TSGR-21 GAS Release Panel User Manual
Vighnaharta Technologies Pvt. Ltd.
2nd Floor,Karanjkar Estate,
S.N.11/11,Nanded Gaon,
Pune-411041
Tel no.: +919011033259, Sales: +919011033260
Email: sales@vighnaharta.in | Website: http://www.vighnaharta.in
Prepared By: SSK
Doc No.: TSGR-21_UM_1_0
Approved By: JVG
Rev.No.: 1_0
Eff.Date.: 02.09.2020
T R U E S A F E G A S R E L E A S E P A N E L
Mfg. By:
Vighnaharta Technologies Pvt. Ltd.
2nd Floor,Karanjkar Estate,S.N.11/11,Nanded Gaon,Pune-411041
Contact no.: +919011033259 (Landline)
Email: sales@vighnaharta.in | Website: http://www.vighnaharta.in
Vighnaharta Technologies Pvt. Ltd.
T S G R - 2 1
U S E R M A N U A L
Sales: +919011033260
Page 1 of 43

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSGR-21 and is the answer not in the manual?

Questions and answers

Related Manuals for Vighnaharta TSGR-21

Summary of Contents for Vighnaharta TSGR-21

  • Page 1 TSGR-21 GAS Release Panel User Manual Vighnaharta Technologies Pvt. Ltd. 2nd Floor,Karanjkar Estate, S.N.11/11,Nanded Gaon, Pune-411041 Tel no.: +919011033259, Sales: +919011033260 Email: sales@vighnaharta.in | Website: http://www.vighnaharta.in Prepared By: SSK Doc No.: TSGR-21_UM_1_0 Approved By: JVG Rev.No.: 1_0 Eff.Date.: 02.09.2020 T R U E S A F E G A S R E L E A S E P A N E L...
  • Page 2 TSGR-21 GAS Release Panel User Manual Fire Alarm System Limitations An automatic fire alarm system—typically density levels are not created by developing made up of smoke detectors, heat detectors, fire at the location of detectors, the detectors manual pull stations,...
  • Page 3 TSGR-21 GAS Release Panel User Manual minimum, the requirements of NFPA 72 or representative. Maintenance should EN54 shall be followed. Environments with scheduled monthly or as required by National large amounts of dust, dirt or high air and/or local fire...

  • Page 4: Abbreviations

    RAC1: Main Cylinder Output RAC2: Standby Cylinder Output IDC: Initiating Device Circuit (for example, Smoke detector(Make - Vighnaharta, Apollo series 65, GST and Orbis are compatible with TSGR-21) / Heat detector / MCP) RAC: Releasing Appliance Circuit (for example, FM200) FM 200: Gas Extinguisher which removes the free radicals or heat element from the fire triangle.

  • Page 5: Table Of Contents

    TSGR-21 GAS Release Panel User Manual Table of Contents Abbreviations ..................................... 4 Product Description ............................. 7 1.1 Overview: ..................................7 1.2 System Features: ................................8 1.3 Technical Specifications ............................... 9 1.4 Controls and Indications ............................. 10 1.4.1 Controls ..............................10 1.4.2 LED Indications ............................
  • Page 6 TSGR-21 GAS Release Panel User Manual 4.1.5 key: ( Right Key) ..........................33 4.1.6 Reset Key: ..............................33 4.1.7 Enter Key ..............................33 4.1.8 Gas Inhibit:..............................33 4.2 Normal Mode Operation ............................. 33 4.2.1 Fire Condition ............................33 4.2.2 Fault Condition ............................34 4.2.3 Pre Release Condition ..........................

  • Page 7: Product Description

    1. Product Description 1.1 Overview: TSGR-21 is basically used for fire detection as well as suppression panel to suppress fire using gas release system. Main purpose of the system is to monitor fire and pressure switch of TSGR-21 gas release system and if fire is detected, panel will activate the solenoid valve to release the gas cylinder and display shows the fire zone.

  • Page 8: System Features

    TSGR-21 GAS Release Panel User Manual 1.2 System Features: • Operated on 24 V/3A DC power supply. • Battery low voltage 23 V DC and battery cut at 22 V. • Stand by battery backup of up to 24 hrs.

  • Page 9: Technical Specifications

    TSGR-21 GAS Release Panel User Manual • More than 200 records history events for fire alarm, fault condition, RAC release or abort condition, sequence of events. 1.3 Technical Specifications Power Supply 180 – 265V AC, 3A, 60/50 Hz. Input Initiating Device Circuit (IDC) •...

  • Page 10: Controls And Indications

    TSGR-21 GAS Release Panel User Manual Buzzer Indication Fire, Fault, Key press acknowledge Output Releasing Appliance Circuit (RAC1, RAC2) Voltage: 24 VDC, Current: 500mA each. Notification Appliance Circuit (NAC1, NAC2, NAC3) Voltage: 24 VDC, Current: 250mA each. PFC Relay outputs: 3...

  • Page 11: Led Indications

    TSGR-21 GAS Release Panel User Manual 1.4.2 LED Indications There are different LED indications given on front panel of gas release system provided to user to alert from different events occurred. Name of events along with colour of corresponding LED with description are as follows.

