- Page 1 SB.1.1 MODEL 3778P AC STRAIN GAGE CONDITIONER INSTRUCTION MANUAL 3700 Instrument Series...
- Page 2 WARNING Death, serious injury, or fire hazard could result from improper connection of this instrument. Read and understand this manual before connecting this instrument. Follow all installation and operating instructions while using this instrument. Connection of this instrument must be performed in compliance with the National Electrical Code (ANSI/NFPA 70-2014) of USA and any additional safety requirements applicable to your installation.
- Page 3 WARNUNG Der falsche Anschluß dieses Gerätes kann Tod, schwere Verletzungen oder Feuer verursachen. Bevor Sie dieses Instrument anschließen, müssen Sie die Anleitung lesen und verstanden haben. Bei der Verwendung dieses Instruments müssen alle Installation- und Betriebsanweisungen beachtet werden. Der Anschluß dieses Instruments muß in Übereinstimmung mit den nationalen Bestimmungen für Elektrizität (ANSI/NFPA 70- 2014) der Vereinigten Staaten, sowie allen weiteren, in Ihrem Fall anwendbaren Sicherheitsbestimmungen, vorgenommen werden.
-
Page 4: Medidas De Seguridad
Medidas de seguridad Las medidas de seguridad siguientes deberán observarse cuando se realice cualquier tipo de conexión al instrumento. ο Cuando se haga conexiones a circuitos eléctricos o a equipo de activación por pulso, deberá abrirse sus respectivas cajas de seguridad. NO deberá hacerse ninguna conexión del instrumento en líneas eléctricas bajo tensión. ο... -
Page 5: Standard Accessories
Sicherheitsvorkehrungen Die folgenden Sicherheitsvorkehrungen sind immer dann zu befolgen, wenn eine Verbindung zum Instrument hergestellt wird. ο Öffnen Sie beim Anschluß an elektrische Stromkreise oder Impulsauslösungseinrichtungen die entsprechenden Unterbrecher. Es dürfen KEINE Anschlüsse an das Instrument unter stromführenden Spannungsleitungen montiert werden. - Page 6 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R 1.A.0.3778 3778 E N E R A L E S C R I P T I O N A N D P E C I F I C A T I O N S The Model 3778 is a single-channel panel instrument of phase-sensitive carrier-amplifier design, intended for applications involving transformer coupled rotary torque sensors or...
- Page 7 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R 3778 SPECIFICATIONS Measurement Range: Adjustable 0.5 mV/V to 5.0 mV/V; nominal full-scale Transducer Types: Conventional 4-arm strain gage bridges, typically transformer coupled - 120 to 10k Ohm Excitation: 3.28 or 5.0 KHz (selectable);...
-
Page 8: Rear Panel Connection
MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R The Model 3778 I/O CONNECTIONS are via removable screw terminals which will accept wire sizes from AWG 12 to 26. N O T E : The recommended transducer cabling would be eight wire, individually shielded, twisted pair - wired as indicated (Fig. - Page 9 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R O N N E C T I O N S J1 - Sync Connections. The Sync connection is used when more than one 3778 or 3730 unit(s) are installed in an application that either the unit, cabling or the measurement sensor are in close proximity to where "cross talk"...
- Page 10 5 must be in the External position) NOTE: Daytronic Shunt Calibration circuit, when activated, will place the Shunt resistor across the + Sense Line (for positive shunt) or the – Sense Line (for negative shunt) with the connection of the Sensor’s Calibration Sense line located on the J2 connector - which is recommend to be connected to the + Signal line.
- Page 11 Note: Cable should be low capacitance, low resistance – Four Twisted pair, shielded cable. Paired as shown. Recommended Cable - Daytronic Part # 77029.00 or Belden 8164 For proper operation, sense lines must be connected at the transducer or at the rear panel of the 3778.
- Page 12 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R O N N E C T I O N S J3 - Analog Connections. Connections are used to provide analog outputs from the meter's signal conditioning area in the form of ±...
- Page 13 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R O N T R O L S Digital Display Range and Decimal Point Selection Configures the Engineering Unit Digital Display Range. Three selections are available to set the display operation for 1 count in 5000, 2 counts in 10000 or 5 counts in 20000 resolution.
- Page 14 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R O N T R O L S ( c o n t . ) Analog Control Settings Analog Control - 7 position dip switch configures the main parameters of the AC Signal conditioner for excitation frequency, mode of the analog output signal, low pass filter characteristics and internal or external shunt selection.
- Page 15 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R O N T R O L S ( c o n t . ) Analog Wide Gain and Wide Zero Controls Rotary range control switches for setting of the gain of the analog output signal of the 3778 meter.
- Page 16 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R C O N T R O L S ( c o n t . ) Analog Symmetry, Phase, ± CAL, TARE Symmetry - Adjust the negative gain slope for symmetrical analog adjustment as referenced to the positive span value.
- Page 17 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R CALIBRATION – 2 Point - Dead Weight with known input This section contains the instructions for calibrating the 3778. Reference the description of the instrument front-panel (see Page 1).
- Page 18 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R CALIBRATION – Shunt Calibration This section contains the instructions for calibrating the 3778 using the Shunt calibration method. Note: To calibrate the 3778, a known nominal load should be used to properly adjust the Phase control prior to establishing a Shunt calibration for the measurement system.
- Page 19 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R CALIBRATION (cont.) – Shunt Calibration Once completed, if the sensor is going to be utilized in the Negative or CCW mode, depress and ( i ) hold the –...
