INTRODUCTION
This service manual describes the latest technical
information for the MXG-5000 GPS RECEIVER, at the time
of publication.
MODEL
MXG-5000
To upgrade quality, any electrical or mechanical parts
and internal circuits are subject to change without notice
or obligation.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom part number
2. Component name
3. Equipment model name and unit name
4. Quantity required
<ORDER EXAMPLE>
8900018230 OPC-1886 MXG-5000
8510012351 2273 U-CASE-1 MXG-5000
Addresses are provided on the inside back cover for your
convenience.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other countries.
VERSION
EXP
USA
EUR
CHASSIS UNIT 2 pieces
CHASSIS UNIT 3 pieces
CAUTION
NEVER connect the receiver to an AC outlet or to a DC
power supply that uses more than specified. This will ruin
the receiver.
DO NOT reverse the polarities of the power supply when
connecting the receiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the receiver's
front-end.
REPAIR NOTES
1. Make sure that the problem is internal before
disassembling the receiver.
2. DO NOT open the receiver until the receiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts.
5. DO NOT keep power ON for a long time when the
receiver is defective.
