Summary of Contents for Vaisala FB15
- Page 1 Vaisala Balloon Launcher FB15 UIDE M210767EN-A March 2006...
- Page 2 The contents are subject to change without prior notice. Please observe that this manual does not create any legally binding obligations for Vaisala towards the customer or end user. All legally binding commitments and agreements are included exclusively in the applicable supply contract or...
-
Page 3: Table Of Contents
Product Related Safety Precautions ........7 Recycling .................. 7 Warranty..................7 CHAPTER 2 PRODUCT OVERVIEW.................. 9 Introduction to Vaisala Balloon Launcher FB15 ....9 CHAPTER 3 INSTALLATION.................... 11 Selecting the Launching Site ..........11 Assembling Balloon Launcher FB15........11 Packing the Launcher for Transportation......14 Upgrading FB15 for Vaisala Radiosonde RS92.... - Page 4 Launcher Setup - Top View ............17 List of Tables Table 1 Manual Revisions ...............6 Table 2 Related Manuals.................6 Table 3 FB15 Main Dimensions ............23 Table 4 Recommended Balloon Weight ..........23 Table 5 Contents of the Balloon Launcher FB15 and Accessory Kit ..24 4 ___________________________________________________________________ M210767EN-A...
-
Page 5: Chapter 1 General Information
- Chapter 4, Operation, contains information about operating this product. - Chapter 5, Troubleshooting, describes the troubleshooting procedure and contact information for technical support. - Chapter 6, Technical Data, provides the technical data of FB15. - Appendix A, provides safety instructions for radiosonde operators . VAISALA ________________________________________________________________________ 5... -
Page 6: Version Information
First version. Note the different manual code. Related Manuals Table 2 Related Manuals Manual Code Manual Name M210295EN Vaisala Radiosonde RS92-SGP User's Guide M210696EN Vaisala Radiosonde RS92-AM User's Guide M210299EN Vaisala Radiosonde RS92-KL, RS92-K, RS92-KLE, RS92-KE User's Guide General Safety Considerations... -
Page 7: Feedback
You can send comments to us by e-mail: manuals@vaisala.com Product Related Safety Precautions The Balloon Launcher FB15 delivered to you has been tested for safety and approved as shipped from the factory. Note the following precautions: CAUTION Do not modify the unit. - Page 8 User's Guide ______________________________________________________________________ This page intentionally left blank. 8 ___________________________________________________________________ M210767EN-A...
-
Page 9: Chapter 2 Product Overview
This chapter introduces Vaisala Balloon Launcher FB15. Introduction to Vaisala Balloon Launcher FB15 Vaisala Balloon Launcher FB15 is a manually operated set for launching radiosondes of type RS80, RS90 and RS92. Designed for one-man operations, the lightweight launcher is made of glass-fiber reinforced plastic. - Page 10 User's Guide ______________________________________________________________________ This page intentionally left blank. 10 __________________________________________________________________ M210767EN-A...
-
Page 11: Chapter 3 Installation
- In marine operation, install the launcher so that the balloon is launched on the lee side. Assembling Balloon Launcher FB15 To assemble the balloon launcher, do the following. For details, refer to Figure 1 on page 13. - Page 12 User's Guide ______________________________________________________________________ Fit the canvas bag inside the frame, see item G. Make sure that the bag opening aligns with the nozzle. Fold the edge of the canvas bag over the rim of the launcher frame module, see item H in Figure 1, and fasten down with a band, see item J.
-
Page 13: Figure 1 Balloon Launcher Fb15 Assembly
Chapter 3 _______________________________________________________________ Installation 0603-007 Figure 1 Balloon Launcher FB15 Assembly VAISALA _______________________________________________________________________ 13... -
Page 14: Packing The Launcher For Transportation
Therefore the launcher should be kept inside or disassembled when not in use. Upgrading FB15 for Vaisala Radiosonde RS92 To upgrade Balloon Launcher FB15 for RS92 radiosondes, do the following: Remove the old radiosonde holder. -
Page 15: Chapter 4 Operation
OPERATION This chapter contains information about operating this product. Overview of Operation After you have installed Balloon Launcher FB15, the operation of the launcher consists of the following steps: Aligning and securing the launcher. Setting up the radiosonde and launcher. -
Page 16: Aligning And Securing The Launcher
User's Guide ______________________________________________________________________ Aligning and Securing the Launcher To align and secure the balloon launcher: Turn the launcher so that the sonde holder is always on the lee side, refer to Figure 2 and Figure 3. Insert pegs through the holes in the legs to secure the launcher, see item A in Figure 2. -
Page 17: Figure 3 Launcher Setup - Top View
Chapter 4 ________________________________________________________________ Operation The following items refer to Figure 2 on page 16: Frame module pegs Strap Radiosonde holder Canvas Unwinder Nozzle Unwinder string 0603-011 Figure 3 Launcher Setup - Top View VAISALA _______________________________________________________________________ 17... -
Page 18: Setting Up The Radiosonde And Launcher
User's Guide ______________________________________________________________________ Setting Up the Radiosonde and Launcher To set up the radiosonde and launcher, do the following: Set the ready-to-launch radiosonde in the sonde holder, see item D in Figure 2. Note that the radiosonde is fixed by a spring. Remove any debris, snow or ice from inside the canvas bag. -
Page 19: Launching The Balloon
If the canvas bag is wet the balloon may cling to the walls of the bag. In that case release the balloon with the launching strap inside the bag. Once past the launcher trim, the balloon will pull the radiosonde from the holder and the sounding will start. VAISALA _______________________________________________________________________ 19... - Page 20 User's Guide ______________________________________________________________________ This page intentionally left blank. 20 __________________________________________________________________ M210767EN-A...
-
Page 21: Chapter 5 Troubleshooting
- When did it fail (date, immediately / after a while / periodically / randomly)? - What was done when the failure was noticed? Technical Support For technical questions, contact the Vaisala technical support: E-mail helpdesk@vaisala.com +358 9 8949 2790... - Page 22 If the product needs repair, please follow the instructions below to speed up the process and to avoid extra costs to you. Read the warranty information. Contact Vaisala technical support via e-mail or fax and request for RMA (Return Material Authorization) and shipping instructions.
-
Page 23: Chapter 6 Technical Data
Chapter 6 ____________________________________________________________ Technical Data CHAPTER 6 TECHNICAL DATA This chapter provides the technical data of FB15. Specifications Table 3 FB15 Main Dimensions Main Dimensions Assembled Width 1510 mm Height 1270 mm Max. internal diameter 1300 mm Disassembled for transportation 1370 x 1270 x 480 mm Weight (approx.) -
Page 24: Parts List
User's Guide ______________________________________________________________________ Parts List Table 5 Contents of the Balloon Launcher FB15 and Accessory Kit Item Quantity Part No. Module 12483 Launching module 12484 Strap with buckle (used for tying up the 12482 launcher packet) User's Guide Carrying bag (used for holding the accessory... -
Page 25: Safety Instructions For Balloon Operators
The balloon film is only 0.05 - 0.1 mm thick upon launch, a slightest scratch could cause premature or even immediate burst in the shed. VAISALA _______________________________________________________________________ 25... - Page 26 User's Guide ______________________________________________________________________ Keep the doors of the shed shut while inflating the balloon on a windy day. Despite this, ensure that the shed is properly ventilated. No outside person shall be allowed admittance to the shed while the hydrogen generator is in operation or balloon inflation is going on.
