Owner's Guide
Please read entire booklet before assembling KYDZ Suite
products.
®
Keep this booklet for future reference and add-ons.
The KYDZ Suite line of products and all Jonti-Craft products are intended for use in
caring for children of immature judgement; adult supervision is required at all times!
www.jonti-craft.com/kydzsuite
Advertisement
Table of Contents
Related Manuals for Jonti-Craft KYDZ Suite Series
Summary of Contents for Jonti-Craft KYDZ Suite Series
- Page 1 Please read entire booklet before assembling KYDZ Suite products. ® Keep this booklet for future reference and add-ons. The KYDZ Suite line of products and all Jonti-Craft products are intended for use in caring for children of immature judgement; adult supervision is required at all times! www.jonti-craft.com/kydzsuite...
-
Page 2: Table Of Contents
With an easy-to-use Tab Mounting Template and Hub Connector Tabs, KYDZ Suite easily connects to most Jonti-Craft products, letting you make the most of what you already have. KYDZ Suite is also GREENGUARD Gold Certified which means you can breathe easy knowing that these products contribute to healthier indoor air quality. -
Page 3: The Essentials Of Kydz Suite
The Essentials of KYDZ Suite The KYDZ Suite line of products and all Jonti-Craft products are intended for use in caring for children of immature judgement; adult supervision is required at all times! Never connect more than two KYDZ Suite Panels in a straight line without... - Page 4 The Essentials of KYDZ Suite KYDZ Suite Panels must always be connected at the ends, either to another Panel, a wall (via the KYDZ Suite Wall Adapter), a stationary Jonti-Craft furniture item or a pair of KYDZ Suite Stabilizer Wings.
- Page 5 Use KYDZ Suite Cascade Panels to connect from E-Height to A or T-Height. Do not attempt to connect different height items together without the use of a Cascade Panel. A-Height A to E-Height Cascade Panel E-Height DHBWI-316 www.jonti-craft.com/kydzsuite 800.543.4149 Page 5...
- Page 6 KYDZ Suite Welcome Gates and Welcome Arches must either be connected to KYDZ Suite Panels at an angle other than 180˚ (straight line) or be connected to a stationary Jonti-Craft furniture item. They can also be supported via a pair of KYDZ Suite Stabilizer Wings on each end. The Welcome Gates and Welcome Arches should be placed on a flat surface with the handle facing outwards, away from the space children primarily occupy.
- Page 7 Go to page 16 for Upper Deck Divider assembly instructions. KYDZ Suite Panels are the same length as most Jonti-Craft units, so they can easily be interchanged with one another. KYDZ Suite products are intended for indoor use only.
-
Page 8: Assembling Hubs
Then retighten top cap top cap by twisting by twisting clockwise counter clockwise with your hand. with your hand. Once loose, simply pull off connector block. DHBWI-316 www.jonti-craft.com/kydzsuite 800.543.4149 Page 8... -
Page 9: Assembling Panels
Hub. NOTE: a Hub can be attached to the post with the connector block more than two items at a time (i.e., two Screw in the top cap until tight. Panels and two Stabilizer Wings). DHBWI-316 www.jonti-craft.com/kydzsuite 800.543.4149 Page 9... -
Page 10: Assembling Hub Connector Tabs
Assembling Hub Connector Tabs Mounting Template 1. To apply Hub Connector Tabs to a Jonti-Craft furniture 2. Drill holes using the ” drill bit from item, first place the Tab Mounting Template included the starter kit. NOTE: Drill no in your starter kit on the side of the unit as shown. -
Page 11: Assembling Items To Jonti-Craft Units
Assembling Items to Jonti-Craft Units To connect a KYDZ Suite item to a Jonti-Craft furniture item, first follow the instructions on page 10 while using the included Tab Mounting Template. Once the Hub Connector Tabs are in place, slide the unit into a groove in the bottom connector block. -
Page 12: Assembling Wall Mounts
4. Screw in the two supplied #8 – 2½” screws 5. Your Wall Connector is now through the holes in the Wall Connector and securely in place. into the wall. Be sure the screws are securely into the stud. DHBWI-316 www.jonti-craft.com/kydzsuite 800.543.4149 Page 12... -
Page 13: Assembling Immobilizer Blocks
Immobilizer Block Installing Immobilizer Blocks allows you to convert a mobile Jonti-Craft furniture item to a stationary unit. To insert Immobilizer Blocks under a mobile Jonti-Craft furniture item, slide one block under the base rail in each corner of the storage unit. The unit may need to be lifted slightly. -
Page 14: Assembling Accordion Panels
Accordion Panel to other KYDZ Suite items and page 11 to attach to Jonti- Craft furniture items. CAUTION: To prevent children from playing with the knobs, face side of Panel with knobs outward, away from the space children primarily occupy. DHBWI-316 www.jonti-craft.com/kydzsuite 800.543.4149 Page 14... -
Page 15: Assembling Filler Plates
Filler Plate of the Hub and place the Filler Plate over the top connector blocks. top cap top cap Reinsert the top caps and tighten. There should no longer be a space between your Jonti-Craft units. DHBWI-316 www.jonti-craft.com/kydzsuite 800.543.4149 Page 15... -
Page 16: Assembling Upper Deck Dividers
Assembling Upper Deck Dividers 1. First attach Hub Connector Tabs to rear of the Jonti-Craft furniture item on both sides by following directions on page 10. Then attach Hub (without top cap and top connector block) to the mounted Hub Connector Tabs at the rear of the unit. - Page 17 6. Place the top connector blocks over the Hub 7. Your Upper Deck Divider is now ready Connector Tabs on the Panel and screw in for use. the top cap from the Hubs. DHBWI-316 www.jonti-craft.com/kydzsuite 800.543.4149 Page 17...
- Page 18 KYDZ Suite product, any use not compliant with published KYDZ Suite guidelines or connecting KYDZ Suite products to non-Jonti-Craft brand products voids this warranty. For full and detailed warranty information or to submit a warranty claim, please contact Jonti-Craft at 507.342.5169.
