page 78: Tyre Puncture

    Tyre Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tyre or tube repair can be risky. If the performed by your dealer. temporary repair fails, you can crash After an emergency repair, always have the and be seriously injured or killed.
  • Page 79 Tyre Puncture Removing Wheels Front Wheel Speedometer cable Removal Front axle nut Place your vehicle on its centre stand on a firm, level surface. Support your vehicle securely and raise the front wheel off the ground using a maintenance stand or a hoist. Remove the speedometer cable by pushing the tab.
  • Page 80 Tyre Puncture Removing Wheels Installation After installing the wheel, apply the brake lever several times, then check if the Attach the side collar and speedometer wheel rotates freely. Recheck the wheel if gearbox to the wheel. the brake drags or if the wheel dose not Position the wheel between the fork legs rotate freely.
  • Page 81 Tyre Puncture Removing Wheels Rear Wheel Drive chain adjusting nut CFT125MR/MRC Rear axle Removal washer Support your vehicle securely and raise the rear wheel off the ground using the centre stand or a hoist. Loosen the rear axle nut, drive chain lock nuts and turn the drive chain adjusting Drive chain Rear axle nut...
  • Page 82 Tyre Puncture Removing Wheels Remove the rear axle shaft, rear axle NOTICE washer, side collars and rear wheel. When installing a wheel or caliper into original position, carefully fit the brake disc between the Support the brake caliper assembly so pads to avoid scratching them.
  • Page 83 Tyre Puncture Removing Wheels Adjust the drive chain. P. 65 Install and tighten the rear axle nut. Torque: 59 N·m (6.0 kgf·m, 44 lbf·ft) After installing the wheel, apply the brake pedal several times, then check if the wheel rotates freely. Recheck the wheel if the brake drags or if the wheel does not rotate freely.
  • Page 84 Tyre Puncture Removing Wheels Rear Wheel Drive chain Drive chain adjusting nut lock nut Rear axle Rear axle CFT125MS washer Removal Support your vehicle securely and raise the rear wheel off the ground using the centre stand or a hoist. Remove the rear brake adjusting nut.
  • Page 85 Tyre Puncture Removing Wheels Remove the rear axle shaft, rear axle Adjust the drive chain. P. 65 washers, side collars and rear wheel from Adjust the rear brake pedal freeplay. the swingarm. P. 59 Rear axle shaft Rear axle washer Tighten the rear axle nut.

  • Page 86: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the vehicle before Turn the ignition switch to the OFF or LOCK charging.
  • Page 87 Electrical Trouble Burned-out Light Bulb Headlight Bulb Remove the headlight case by removing the bolts. Headlight case Remove the rubber dust cover. Slightly press the socket and turn it counterclockwise. Remove the bulb. Install a new bulb and parts in the reverse order of removal.
  • Page 88 Electrical Trouble Burned-out Light Bulb Brakelight/Taillight Bulb Remove the brakelight/taillight lens by removing the screws. Brakelight/Taillight lens Remove the license lens. Lens packing Bulb Slightly press the bulb in and turn it counterclockwise. Install a new bulb and parts in the reverse order of removal.
  • Page 89 Electrical Trouble Burned-out Light Bulb Front Turn Signal Bulb Rear Turn Signal Bulb Front turn signal lens Turn signal Lens packing lens Bulb Screw Bulbs Remove the brakelight/taillight lens. Remove the front turn signal lens by P. 84 removing the screw. Remove the rear turn signal lens.

  • Page 90: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse Spare fuses Battery cover Before handling fuses, see “Inspecting and Replacing Fuses.” P. 40 Fuse Box Fuses Sub fuse Main fuse Open the seat. P. 30 Remove the battery cover P. 50. Open the fuse box covers. Pull out the fuses one by one to check for a blown fuse.

  • Page 91: Unstable Engine Operation Occurs Intermittently

    Unstable Engine Operation Occurs Intermittently If the fuel pump filter is clogged, unstable engine operation will occur intermittently while riding. Even if this symptom occurs, you can continue to ride your vehicle. If unstable engine operation occurs even if sufficient fuel is available, have your vehicle inspected by your dealer as soon as possible.

  • Page 92: Information

    Information Keys............... P. 89 Instruments, Controls, & Other Features..P. 90 Caring for Your Vehicle........P. 91 Storing Your Vehicle......... P. 94 Transporting Your Vehicle ......P. 95 You & the Environment........P. 96 Serial Numbers........... P. 97 Fuels Containing Alcohol......... P. 98 Catalytic Converter ...........

  • Page 93: Keys

    Keys Keys Ignition Key Be sure to record the key number provided with the original keys. Store the spare key and key number in a safe location. To make a duplicate, take the spare key or the key number to your dealer. If you lose all ignition keys and the key number, the ignition switch assembly will probably have to be removed by your dealer to determine the...

