- Page 1 LCD Monitor User Manual C24V1H/C27V1Q/C32V1Q/CQ32V1 LED backlight www.aoc.com ©2018 AOC. All Rights Reserved.
-
Page 2: Table Of Contents
Safety ..................................3 National Conventions ............................3 Power ................................4 Installation ................................5 Cleaning................................6 Other .................................. 7 Setup ..................................8 Contents in Box ..............................8 Setup Base ................................ 9 Adjusting Viewing Angle ........................... 10 Connecting the Monitor ............................ 11 Hotkeys ................................ -
Page 3: Safety
Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 4: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the monitor from damage due to power surges. -
Page 5: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 6: Cleaning
Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. -
Page 7: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 8: Setup
IO Cover Power Cable Analog Cable HDMI Cable DP Cable Not all signal cables ( Analog, HDMI, DP cables),CD manual will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. -
Page 9: Setup Base
Setup Base Please setup or remove the base following the steps as below. Please place the monitor on the curve-surface foamed cushion to prevent the scratch. Setup: Remove:... -
Page 10: Adjusting Viewing Angle
Adjusting Viewing Angle For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor's angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor's angle. NOTE: Do not adjust the viewing angle over 23 degrees in order to avoid damage. -
Page 11: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor and Computer: Power HDMI Analog (D-Sub 15-Pin VGA cable) Earphone out To protect equipment, always turn off the PC and LCD monitor before connecting. Connect the power cable to the AC port on the back of the monitor. Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer's D-Sub port. -
Page 12: Hotkeys
Hotkeys Source/Auto/Exit/Up Eco/DCR/Down Clear Vision/Left Image Ratio/Volume/Right Power/ Menu/Enter Menu/Enter Press to display the OSD or confirm the selection. Power Press the Power button to turn on/off the monitor. Image Ratio/Volume/Right When there is no OSD, Press Volume button to active volume adjustment bar, Press Left or Right to adjust volume. When there is no OSD, press Right hotkey continuously to change 4:3 or wide image ratio. - Page 13 Clear Vision When there is no OSD, Press the “Left” button to activate Clear Vision. Use the “Left” or “Right” buttons to select between weak, medium, strong, or off settings. Default setting is always “off”. Press and hold “Left” button for 5 seconds to activate the Clear Vision Demo, and a message of “Clear Vision Demo: on”...
-
Page 14: Osd Setting
OSD Setting Basic and simple instruction on the control keys. Press the MENU-button to activate the OSD window. Press Left or Right to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it. If there is a sub-menu, press Left or Right to navigate through the sub-menu functions. -
Page 15: Luminance
Luminance MENU 1 Press (Menu) to display menu. MENU 2 Press Left or Right to select (Luminance), and press to enter. 3 Press Left or Right to select submenu. 4 Press Left or Right to adjust. AUTO 5 Press to exit Contrast 0-100 Contrast from Digital-register. -
Page 16: Image Setup
Image Setup MENU 1 Press (Menu) to display menu. MENU 2 Press Left or Right to select (Image Setup), and press to enter. 3 Press Left or Right to select submenu. 4 Press Left or Right to adjust. AUTO 5 Press to exit Clock 0-100... -
Page 17: Color Setup
Color Setup MENU 1 Press (Menu) to display menu. MENU 2 Press Left or Right to select (Color Setup), and press to enter. 3 Press Left or Right to select submenu. 4 Press Left or Right to adjust. AUTO 5 Press to exit Warm Recall Warm Color Temperature from EEPROM. -
Page 18: Picture Boost
Picture Boost MENU 1 Press (Menu) to display menu. MENU 2 Press Left or Right to select (Picture Boost), and press to enter. 3 Press Left or Right to select submenu. 4 Press Left or Right to adjust. AUTO 5 Press to exit Bright Frame ON/OFF... -
Page 19: Osd Setup
OSD Setup MENU 1 Press (Menu) to display menu. MENU 2 Press Left or Right to select (OSD Setup), and press to enter. 3 Press Left or Right to select submenu. 4 Press Left or Right to adjust. AUTO 5 Press to exit Language Select the OSD language. -
Page 20: Extra
4 Press Left or Right to adjust. AUTO 5 Press to exit C27V1Q/C32V1Q/CQ32V1: Auto/D-SUB/HDMI/DP Input Select Select signal source as input C24V1H: Auto/D-SUB/HDMI Auto Config. Yes / No Auto adjust.the picture to default. Off Timer 0-24 hrs Select DC off time. -
Page 21: Exit
Exit MENU 1 Press (Menu) to display menu. MENU 2 Press Left or Right to select (Exit), and press to enter. AUTO 3 Press to exit Exit Exit the main OSD LED Indicator Status LED Color Full Power Mode White Power Saving Orange... -
Page 22: Troubleshoot
Adjust the maximum resolution and frequency that the monitor can handle properly. Make sure the AOC Monitor Drivers are installed. Adjust the Contrast and Brightness Controls. Press to auto adjust. Picture Is Fuzzy & Has Make sure you are not using an extension cable or switch box. - Page 23 The Computer Power Switch should be in the ON position. The Computer Video Card should be snugly fitted in its slot. Make sure the monitor's video cable is properly connected to the computer. Monitor Is Stuck In Active Inspect the monitor's video cable and make sure no pin is bent. Off-Mode"...
