KROHNE BM26A-5000 Handbook
KROHNE BM26A-5000 Handbook

KROHNE BM26A-5000 Handbook

Bypass chamber for level transmitters
Table of Contents

Advertisement

Quick Links

BM26A-5000
BM26A-5000
BM26A-5000
BM26A-5000
Bypass chamber for level transmitters:
- OPTIFLEX 7200 Guided Radar
- OPTIFLEX 8200 Guided Radar
- OPTIWAVE 7400 24 GHz FMCW Radar
- BW25 Displacer-Type
© KROHNE 01/2021 - 4008339901 - HB BM26A-5000 R01 en
Handbook
Handbook
Handbook
Handbook

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BM26A-5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KROHNE BM26A-5000

  • Page 1 BM26A-5000 Handbook Handbook Handbook Handbook Bypass chamber for level transmitters: - OPTIFLEX 7200 Guided Radar - OPTIFLEX 8200 Guided Radar - OPTIWAVE 7400 24 GHz FMCW Radar - BW25 Displacer-Type © KROHNE 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 2 All rights reserved. It is prohibited to reproduce this documentation, or any part thereof, without the prior written authorisation of KROHNE Messtechnik GmbH. Subject to change without notice. Copyright 2021 by KROHNE Messtechnik GmbH - Ludwig-Krohne-Str. 5 - 47058 Duisburg (Germany) www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 3: Table Of Contents

    4.5 Grounding connection ....................16 5 Start-up 5.1 Start-up checklist......................17 5.2 How to start the device....................17 6 Operation 6.1 Operating concept ......................18 6.2 Description of display ..................... 18 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 4 8.4.1 Magnetic level indicator with a 316 / 316 L bypass chamber ..........37 8.4.2 Magnetic level indicator with a 304 L bypass chamber ............40 9 Appendix 9.1 Glossary .......................... 42 10 Notes www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 5: Safety Instructions

    BM26A-5000 1.1 Intended use The BM26A-5000 is a bypass chamber designed for use with a FMCW Radar (non-contact radar), TDR (guided radar) or displacer-type level transmitter. This bypass chamber is connected to open or pressurized tanks. With the applicable options, it is resistant to difficult service conditions and liquids that are poisonous, flammable, or that cause corrosion.
  • Page 6: Eu Pressure Equipment Directive

    Tighten the process connections in agreement with the design code. • The user must take necessary steps to protect the installed device from shock waves (water hammer). A pressure-limiting valve must protect the installation. www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 7: Safety Instructions From The Manufacturer

    The manufacturer reserves the right to alter the content of its documents, including this disclaimer in any way, at any time, for any reason, without prior notification, and will not be liable in any way for possible consequences of such changes. 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 8: Product Liability And Warranty

    This document is provided to help you establish operating conditions, which will permit safe and efficient use of this device. Special considerations and precautions are also described in the document, which appear in the form of icons as shown below. www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 9: Warnings And Symbols Used

    In general, devices from the manufacturer may only be installed, commissioned, operated and maintained by properly trained and authorized personnel. This document is provided to help you establish operating conditions, which will permit safe and efficient use of this device. 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 10: Device Description

    Technical documentation for this device can be downloaded from the website (Download Centre). 2.2 Device description The BM26A-5000 is a bypass chamber for FMCW (non-contact) radar, TDR (Guided Radar) or displacer-type level transmitters. The level transmitter is installed on top of the bypass chamber.
  • Page 11 The bypass chamber can be made of: • 316/316L (1.4401/1.4404) stainless steel, • 304L (1.4307) stainless steel with >9.5% nickel content, • HASTELLOY® C-276 alloy (2.4819), or • INCONEL® nickel-chromium alloy 625 (2.4856) 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 12: Nameplates

    2 Optional level transmitter nameplate - for more data, refer to the related handbook INFORMATION! For more data about the level transmitter options, refer to the related handbook (BW25, OPTIWAVE 7400, OPTIFLEX 7200 or OPTIFLEX 8200). www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 13: Bypass Chamber Nameplate

    9 Construction code 10 CE marking PED certification agency code (0036) - if there is a PED marking given on the nameplate. Refer also to item 7 on this illustration. 11 Model name 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 14: Installation

    We recommend that you install isolation valves between the device and the tank. The device can then be easily removed from the tank for the cleaning procedure. Drain the device only when it is isolated from the tank. www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 15: Level Transmitter Options

