SECTION 4.
[CHASSIS PARTS]
REF ORDER
NO. NO.
W1 8900018230 OPC-1886 <LIA>
MP1 8510012340 2273 L-CASE
MP2 8930049320 2288 VENT.SHEET
MP3 8810008661 PHBT M3 X 8 NI-ZC3
MP11 8510012351 2273 U-CASE-1
MP13 8930049392 2273 MAIN SEAL-2 (TOT)
MP14 8820001210 2438 SCREW
MP15 8930052290 O-RING (AD) (TOP)
[MAIN UNIT]
REF ORDER
NO. NO.
J2* 6510018951 B7B-PH-SM4-TB (LF) (SN)
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations

MECHANICAL PARTS

DESCRIPTION
DESCRIPTION
W1(C)
MP1(C)
MP15(C)x4
MP14(C)x4
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[ACCESSORIES]
REF ORDER
QTY.
NO. NO.
1 MP1 8930049400 2273 PIPE
MP2 8930049740 HAS-40 (X-2272-3) STAINLESS BAND
1
1
4
MP1
1
1
4
4
QTY.
1
MP11(C)
MP13(C)
MP3(C)
MAIN UNIT
J2(M)
MP2(C)
4 - 1
DESCRIPTION QTY.
MP2
1
2
