INSTRUCTION MANUAL
FOR INSTALLATION
USE AND MAINTENANCE
RNO 200
TYPE
MODEL
1
SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RNO 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LA CASTELLAMONTE RNO 200

  • Page 1 INSTRUCTION MANUAL FOR INSTALLATION USE AND MAINTENANCE RNO 200 TYPE MODEL SAVE THESE INSTRUCTIONS...
  • Page 2: Table Of Contents

    INDEX CHARACTERISTICS • Scheme with legenda THE CHIMNEY FLUE • The Chimney flue – our stoves’ “engine” • The Chimneypot • Chimney Systems INSTALLATION • Initial advices p.17 • Installation distances from flammable material p.18 OPERATION • Lighting and Combustion p.19 COMBUSTIBLE p.22...
  • Page 3: Scheme With Legenda

    SCHEME WITH LEGENDA 0,31inches 1,18 inches 1,57 inches...
  • Page 4: The Chimney Flue

    SAFETY NOTICE: IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, OPERATED AND MAINTAINED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA Please read this entire manual before you install and use your new room heater.
  • Page 5 shall end with an airtight door, accessible for cleaning. This will avoid unpleasant smells, bad draft and frequent cleaning of the stove. FIG. 2 A FIG. 2 B 16,40 ft FIG. 2 C...
  • Page 6: The Chimneypot

    The Chimneypot The chimney pot is placed on top of the chimney and helps to expell the smoke. The fundamental characteristics of the chimneypot are: It must have the same diameter of the chimney flue useful outlet section not less than twice the minimum of the chimney flue (ex. Chimney flue section 200 cm -31 inches –...
  • Page 7: Chimney Systems

    CHIMNEY SYSTEMS - DO NOT INSTALL A FLUE DAMPER - DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE A. Venting Systems The venting system consists of: • A chimney connector (also known as flue or stove pipe) •...
  • Page 8 FIGURE 3A NOTE: In Canada when using a factory- built chimney it must be safety listed, Type UL103 HT (2100oF) CLASS “A” or conforming CAN/ULC-S629M, STANDARD FOR 650oC FACTORY- BUILT CHIMNEYS. FIGURE 3B - Solid Pack Chimney with metal Supports as a Thimble...
  • Page 9 FIGURE 3C B. Chimney Systems • The chimney connector joins the stove to the chimney. • It must be a 6 inch (152mm) minimum diameter 24 gauge mild steel black or 26 gauge blued steel. • Or an approved air-insulated double wall venting pipe. Single wall connector or stove pipe •...
  • Page 10 The listed connectors must conform to each other to ensure a proper fit and seal. FIGURE 3D WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this information manual provided with the appliance. For assistance or additional information consult a qualified installer, service agency or your dealer.
  • Page 11 D. Factory-Built Chimney The chimney can be new or existing, and must meet the following minimum requirements. • Must be a 6 inch (152mm) diameter (ID) high temperature chimney listed to UL 103 HT (2100oF) or ULC S629M. • Must use components required by the manufacturer for installation. •...
  • Page 12 FIGURE 3F – Factory built interior chimney WARNING Fire Risk – do NOT pack insulation or other combustibles between spacers. ALWAYS maintain specified clearances around venting and spacers. Install spacers as specified. FAILURE TO KEEP INSULATION OR OTHER MATERIAL AWAY FROM VENT PIPE MAY CAUSE FIRE.
  • Page 13 FIGURE 3G WARNING Fire risk – When lining air-cooled factory-built chimneys: run chimney liner approved to UL 1777 Type HT requirements (2100 degrees F) re-install original factory built chimney cap ONLY DO NOT block cooling air openings in chimney blocking cooling air will overheat the chimney E.
  • Page 14 • The masonry wall of the chimney, if brick or modular block, must be a minimum of 4 inches (102mm) nominal thickness. • A chimney of rubble stone must be at least 12 inches (305mm) thick. • The chimney must have a fire clay flue liner (or equivalent) with a minimum thickness of 5/8 inch (16mm) and must be installed with refractory mortar.
  • Page 15 CHIMNEY TERMINATION REQUIREMENTS Follow manufacturer’s instructions for clearance, securing flashing and terminating the chimney. • Must have an approved and Listed cap • Must not be located where it will become plugged by snow or other material • Must be located away from trees or other structures D.
  • Page 16 > 4,26 ft 1,64 ft over the ridge h min 4 ft 2,62 ft reflux area d> 16,50 ft 1,64 ft 1,64 ft...
  • Page 17: Installation