  • Page 12: Components

    1.5 Components PCB Board: Consists of CPU, keypad, Display, zones, inputs, and outputs. Power Supply: 24V, 3 A power supply with each TSGR-21 panel, mounted inside enclosure. Enclosure: Metallic enclosure with powder coating RAL 7035, size as mentioned in Technical Specifications.

  • Page 13: Installation

    TSGR-21 GAS Release Panel User Manual 2. Installation 2.1 Installation Precaution WARNING: Do not attempt to install, service, or operate this unit, until this manual is read and understood. Do not connect other equipment to this unit. CAUTION: This system works at 0° C to +50° C and at a relative humidity of 5 to 90 ±2% RH.

  • Page 14: Block Diagram Of Panel

    2.3 Block Diagram of Panel The following diagram shows basic components of TSGR-21 system. It consists of various smoke and heat detectors, AC power source, Notification devices like NAC or sounder, Fire Suppression and Releasing agent Gas based extinguishers, SCADA communication cables, all connected to control panel.

  • Page 15: Field Wiring Details

    TSGR-21 GAS Release Panel User Manual Use two 12V,7Ah sealed lead acid type Batteries. Observe polarity when connecting the battery. Connect the battery to the provided cable. The battery charger is current - limited and capable of recharging sealed lead acid type batteries up to 6Ah.
  • Page 16 TSGR-21 GAS Release Panel User Manual Pin No. Connection Description Name J11.1 NAC 1 + NAC1 Positive(+) J11.2 NAC 1 - Ground/NAC1 Negative(-) J11.3 NAC 2 + NAC2 Positive(+) J11.4 NAC 2 - Ground/NAC2 Negative(-) J11.5 NAC 3 + NAC3 Positive(+) J11.6...

  • Page 17: Initiating Device Circuit (Idc)

    TSGR-21 GAS Release Panel User Manual Pin No. Connection Description Name J4.14 Ground (Not used) J4.15 DI 3 Extra Digital Input 3 (Not used) J4.16 DI 4 Extra Digital Input 4 (Not used) Add-on Supply J15.1 Add-on DC supply Positive(+) (Not used) J15.2...

  • Page 18: Output Circuits

    TSGR-21 GAS Release Panel User Manual 2.3.4 Output Circuits The panel has three types of output circuits. • Notification Appliance Circuit (NAC) • Releasing Appliance Circuit (RAC) • Potential Free Contact Relay Outputs (PFC) • No. of NAC 3 circuits •...

  • Page 19: Release & Abort Controls

    2.4.1 Maintenance mode through Key Switch It is maintenance purpose mode. There is provision in TSGR-21 panel that user can select maintenance mode by using Key Switch. Remember without key you cannot change the mode. When panel is set as a Vighnaharta Technologies Pvt.

  • Page 20: Servicing

    In this way multiple sensors in a single loop can be tested. Note: Repeat Maintenance Mode after every 3 months. 2.4.2 Servicing Following are the servicing check list of TSGR-21 panel. Maintenance / servicing is required twice a year for each panel. Check point or maintenance point...

  • Page 21: Do's And Don'ts

    TSGR-21 GAS Release Panel User Manual Each week, choose different manual check points so that the manual check points in the building ▪ are tested in rotation over a prolonged period. Check all detectors and ensure that none are obstructed in any way. Enter results of tests into the ▪...

  • Page 22: Don'ts

    TSGR-21 GAS Release Panel User Manual Do you know the difference between the Trouble signal and the Supervisory signal in your Fire Alarm system? What’s the correct response to these different signals? What button should you press? It’s important that you find ways to learn how the system operates so that you are prepared to interact with the equipment in the case of an emergency.

  • Page 23: System Configuration

    To enter into Programming mode do following steps. 3.1 Programming menu: The gas release panel TSGR-21 is Programmable for gas release timer, PFC relays, input type etc. When entered into the menu first shows the screen “SYSTEM MENU”. Use Right key for next menu.
  • Page 24 TSGR-21 GAS Release Panel User Manual 5. Timer Setting 6. Factory Reset Note: keys to move the arrow cursor for the option. Use keys to show the next ❖ set of four menu options. Press ENTER key to select the pointed menu option to configure.
  • Page 25 TSGR-21 GAS Release Panel User Manual Vighnaharta Technologies Pvt. Ltd. Page 25 of 43...

  • Page 26: Press Enter To Default The Panel Settings

    TSGR-21 GAS Release Panel User Manual <SELECT MENU> Reset Factory Reset> Press Enter to Default the Panel settings <Factory Factory Default Reset> <Factory Press Enter to clear all events Clear all Events 3.2 Program Function: 3.2.1 System Config: From selecting this menu you can Enter Below Sub Menus 1) Set Date: By selecting this menu Set Date you can change Date With the help of left, right, up and down Keys.

  • Page 27: Input Config

    TSGR-21 GAS Release Panel User Manual 3.2.2 Input Config: From selecting this menu you can Enter Below Sub Menus 1) ZONE1 Config: By selecting this menu ZONE1 Config you can Enable or Disable (Bypass) the Zone1. By default Zone1 is Enable to change the state press Enter menu and the use left or right key. Press ENTER key to save the changes.