    INSTALLATION BM26A-5000 3.4 Level transmitter options The level transmitter (OPTIFLEX 7200, OPTIFLEX 8200, OPTIWAVE 7400 or BW25) is attached to the bypass chamber at the factory. 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 16: Electrical Connections

    BW25 handbook. 4.5 Grounding connection Figure 4-1: Bypass chamber - location of grounding terminal 1 Bypass chamber nameplate 2 Grounding terminal on the side of the nameplate www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 17: Start-Up

    Do the servicing of device regularly to agree with the regulations of the site that it is installed on. CAUTION! Risk of damage to the device from shock waves. Open the valves slowly to prevent damage from water hammer. Use a pressure-limiting valve to prevent damage to the installation. 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 18: Operation

    This device is supplied as an option with the bypass chamber. For the device configuration procedure, refer to the BW25 handbook. 6.4 Errors For more data about error handling, refer to the handbook related to the level transmitter option. www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 19: Service

    • male and female plugs for drains and vents • ball valves • support brackets for the bypass chamber Use only KROHNE-authorized service staff to repair the device. 7.3 Availability of services The manufacturer offers a range of services to support the customer after expiration of the warranty.
  • Page 20: Returning The Device To The Manufacturer

    • such dangerous substances, to enclose a certificate with the device confirming that it is safe to handle and stating the • product used. www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 21: Form (For Copying) To Accompany A Returned Device

    We have flushed out and neutralized all cavities in the unit. We herewith confirm that in returning this unit there is no risk to man or environment through any residual liquid contained in it. Date: Company stamp: Signature: 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 22: Disposal

    The user must dispose of the WEEE to a designated collection point for the recycling of WEEE or send them back to our local organisation or authorised representative. www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 23: Technical Data

    The measuring principle is also related to the level transmitter option that you selected in the customer order. For more data, refer to the handbook for that level transmitter option. 1 Bypass chamber with level transmitter 2 Tank 3 Level of the liquid 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 24: Technical Data

    -196...+400°C / -320.8…+752°F (refer also to the handbook of the level transmitter option) Ambient temperature -70...+80°C / -94...+176°F (refer also to the handbook of the level transmitter option) Storage temperature -70…+80°C / -94…+176°F www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 25 PN40 (welding PN100 (welding PN160 or 250 neck or lap joint) neck) (welding neck) Facing type options B1; C; D; E; F B2; C; D; E; F B2; C; D; E; F 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 26 Refer to the handbook of the level transmitter option Electrical heat tracing Refer to the handbook of the electrical heat tracing equipment equipment Input and output Level transmitter Refer to the handbook of the level transmitter option www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 27 7 NPS = National Pipe Size. For more data about the dimensions of flanges, refer to the ASME B16.5 standard. For more data about the dimensions of welded pipes, refer to the ASME B36.19M standard. 8 Other process connections on request 9 Other vent and drain connections on request 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 28: Dimensions

    8.3 Dimensions 8.3.1 PN40 - Class 300 Figure 8-1: BM26A-5000 PN40 / Class 300: side - side process connections 1 Top flange (DN65 / NPS 2 1/2 or DN80 / NPS 3) for level transmitter option 2 Optional drain with 3/8...3/4 NPT female threaded connection (with plug) or DN15...50 / NPS 1/2…2 flange 3 Process connection (flange or welded pipe) 4 Optional side vent with 1/2...3/4 NPT or G 1/2...3/4 female threaded connection (with plug) or DN25 / NPS 1 flange...
  • Page 29 70.7 74.1 Table 8-2: BM26A-5000 PN40 / Class 300 (side - side process connections): general dimensions in mm 1 Drain options are available. NPT or G connection (female) + plug: 185 mm. Flange, DN15...25 and NPS 1/2...1: 270 mm. Flange, DN40...50 and NPS 1 1/2...2: 345 mm.
  • Page 30: Pn100 - Class 600

    8.3.2 PN100 - Class 600 Side - side process connections Figure 8-2: BM26A-5000 PN100 / Class 600: side - side process connections 1 Top flange (DN65 / NPS 2 1/2 or DN80 / NPS 3) for level transmitter option 2 Optional drain with 3/8...3/4 NPT female threaded connection (with plug) or DN15...50 / NPS 1/2…2 flange 3 Process connection (flange or welded pipe) 4 Optional side vent with 3/8...3/4 NPT female threaded connection (with plug) or DN25 / NPS 1 flange...
  • Page 31 3.94 2.92 Table 8-5: BM26A-5000 PN100 / Class 600 (side - side process connections): general dimensions in inches 1 Drain options are available. NPT or G connection (female) + plug: 7.28¨. Flange, DN15...25 and NPS 1/2...1: 10.63¨. Flange, DN40...50 and NPS 1 1/2...2: 13.58¨.
  • Page 32: Pn250 - Class 1500

