Summary of Contents for Ideal Heating Halo
- Page 1 For use with...
- Page 2 If you have purchased or are upgrading a Halo Heat & System RF (non-connected control) you can upgrade this to an internet heating control by downloading the Halo app and following the steps in the app to connect your Halo control. You will be required to pay a connection fee to upgrade to app controlled heating.
-
Page 3: Mode Selection
MAIN FEATURES HEATING MODE SELECTION You can choose to run your Halo in Auto, Manual or Off mode. The current mode is Auto: runs your heating to displayed bottom right pre-set scheduled times and temperatures. Press the right hand button... - Page 4 MAIN FEATURES HEATING PLUS HOURS If you are running a schedule with pre-set times (Auto mode) and you want to maintain the current temperature of your Press and hold the dial to heating instead of moving to the extend the current heating next setting simply press the dial.
- Page 5 MAIN FEATURES HEATING OVERRIDE If you are running a schedule with pre-set times (Auto mode) and you want to adjust the temperature of your heating temporarily, simply turn the dial to your desired temperature. The new temperature will be active until the next scheduled change shown under the target temperature.
- Page 6 MAIN FEATURES HEATING SCHEDULES Turn the dial to move Your Halo will come with between the different days a pre-set schedule: and view the schedule that is set. To edit a day, push the 6:00am - 8:00am 21°C dial or right hand button...
- Page 7 MAIN FEATURES HOT WATER To access the hot water functions, when on the heating home screen, Hot water on simply press the dial. until 10:00pm Alternatively press the menu button, scroll to Hot Water hot water auto menu mode Push dial to alternate Control and press confirm.
- Page 8 MAIN FEATURES HOT WATER MODE SELECTION You can choose to run your Hot Water in Auto, On or Off Hot water on mode. until 10:00pm The current mode is displayed bottom right Auto: runs your hot water hot water auto to pre-set scheduled times menu mode...
- Page 9 MAIN FEATURES HOT WATER BOOST If you are running a schedule with pre-set times (Auto mode) and Hot water on you want to boost your hot water until 10:00pm rather than wait for the next setting simply turn the dial. hot water auto menu...
- Page 10 MAIN FEATURES HOT WATER SCHEDULES Turn the dial to move HW Schedule Your Halo will come with between the different days 6:00am 8:00am a pre-set schedule: and view the schedule that 8:00am 4:00pm 4:00pm 6:00pm is set. To edit a day, push the...
- Page 11 HALO SMART INTERFACE The Halo Smart Interface will be installed in the The Halo Smart Interface has a Failsafe/Override aperture in the front of your Ideal boiler. It will feature which can be used to switch your boiler on wirelessly communicate with your Halo control...
- Page 12 HALO SMART WIRING CENTRE The Halo Smart Wiring Centre will wirelessly The Halo Smart Wiring Centre has a Failsafe/ communicate with your Halo Smart Interface, in Override feature which can be used to open normal circumstances you will not have to interact...
-
Page 13: Additional Features
Halo. Fault If there is a fault then the fault symbol will show on the home screen of your Notification Halo. Press the left hand button to access further information about the fault. - Page 14 Flame Indicates your heating is on. Fault Indicates there is a fault with the boiler. Child lock Childlock is set so the Halo cannot be altered. Override Override or plus hours function is active. Optimised start Optimised start is active.
- Page 15 Battery status indication. Indicates that the Halo is communicating Zigbee with the Smart Interface. Indicates that the Halo is communicating with internet and can be controlled with the Halo app via your smart phone. Cloud* *Halo Combi Wi-Fi only Hot water Indicates that the hot water demand is active.
- Page 16 There are also two finger grabs top and bottom as shown below. Use the finger grabs to gently pull the Halo away from the rear housing. Do not use a screwdriver to separate. Remove all the old batteries and replace with 4 new The Halo will go through a short synchronisation AA Alkaline batteries.
-
Page 17: Troubleshooting
SMART INTERFACE WITH SMART INTERFACE If the below message shows on the Halo screen If the below message shows on the Halo screen then then it is not communicating with the Halo Smart the Smart Wiring Centre is not communicating with Interface. - Page 18 In the unlikely event that the Halo loses pairing you key to view the fault and recommendations. will see the following screen. To re-pair go to section H in the Halo Heat & System installation instructions. You can also find a copy of the installation guide at idealheating.com...
-
Page 19: Warranty
WARRANTY Your Ideal Halo comes complete with a 2 year Ideal b. To any defect, damage or breakdown caused by Guarantee, subject to the following terms and the design, installation and maintenance of the conditions. central heating system. d. To any other costs or expenses caused by or arising During the period of the guarantee we will replace as a result of the breakdown of the controls. - Page 20 T: 01482 498660 following internet address idealheating.com E: enquiries@idealheating.com UIN: 227160 A01 RF frequency: 2405 – 2480MHz Max. RF output power: 10dBm Ideal Heating is a trading name of Ideal Boilers and associated Group Companies welcome to our ideology idealheating.com |...
Need help?
Do you have a question about the Halo and is the answer not in the manual?
Questions and answers
I have changed my internet provider and I need to change it in the halo How do I do it
To change the internet provider settings on an Ideal Heating Halo, follow these steps:
1. If you have a new fibre router, broadband/fibre provider, or changed your Wi-Fi password, the Halo needs to reconfigure to connect to the new Wi-Fi network.
2. Put the Smart Interface into access point mode by pressing the override button for 5 seconds (a flashing blue LED indicates this mode).
3. Use the setup steps to connect the Halo to the new Wi-Fi network.
4. Once connected, press the override button again for 5 seconds to exit access point mode.
5. Ensure the router is connected to the internet by testing with a tablet or PC (not a mobile phone using mobile data).
If internet is not working, contact your broadband/fibre provider.