  • Page 28: Output Config

    TSGR-21 GAS Release Panel User Manual Set ActPres Swt1 NO Type 6) Set ActPress Swt2: By selecting this menu Set ActPress Swt2 switch type is selected which is going to connect with cylinder. By default it is NO type you can select NC type to change the state press Enter menu and the use left or right key.

  • Page 29: Event View

    TSGR-21 GAS Release Panel User Manual In this menu cylinder type specifies that main cylinder or standby cylinder. In Case of Main cylinder is goes for refilling you can switch over the system on standby cylinder and run the system. By Default it is Main. To change the state press Enter menu and the use left or right key.

  • Page 30: Timer Setting

    TSGR-21 GAS Release Panel User Manual Z1Open 01/50 DD/MM/YY HH:MM 3) RAC Rel/Abt Event: After entering in the RAC Rel/Abt Evet menu, It will show last RAC event. Use Left and right key to scroll event. LCD Display Shows as below.

  • Page 31: Factory Reset

    TSGR-21 GAS Release Panel User Manual 4) RAC Abort Tmr: After entering in the RAC abort Tmr menu, you can set RAC abort Tmr. by default it is 005 Sec. To change the state press Enter menu and the use up or down key. Make Sure that RAC Abort Tmr is less than Pre Release Tmr.

  • Page 32: System Operation

    TSGR-21 GAS Release Panel User Manual 4. System Operation The following diagram shows front panel of TSGR-21 model. 4.1 Function keys 4.1.1 MENU key Single press MENU key is generally available for any user. There are six options available under Menu key. Use left and right key to scroll between these menus and use ENTER key to go in to particular menu.

  • Page 33: Silence Key

    TSGR-21 GAS Release Panel User Manual 4.1.4 SILENCE key SILENCE key is used to silence the system, that is, whenever the NAC is ON, it can be turned OFF. By pressing again Silence key will resound all NAC’s. 4.1.5 key: ( Right Key) Right key is used to move cursor right.

  • Page 34: Fault Condition

    TSGR-21 GAS Release Panel User Manual • The zone fire status is visually indicated by respective zone fire LED. • Common Twin Fire LED turns ON. • If Pre Release is not running then Pre Release, RAC Released, Remote Release, RAC Abort LEDs are OFF.

  • Page 35: Pre Release Condition

    TSGR-21 GAS Release Panel User Manual Z1:Nrml Z2:Nrml Evt : PS1 Fault The System operation for the fault condition is given below. • LCD shows fault message along with time & date. Fault message and time and date are scroll simultaneously.

  • Page 36: Rac Released Condition

    TSGR-21 GAS Release Panel User Manual • NACs retain their status. • You can abort RAC within Pre release time. 4.2.4 RAC Released Condition This is the last status condition in system during fire alarm. The status is visibly indicated on LED and LCD. This condition occurs after Pre Release time is over.

  • Page 37: System Silence

    TSGR-21 GAS Release Panel User Manual • By Pressing RAC Abort RAC abort timer is activated. Screen shows RAC Abort Time : 005 Sec • Respective RAC Abort LED turns ON. • Respective Pre Release LED turns OFF. • Other LED retains their status.

  • Page 38: Zone Disable

    TSGR-21 GAS Release Panel User Manual • All relay outputs are deactivated. • System scans zone status and indicates accordingly. 4.3 Zone Disable When any zone is disable, system ignores any input from the particular zone, even if there is fire condition. In case of cross zoning, if one zone is disabled (bypassed) and other is in fire condition, system does not release RAC.

  • Page 39: Rac Operation

    TSGR-21 GAS Release Panel User Manual 4.5 RAC Operation 4.5.1 Auto Mode Operation By using Key Switch you can select Auto Mode .Remember without key you cannot change the mode. Whenever there is fire alarm condition in any zone, depending upon RAC configuration, pre release timer for the particular RAC starts automatically and system enters into pre release condition.

  • Page 40: Keypad Enable, Disable And Evacuate

    TSGR-21 GAS Release Panel User Manual • Release output of relay gets activated. • Other LED & NAC indications retain their status. • RAC Fault LED turns ON if RAC has been connected to gas extinguisher. 4.6 Keypad Enable, Disable and Evacuate This is basically a key switch operation by which you Enable disable keypad and Perform Evacuate Operation.

  • Page 41: Rac Release/Abort Events

    TSGR-21 GAS Release Panel User Manual Fire alarm history event view on scrolling using Right key. 4.8.2 RAC Release/Abort Events The system has capability to save 50 RAC events. All events are stored with time and date. User or Admin user cannot clear this event history.

  • Page 42: Sequence Of Events

    TSGR-21 GAS Release Panel User Manual 4.8.4 Sequence of Events The system has capability to save 75 sequence events. All events are stored with time and date othe than Fire Event, Fault Event, RAC Event. User cannot clear this event history. To view sequence events, press MENU key one time.
  • Page 43 TSGR-21 GAS Release Panel User Manual Vighnaharta Technologies Pvt. Ltd. Page 43 of 43...
