- Page 1 Tiled Wood burning Stoves INSTRUCTION MANUAL FOR INSTALLATION USE AND MAINTENANCE OND12 TYPE COOKIN STACK MODEL...
- Page 2 3) Additional notes to the identification of the construction product: • SOLID FUEL RESIDENTIAL HEATING APPLIANCE 4) Name and address of the producer: • LA CASTELLAMONTE DI R. PERINO & S. NERI SNC VIA CASARI SN 10081 CASTELLAMONTE (TO) TEL. 0124581690 FAX 0124581690 info@lacastellamonte.it...
- Page 3 Dop – DECLARATION OF PERFORMANCE (DOP) In accordance with UE 305/2011 regulation 2090 9) Declared performance: CARATTERISTICHE ESSENZIALI / ESSENTIAL CHARACTERISTICS SPECIFICA TECNICA PRESTAZIONE / ARMONIZZATA / PERFORMANCE HARMONISED TECHNICAL SPECIFICATIONS Diametro scarico fumi / Smoke exit diameter / Diametre conduit des fumées / 12 cm EN-13240 Rauchrohrdurchmesser...
-
Page 4: Installation
THE CHIMNEY • The Chimney – our stoves’ “engine” • The Chimneypot INSTALLATION • Initial advice WORKING • Lighting and Combustion COMBUSTIBLE SAFETY ADVICES • External air inlet • Domestic fire prevention • Installation distances from combustible materials • Ceramic covering •... - Page 5 Please read this manual before installing and lighting the stove. If you have any doubt, please contact the selling Firm. 1.THE CHIMNEY Our stoves’ “engine”. The chimney is a key element for the optimal functioning of our stoves. General rules: Each device must have its own chimney to the roof, adequately insulated, through which the smoke will flow outside, through natural draft;...
- Page 6 FIG. 2 A FIG. 2 B FIG. 2 C...
- Page 7 The Chimneypot The chimney pot is placed on top of the chimney and helps to expell the smoke. The fundamental characteristics of the chimneypot are: It must have the same diameter of the chimney useful outlet section not less than twice the minimum of the chimney (ex. Chimney section 200 cm –...
- Page 8 FIG. 2 E...
- Page 9 2.INSTALLATION INITIAL ADVICE • The device must be installed on a floor with adequate capacity. If the existing building does not meet this requirement, appropriate measures (eg, load distribution plate) must be taken. • The installation must guarantee easy access to clean the stove, the smoke pipes and the chimney as well.
-
Page 10: Air Regulation
3.FUNCTIONING LIGHTING AND COMBUSTION If, during the first lighting, the stove should emanate smells due to the evaporation of substances used in the manufacturing, it is sufficient to ventilate the room for a few hours. Use small and medium-size logs and put them in the fireplace so that the air can penetrate between them. - Page 11 N.B. It is also necessary to clean from the ashes the fireplace area immediately behind the door in order to keep the primary air inlet open. The ash found in this area can be pushed towards the back of the fireplace or removed. By using dry and seasoned wood, it is possible to obtain a high flame and to immediately activate the draft in the chimney.
- Page 12 However, if the smoke comes out from the stove while loading it, ventilate momentarily the room and continue to load more slowly, giving time to ignite the wood. The firebox and the ashtray doors must be kept closed except during lighting, charging and embers removing, in order to avoid smoke escape.
-
Page 13: External Air Inlet
5.SAFETY EXTERNAL AIR INLET The stove must have the necessary air so as to ensure a regular combustion and a healthy environment, so: Make sure that in the room where the stove is installed there is adequate ventilation, the minimum recommended section is > 80 cm for devices with closed fireplace The air intake must be directly communicating with the room in which the... - Page 14 HOME FIRE SAFETY Installation and use of the stove should be in accordance with the instructions of the manufacturer and the local rules of habitability. • When a flue pipe pass through a wall or ceiling particular methods of installation should be applied (protection, thermal insulation, distance from heat sensitive material, etc) •...
- Page 15 INSTALLATION DISTANCES FROM FLAMMABLE MATERIAL Minimum installation distances from flammable material: -minimum distance from lateral flammable wall: 300mm -minimum distance from flammable rear wall: 200mm Minimum front distance from flammable material: 100cm CERAMIC COATING • The various ceramic parts must be handled with extreme care. •...
- Page 16 6. ASSEMBLY 3. place the door 2. place the first flange – sustain it ceramic element until it is completely screwed 4. screw the 8 screws 5. place the little of the door flange refractory brick...