    INSTALLATION VENT SPECIFICATION: six (6) inches diameter, minimum 24 MSG black or blued steel connector pipe, with a listed factory-built UL103HT Class A chimney, suitable for use with solid fuels, or a masonry chimney and the referenced clearances. THIS ROOM HEATER MUST BE CONNECTED TO: A chimney complying with the requirements for Type HT chimneys in the Standard for Chimneys, Factory-Built, Residential Type and Building Heating Appliance, UL 103, or A code-approved masonry chimney with a flue liner.
  • Page 18: Installation Distances From Flammable Material

    INSTALLATION DISTANCES FROM FLAMMABLE MATERIAL COMPLY WITH ALL MINIMUM CLEARANCES TO COMBUSTIBLES AS SPECIFIED. FAILURE TO COMPLY MAY CAUSE HOUSE FIRE. Minimum installation distances from flammable material - Minimum distance from lateral flammable wall/material: 200 mm – 8 inches - Minimum distance from rear flammable wall/material: 200 mm – 8 inches - Minimum distance from flammable floor: 80 mm –...
  • Page 19: Operation

    OPERATION Lighting and combustion DO NOT USE GRATES OR ELEVATE FIRE. BUILD WOOD FIRE DIRECTLY ON EARTH. If, during the first lighting, the stove should emanate smells due to the evaporation of substances used in the manufacturing, it is sufficient to ventilate the room for a few hours. Use small and medium-size logs and put them in the fireplace so that the air can penetrate between them.
  • Page 20 N.B. It is also necessary to clean the fireplace area immediately behind the door from the ashes in order to keep the primary air inlet open. The ash found in this area can be pushed towards the back of the fireplace or removed. Remove the ashes from the fireplace before their level is so high as to close the primary air entrance.
  • Page 21 For a good yield, it is necessary to always have a good quantity of wood inside the fireplace; without overfilling it and without pressing its ceiling and its walls (it is always advisable to leave some space to let the air circulate and the inner refractory bricks to dilate). In this way, the air will circulate freely while keeping a “lively”...
  • Page 22: Combustible

    THE FIREPLACE DOOR MUST BE KEPT CLOSED during lighting (only the moment in which you light the lighter under the wood, then close it), charging and embers removing, in order to avoid smoke escape. For night operating, use large size logs and possibly of hard species (beech, oak, etc..) and if the wind and draft conditions are reasonably stable, the stove will continue to burn calmly.
  • Page 23: Safety

    SAFETY Air inlet The stove must have the necessary air so as to ensure a regular combustion and a healthy environment, so: Make sure that in the room where the stove is installed there is adequate ventilation, the minimum recommended section is > 80 cm (12 inches ) for devices with closed fireplace...
  • Page 24: Home Fire Safety

    HOME FIRE SAFETY Installation and use of the stove should be in accordance with the instructions of the Manufacturer and the local rules of habitability. • When a flue pipe pass through a wall or ceiling particular methods of installation should be applied (protection, thermal insulation, distance from heat sensitive materials, etc) •...
  • Page 25 • In Canada, it is necessary to install a floor protector of non-combustible material a minimum of 18 inches (457mm) in front of glass and 8 inches (203mm) to both sides and back of the appliance. see exception • EXCEPTION: non-combustible floor protections must extend beneath the flue pipe when installed with horizontal venting and extend 2 inches (51mm) beyond each side.
  • Page 26: Ceramic Lining

    Minimum front distance from flammable material: 1000 mm – 40 inches NOTICE: LA CASTELLAMONTE assumes no responsibility for the improper performance of the appliance system caused by: • Inadequate draft due to environmental conditions • Downdrafts • Tight sealing construction of the structure •...
  • Page 27 HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass will cause burns. • Do not touch glass until it is cooled • NEVER allow children to touch glass • Keep children away • CAREFULLY SUPERVISE children in same room as appliance. •...
  • Page 28: Assembly Schemes

    ASSEMBLY SCHEMES...
  • Page 29 ASSEMBLY SCHEMES...
  • Page 30 ASSEMBLY SCHEMES...
  • Page 31: Maintenance

    MAINTENANCE The installation of the stove must guarantee easy access for its cleaning, as well as for the cleaning of the flue pipes and of the chimney flue. All maintenance operations must be carried out on the stove off and cold. Ash disposal The removal of the ashes from the fireplace is made with the proper paddle directly from the fireplace floor.
  • Page 32: Warranty

    WARRANTY La Castellamonte will replace or repair the goods or its individual components when they are found in lack of conformity which existed at the time the goods were delivered in the manner and extent permitted by the law. (d. lgs 206/05)
  • Page 33 LA CASTELLAMONTE di R. Perino e S. Neri Snc Via Casari 13, s.n. – Tel. e fax 0039 124 581690 – 0039 124 514149 10081 Castellamonte (TO) – Italy www.lacastellamonte.it www.stackstoves.com e-mail: info@lacastellamonte.it...
