Using Propoint; Tilt + Move Gestures Functions; Tilt + Center Button Gesture Functions; Tilt + Rear Button Gesture Functions - Swiftpoint PROPOINT Quick Start Manual

Using ProPoint

Hold the mouse with your thumb on the thumb grip & your
middle finger on the finger grip. Rest your index finger on the
front button.
To right-click, move your index

finger to the center button
To middle-click, move your index

finger to the rear button
Use your index finger to roll

the scroll wheel

Tilt + Move Gestures Functions

To perform tilt gestures:
Tilt the mouse to the right
to engage the tilt gestures
& move the mouse
sideways, backwards,
or forwards.
Move the mouse forwards & backwards to scroll up & down

Move the mouse left & right to pan sideways

Tilt gestures can be customized using the Swiftpoint Control
Panel.

Tilt + Center Button Gesture Functions

TILT Mouse
Previous
Application
Tilt + Center Button gesture functions can be customized &
reassigned using the Swiftpoint Control Panel.

Tilt + Rear Button Gesture Functions

TILT Mouse
Previous Browser
Tab
Tilt + Rear Button gesture functions can be customized &
reassigned using the Swiftpoint Control Panel.

Presentation Mode

Presentation mode operates with all presentation software and
any other application. To get started with Presentation Mode;
1.
Ensure the Swiftpoint Control Panel is installed & running.
2. Start the show & move the switch on the underside
of the mouse to PRESENT

Presentation Mode - Functions

Hold the mouse
in the palm
of your hand
& use your
thumb to operate.
Use the Swiftpoint Control Panel to customize your settings.
Functions available in Presentation Mode include;
Next Slide/Left Click

Previous Slide/Up

SpotPoint

Laser Pointer

Move the switch on the underside of the mouse to ON to
return your mouse to standard mouse functionality.
Specifications
Operating Systems
Windows 7, 8, 10 or higher

MacOS 10.4 or higher

Android 4.4 or higher

iOS 7 or higher, with compatible applications

Communications
USB Wireless (2.4GHz)

Bluetooth 4.0

Power
Li-Ion Battery 3.7V, 120mAh

Charging: USB Outlet, 5V

Install the SWIFTPOINT CONTROL PANEL at
www.swiftpoint.com/download-propoint-drivers
Quick Start Guide V03 En
Left click
(front)
Tilt
Zoom In
Zoom Out
© 2019 Swiftpoint Limited. All rights reserved
Right click
(center)
PRESS Center Button
Next
Application
PRESS Rear Button
Next Browser Tab
Mac - Next Window
Right Click

Application Switch

Move Cursor

Custom Command

, 130mA
Middle click
(rear)