    8.3.3 PN250 - Class 1500 Side - side process connections Figure 8-3: BM26A-5000 PN250 / Class 1500: side - side process connections 1 Top flange (NPS 2 Class 1500, NPS 3 Class 900, or NPS 3 Class 1500) for level transmitter option 2 Optional drain with 3/8...3/4 NPT female threaded connection (with plug) or DN15...50 / NPS 1/2…2 flange...
  • Page 33 70.7 74.1 Table 8-6: BM26A-5000 PN250 / Class 1500 (side - side process connections): general dimensions in mm 1 Drain options are available. NPT or G connection (female) + plug: 180 mm. Flange, DN15...25 and NPS 1/2...1: 297 mm. Flange, DN40...50 and NPS 1 1/2...2: 374 mm.
  • Page 34: Pn400 - Class 2500

    8.3.4 PN400 - Class 2500 Side - side process connections Figure 8-4: BM26A-5000 PN400 / Class 2500: side - side process connections 1 Top flange (NPS 2 Class 2500 or NPS 3 Class 2500) for level transmitter option 2 Optional drain with 3/8...3/4 NPT female threaded connection (with plug) or DN15...50 / NPS 1/2…2 flange 3 Process connection (flange or welded pipe) 4 Optional side vent with 1/2...3/4 NPT female threaded connection (with plug), or DN25 / NPS 1 flange...
  • Page 35 70.7 74.1 Table 8-8: BM26A-5000 PN400 / Class 2500 (side - side process connections): general dimensions in mm 1 Drain options are available. NPT or G connection (female) + plug: 185 mm. Flange, NPS 1/2...1: 324 mm. 2 This value agrees with the "C-C" dimension given in the customer order 3 Flange, NPS 1: 165 mm.
  • Page 36: Accessories

    Table 8-10: Support bracket: dimensions in mm Dimensions [inches] Øf Øg Support 2.87 0.12 2.05 1.12 0.16 0.33 0.59 0.59 1.97 3.15 1.02 0.47 0.65 1.30 0.16 2.28 bracket Table 8-11: Support bracket: dimensions in inches www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 37: Maximum Process Pressure: Bypass Chamber

    248.2 248.2 248.2 248.2 248.2 240.6 210.9 Class 2500 JIS B 2220 ASME B36.19M ISO 228-1 ASME B1.20.1 Table 8-12: Maximum process pressure [barg] for a given maximum process temperature [°C] 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 38 178.5 171.4 ISO 228-1 36.3 33.7 31.8 29.7 28.5 27.4 ASME B1.20.1 90.9 84.2 79.5 74.2 71.4 68.5 Table 8-13: Maximum process pressure [barg] for a given maximum process temperature [°C] www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 39 2588.9 2485.9 ISO 228-1 526.5 488.8 461.2 430.8 413.4 397.4 ASME B1.20.1 1318.4 1221.2 1153.1 1076.2 1035.6 993.5 Table 8-15: Maximum process pressure [psig] for a given maximum process temperature [°F] 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 40: Magnetic Level Indicator With A 304 L Bypass Chamber

    30.8 24.1 77.1 65.2 60.4 57.6 55.2 ISO 228-1 30.8 24.1 ASME B1.20.1 77.1 65.2 60.4 57.6 55.2 Table 8-17: Maximum process pressure [barg] for a given maximum process temperature [°C] www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 41 1015.3 945.6 835.4 880.6 ISO 228-1 446.7 377.1 349.5 333.6 319.1 ASME B1.20.1 1118.2 1015.3 945.6 835.4 880.6 Table 8-19: Maximum process pressure [psig] for a given maximum process temperature [°F] 01/2021 - 4008339901 - HB BM26A-5000 R01 en www.krohne.com...
  • Page 42: Appendix

    Electromagnetic compatibility Defines how much a device influences or is influenced by other devices that generate electromagnetic fields during operation. Refer to European standard EN 61326-1 and EN 61326-2-3 for further details. www.krohne.com 01/2021 - 4008339901 - HB BM26A-5000 R01 en...
  • Page 43: Notes