- Page 20 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R CALIBRATION (cont.) Master/Slave Connections. When more than one 3778 is being used in a measurement setup (instruments are closely mounted or the transducer cabling is in a common conduit or raceway), beat frequencies may be produced from the oscillators used in the instruments to develop the excitation.
- Page 21 MODEL 3778 A C S T R A I N G A G E P A N E L M E T E R Tech Tip on use of wide range settings for the AC Strain Gage Conditioner Due to multiple amplifier stages within the 3778 instrument, attention to the proper gain setting and understanding of the sensor inputs should be reviewed to produce a linear- amplified analog output signal and display reading.
- Page 22 Model 3778 AC STRAIN GAGE PANEL METER FUSE REPLACEMENT Should you suspect a blown fuse proceed as follows. WARNING Installation, operation and maintenance of this instrument must be performed by qualified personnel only. The National Electrical Code defines a qualified person as “one who has the skills and knowledge related to the construction and operation of the electrical equipment and installations, and who has received safety training on the hazards involved.”...
- Page 23 Model 3778 AC STRAIN GAGE PANEL METER WARNING Do not replace fuse again if failure is repeated. Repeated failure indicates a defective condition that will not clear with replacement of the fuse. Refer condition to a qualified technician. ADVERTENCIA No reemplace el fusible nuevamente si se repite la falla. La repetición de las fallas indica una condición defectuosa que no se subsanará...
-
Page 24: Product Warranty And Repair
ALL EQUIPMENT TO BE REPAIRED OR REPLACED UNDER WARRANTY MUST BE RETURNED TO THE FACTORY. Before returning a product or products for any reason, the customer must call Daytronic Customer Support Services at (937) 866-3300 to request a O n c e t h e c u s t o m e r h a s p r o v i d e d RETURN MATERIAL AUTHORIZATION (RMA). - Page 25 3700 SERIES “P” Option ANALOG PEAK CAPTURE INSTRUCTION MANUAL 3700 Instrument Series...
- Page 26 3700 “P” Option Instruction Manual, v. A.01 Issued 07/15 3700 SERIES “P” Option ANALOG PEAK CAPTURE INSTRUCTION MANUAL Daytronic Corporation Dayton, OH • Tel (800) 668-4745 www.daytronic.com...
-
Page 27: General Description
1. General Description The “P” option of the 3700 Series Meter is an added function card which provides the ability of the meter to capture and hold + Peak, -Peak, Max-Min or TIR value that originates from the base 3700 instrument. -
Page 28: Dip Switch Configuration
DIP Switch Configuration Located on the rear panel above the main board connections, the 7 position dip switch configures the PEAK functions of the meter. The Default position of the switch is in the UP (ON) position as noted in the table below. -
Page 29: Pin Number
Functional Block Diagram of the PEAK switch settings 3. PEAK Interface I/O Connections Pin assignments for the 3700P board's 8-pin I/O connector (shown in Fig. 1) functional description Pin Number Function Output HAVE PEAK Output Logic Signal, indicates a Peak has been detected. Input TRACK or PEAK Input Logic Signal to Clear (Track) or to Arm for a Peak capture function... - Page 30 4. Setup conditions for the "P" option and TARE switch operation When the "P" option is installed - the front panel "TARE" Push/Push switch can be configured to operate in three seperate function modes for local operation depending on the DIP switch selection and/or logic inputs selected.
- Page 31 4. Interface I/O Connections Fig. 2 Interface Connector Operation Track/PEAK Via External Command (Switch, Open The 8 pin rear connector provides remote access to the Collector Transistor, or Peak operational parameters. All logic I/O are negative true TTL Logic) signals - logic common when active or true. Functional diagrams of the logic for enabling PEAK 2 (TRACK) functions are shown in Fig.
- Page 32 + PEAK Mode - captures and holds the most positive signal amplitude of the measurement within the positive quadrant of the signal. Switch 2 UP - Switch 3 UP Fig 3 - PEAK Mode - captures and holds the most negative signal amplitude of the measurement within the negative quadrant of the signal.
- Page 33 MAX + MIN Mode - captures and holds the most positive signal and the most negative signal amplitude in the positive and negative quadrants of the measurement resulting in an absolute analog output signal. Switch 2 UP - Switch 3 DOWN Fig 5 Note: When in Max-Min mode the analog signal may overrange due to the summing of the + Peak and - Peak captured signal.
- Page 34 Threshold Level Adjust and Have Peak Detection (Backout) Switch 6 - PEAK THRESHOLD DISPLAY ADJUST on the rear panel dip switch: When in the DOWN position, will switch the front panel display to provide level adjustment of the Threshold Potentiometer to provide a "No Peak Zone" around the Zero level. This adjustment is used to eliminate false Peak Captures around the zero measurement level as shown in the gray area of the Fig.
- Page 35 Quick Set-up operation 1. Determine the Peak Mode required Configure switch settings 2 and 3 for the proper function. 2. Select FAST or SELECT signal source Configure switch 1 - FAST will be the highest dynamic capture. SELECT will reflect the low pass filter selection on the main 3700 Analog Controls. 3.
- Page 36 Peak Capture Response The Peak Capture of the analog signal is performed using “capacitive” memory. This technique is very repeatable and does not involve digital sampling errors. It does, however result in a millivolt/second “leak rate” after the initial “capture” which varies depending on the Peak Capture cycle rate, amplitude of the analog signal and the wave shape of the signal being monitored.
- Page 37 Page left blank Page 11...