-
Page 24: Specification
Specification General Specification Model name C24V1H Driving system TFT Color LCD Viewable Image Size 23.6inch, 59.9cm diagonal Panel Pixel pitch 0.2715(H)mm x 0.2715(V)mm Video R, G, B Analog Interface & HDMI Interface Separate Sync. H/V TTL Display Color 16.7M Colors... - Page 25 Model name C27V1Q Driving system TFT Color LCD Viewable Image Size 27inch, 68.6cm diagonal Panel Pixel pitch 0.3114(H)mm x 0.3114(V)mm Video R, G, B Analog Interface & HDMI Interface & DP Interface Separate Sync. H/V TTL Display Color 16.7M Colors Horizontal scan range 30~83KHz Horizontal scan...
- Page 26 Model name C32V1Q Driving system TFT Color LCD Viewable Image Size 31,5inch, 80.0cm diagonal Panel Pixel pitch 0.36375(H)mm x 0.36375(V)mm Video R, G, B Analog Interface & HDMI Interface & DP Interface Separate Sync. H/V TTL Display Color 16.7M Colors Horizontal scan range 30~83KHz Horizontal scan...
- Page 27 Model name CQ32V1 Driving system TFT Color LCD Viewable Image Size 31,5inch, 80.0cm diagonal Panel Pixel pitch 0.2724(H)mm x 0.2724(V)mm Video R, G, B Analog Interface & HDMI Interface & DP Interface Separate Sync. H/V TTL Display Color 16.7M Colors Horizontal scan range 30~99kHz Horizontal scan...
-
Page 28: Preset Display Modes
56.476 70.069 1024x768@75Hz 60.023 75.029 1280x1024@60Hz 63.981 60.02 SXGA 1280x1024@75Hz 79.976 75.025 1280x720@60HZ WSXG 1280x960@60HZ WXGA+ 1440x900@60Hz 55.935 59.876 WSXGA+ 1680x1050@60Hz 65.29 59.954 1920x1080@60Hz 67.5 FHD(HDMI、DP) 1920x1080@75Hz 83.894 74.973 C24V1H/C27V1Q/C32V1Q QHD(HDMI、DP) CQ32V1 2560x1440@60Hz 88.787 59.951 QHD(HDMI、DP) CQ32V1 2560x1440@75Hz 111.028 74.968... -
Page 29: Pin Assignments
Pin Assignments 15-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Video-Red Video-Green Ground Video-Blue N.C. N.C. DDC-Serial data Detect Cable H-sync GND-R V-sync GND-G DDC-Serial clock GND-B 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. - Page 30 20-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name ML_Lane 3 (n) ML_Lane 0 (p) ML_Lane 3 (p) CONFIG1 ML_Lane 2 (n) CONFIG2 AUX_CH(p) ML_Lane 2 (p) ML_Lane 1 (n) AUX_CH(n) Hot Plug Detect ML_Lane 1 (p) Return DP_PWR ML_Lane 0 (n) DP_PWR...
-
Page 31: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
