Instructions for:
7106YT Coat Locker, 5-Section
Hardware Package HCJX
Qty
Description
(1)
XAUS 4mm Hex Wrench
(32) XAUR 2" Decorative Screw
(12) XCPT #8 X 0-7/8" Washerhead Screw
(10) XBTX #6 Truss Screw
(5)
XCLX Almond Double Coat Hook
Parts:
DHCJX – Rev. B – 23 October 2019
800-543-4149
507-342-5169
www.jonti-craft.com
WARNING:
CHOKING HAZARD/SHARP POINTS- Assembly
hardware contains small parts and components
with sharp points. Adult assembly required.
Tools Required:
-4mm Hex Wrench (Provided)
-Medium Phillips Screwdriver
Hardware Included:
Page 1 of 4
Not Actual Size
JonTi-Craft, Inc.
171 Hwy 68
P.O. Box 30
Wabasso, MN 56293
Advertisement
Related Manuals for Jonti-Craft Young Time Coat Locker 7106YT
Summary of Contents for Jonti-Craft Young Time Coat Locker 7106YT
- Page 1 (32) XAUR 2” Decorative Screw (12) XCPT #8 X 0-7/8" Washerhead Screw (10) XBTX #6 Truss Screw XCLX Almond Double Coat Hook Not Actual Size Parts: JonTi-Craft, Inc. DHCJX – Rev. B – 23 October 2019 171 Hwy 68 800-543-4149 P.O. Box 30 507-342-5169 Wabasso, MN 56293 www.jonti-craft.com...
- Page 2 Decorative Screws with 4mm Hex Wrench provided. 3. Install 4 Dividers- with rounded edge down. Align Divider cutouts with Shelf cutouts ensuring all coat hooks are towards the top. JonTi-Craft, Inc. DHCJX – Rev. B – 23 October 2019 171 Hwy 68 800-543-4149 P.O.
- Page 3 Top, Bottom and Shelves by aligning dowels into dowel holes in RH Side. Secure XAUR with 8- Decorative Screws with 4mm Hex Wrench provided. JonTi-Craft, Inc. DHCJX – Rev. B – 23 October 2019 171 Hwy 68 800-543-4149 P.O. Box 30...
- Page 4 8. Install remaining 3-Backs in the same manner. Once all backs and screws are installed tighten all screws. 9. Stand unit upright. 10. If you experience any difficulties when assembling this product, please contact the Jonti-Craft Customer Relations Team at (800) 543-4149 or sales@jonti-craft.com All other requests for assistance must be directed to your Jonti-Craft Dealer.
