- Page 1 Battery Regulator QBR101 UIDE M210374en-A March 2003...
- Page 2 The contents are subject to change without prior notice. Please observe that this manual does not create any legally binding obligations for Vaisala towards the customer or end user. All legally binding commitments and agreements are included exclusively in the applicable supply contract or...
-
Page 3: Table Of Contents
Specifications ................. 15 Charge Voltage Adjustment ..........16 Temperature Compensation NTC ........17 List of Figures Figure 1 Functional Block Diagram of QBR101 ........8 Figure 2 Adjustment of Current Limit............13 Figure 3 Installation Hole Dimensions ............ 14 VAISALA_________________________________________________________________________ 1... - Page 4 Input Connector X1..............11 Table 3 Output Connector X2 ..............12 Table 4 Control Connector X3 ...............12 Table 5 QBR101 Electrical Performance Specifications .......15 Table 6 QBR101 Environmental Specifications........16 Table 7 QBR101 Mechanical Specifications .........16 Table 8 Voltage Selection Resistor Value vs. Charging voltage (typ.
-
Page 5: Chapter 1 General Information
- Chapter 2, Product Overview, introduces the QBR101 Battery Regulator features and advantages. - Chapter 3, Installation, provides you with information that is intended to help you install this product. - Chapter 4, Technical Data, provides the technical data of QBR101 Battery Regulator. Version Information Table 1... -
Page 6: Feedback
Note highlights important information on using the product. ESD Protection Electrostatic Discharge (ESD) can cause immediate or latent damage to electronic circuits. Vaisala products are adequately protected against ESD for their intended use. However, it is possible to damage the product by delivering electrostatic discharges when touching, removing, or inserting any objects inside the equipment housing. -
Page 7: Warranty
- Always hold the boards by the edges and avoid touching the component contacts. Warranty For certain products Vaisala normally gives a limited one year warranty. Please observe that any such warranty may not be valid in case of damage due to normal wear and tear, exceptional operating conditions, negligent handling or installation, or unauthorized modifications. - Page 8 User's Guide _______________________________________________________________________ This page intentionally left blank. 6 _____________________________________________________________________M210374en-A...
-
Page 9: Chapter 2 Product Overview
The input voltage for the QBR101 can be taken from a 15 V- 30 VDC source. This may be, for example, an off-line SMPS or a solar panel. -
Page 10: Figure 1 Functional Block Diagram Of Qbr101
In normal 12 V operation the input power (to X1/1 and 2) is taken from an off-line SMPS with a 15.5 to 16 V output voltage. Inside the QBR101 the input voltage is applied both to the Battery Charger and via the Voltage Drop Circuit to the output terminals DCout (X2/1) and DCout/Switch (X2/5). -
Page 11: Charger
Chapter 2 ___________________________________________________________ Product Overview Inside the QBR101 the Solar Panel inputs (X1/5 and 6) are applied only to the Battery Charger, i.e. they have no straight connection to the DCout terminals. This is because the 12 V solar panels may present output voltage levels as high as 28 V, not suitable for all equipment normally connected to the DCout terminals. - Page 12 DCout/Switch output. A deep-discharged battery condition will naturally override this condition and turn the output off. The QBR101 has a test terminal Vb Meas for the datalogger to measure the battery voltage. The output level of Vb Meas is between 0 and 2 V.
-
Page 13: Chapter 3 Installation
This chapter provides you with information that is intended to help you install this product. Connections The Battery Regulator QBR101 has three removable screw connectors. The connector X1 is for power input, X2 is for power output, and X3 is for various control functions. The connector signals are described in the tables below. -
Page 14: Table 3 Output Connector X2
User's Guide _______________________________________________________________________ Table 3 Output Connector X2 Pin No Terminal Name Notes Dcout Output terminal for straight DC-output. This output is always live, when DCin+ voltage is connected or when charge is left in the battery. Ground terminal for DCout and DCout/Switch outputs. -
Page 15: Jumpers And Leds
Jumpers for Charge Current Limit The battery charging current limit can be adjusted in 0.5 A steps with the three jumpers J1 - J3 on the QBR101's front panel. The adjustment is normally made according to the battery capacity. For example, a suitable charging limit for a 12 Ah lead-acid battery would be 1.0 to... -
Page 16: Mechanical Installation
Mechanical Installation The QBR101 can be installed to 35 mm DIN-rail using rail clip on the rear. Alternatively it can be mounted to a wall or equivalent surface with M3 screws on the bottom. The maximum allowable length of the screw threads is 6 mm. -
Page 17: Chapter 4 Technical Data
Chapter 4 _____________________________________________________________ Technical Data CHAPTER 4 TECHNICAL DATA This chapter provides the technical data of QBR101 Battery Regulator. Specifications Table 5 QBR101 Electrical Performance Specifications Property Description / Value Maximum input voltage (DCin, SOL1in, 30 VDC SOL2in) Maximum input current (DCin) -
Page 18: Charge Voltage Adjustment
Reverse voltage protection At DCin and SOLin inputs Ground connection Negative; all GND terminals joined together and to the enclosure Table 6 QBR101 Environmental Specifications Property Description / Value -40 … +60 °C Ambient operating temperature -55 … +70 °C Storage temperature... -
Page 19: Temperature Compensation Ntc
NTC resistor may be mounted straight to the X3 screw terminals as well. Recommended type for the NTC resistor is PHILIPS 2322 645 03103 (Vaisala code: 16253), with values 10 kohm at 25 °C, 5 %, 0.1 W. VAISALA________________________________________________________________________ 17...