  • Page 94: Instruments, Controls, & Other Features

    Instruments, Controls, & Other Features Instruments, Controls, & Document Bag Other Features The owner's manual, registration, and insurance information can be stored in the plastic Ignition Switch document bag located reverse side of the seat. Leaving the ignition switch in the ON position with the engine stopped will drain the battery.

  • Page 95: Caring For Your Vehicle

    Frequent cleaning and polishing is important to After the vehicle dries, lubricate any moving ensure the life of your Honda. A clean vehicle parts. makes it easier to spot potential problems.
  • Page 96 Caring for Your Vehicle Do not direct water at the air cleaner: Washing Precautions ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...
  • Page 97 Caring for Your Vehicle Aluminium Components Exhaust Pipe and Muffler Aluminium will corrode from contact with dirt, When the exhaust pipe and muffler are painted, mud, or road salt. Clean aluminium parts do not use a commercially available abrasive regularly and follow these guidelines to avoid kitchen cleaning compound.

  • Page 98: Storing Your Vehicle

    Storing Your Vehicle Storing Your Vehicle After removing your vehicle from storage, inspect all maintenance items required by the If you store your vehicle outdoors, you should Maintenance Schedule. consider using a full-body cover. If you won't be riding for an extended period, follow these guidelines: Wash your vehicle and wax all painted ●...

  • Page 99: Transporting Your Vehicle

    Transporting Your Vehicle Transporting Your Vehicle If your vehicle needs to be transported, it should be carried on a motorcycle trailer or a flatbed truck or trailer that has a loading ramp or lifting platform, and motorcycle tie-down straps. Never try to tow your vehicle with a wheel or wheels on the ground.

  • Page 100: You & The Environment

    You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a vehicle can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.

  • Page 101: Serial Numbers

    Serial Numbers Serial Numbers Frame number The frame and engine serial numbers uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.

  • Page 102: Fuels Containing Alcohol

    Fuels Containing Alcohol Fuels Containing Alcohol The use of petrol containing more than 10% ethanol may: Some conventional fuels blended with alcohol Damage the painting of the fuel tank. ● are available in some locales to help reduce Damage the rubber tubes of the fuel line. ●...

  • Page 103: Catalytic Converter

    A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.

  • Page 104: Specifications

    Specifications Main Components ■ Displacement 124 cm (7.6 cu-in) CFT125MR/MS 1,933 mm (76.1 in) Bore x stroke 52.400 x 57.913 mm (2.0630 x 2.2800 in) Overall length CFT125MRC 1,927 mm (75.9 in) Compression ratio 9.3 : 1 CFT125MS 833 mm (32.8 in) Unleaded petrol Overall width Fuel...
  • Page 105 0.9 L (1.0 US qt, 0.8 Imp qt) Front disassembly CFT125MRC MBP MP-220 Recommended Tyre Recommended CFT125MR/MS MBP MM-102B Honda DOT 3 or DOT 4 Brake Fluid Rear brake fluid CFT125MRC MBP MP-221 Recommended [Rider only] Drive chain lubricant drive chain 200 kPa (2.00 kgf/cm...
  • Page 106 Specifications Bulbs Torque Specifications ■ ■ Headlight 12 V-32/32 W Engine oil drain bolt 24 N·m (2.4 kgf·m, 18 lbf·ft) Brakelight/Taillight 12 V-18/5 W Front wheel axle nut 49 N·m (5.0 kgf·m, 36 lbf·ft) Front turn signal 12 V-10 W × 2 Rear wheel axle nut 59 N·m (6.0 kgf·m, 44 lbf·ft) Rear turn signal...

  • Page 107: Index

    Index Accessories ............10 Document Bag ........... 31, 90 Air Cleaner............47 Drive Chain..........42, 64 Battery............38, 49 Electrical Trouble ..........82 Brakelight Switch..........62 Engine Brakelight/Taillight Bulb........ 84 Number ..............97 Brakes Oil..............41, 53 Fluid............42, 56, 101 Starting ..............
  • Page 108 Fuels Containing Alcohol....... 98 Loading Guidelines.......... 11 Fuses ............. 40, 86 Luggage Box ............. 31 Gasohol .............. 98 Maintenance Gear Position Indicators......... 19 Fundamentals ............. 37 Importance ............33 Safety ..............33 Headlight ............83 Schedule............... 34 Headlight Aim ..........70 Maximum Weight Limit .........
  • Page 109 Petrol ..............28 Specifications..........100 PGM-FI (Programmed Fuel Injection) Speedometer ............ 18 Malfunction Indicator Lamp (MIL)..19, 73 Start Button............20 Protective Apparel..........6 Starting the Engine ......... 23 Storage Compartment ............. 30 Rear Turn Signal Light ........85 Equipment ............30 Recommended Owner’s Manual ..........
  • Page 110 Washing ............. 91 Weight Limit..........11, 100 Wheels Front Removal ............ 75 Rear Removal ..........77, 80...
