Freestanding Letter Box
Art.no 31-5038
Please read the entire instruction manual before using the product
and save it for future reference. We reserve the right for any
errors in text or images and any necessary changes made to
technical data. If you have any questions regarding technical
problems please contact our Customer Services.
Assembly
1. Open the door on the back of the letter box and remove
the screws and the shelf. The legs of the letter box will then
be revealed.
2. Lay the letter box on its side and undo the 4 bolts holding
the legs in place. Remove the legs and the baseplate.
3. The letter box can either be installed raised up off
the ground on the legs or at ground level.
GREAT BRITAIN • customer service tel: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Installation raised off the ground
1. Attach the four legs to the baseplate.
2. Dig a 30 cm deep hole in the ground where the letter box
is to be located.
3. Fill the hole in the ground with concrete.
4. Lay a couple of planks over the hole.
5. Straddle the baseplate over the planks so that 2/3 of the
legs stick down into the concrete.
6. Use a spirit level to check that the baseplate is level.
7. Leave the concrete to dry for 24 hours before removing
the planks.
8. Undo the 4 screws on the baseplate and place the letter
box onto it.
9. Screw the letter box onto the baseplate from the inside.
10. Refit the shelf with the bent edge facing up.
Installation directly on the ground
1. Attach the four legs to the baseplate.
2. Dig a 30 cm deep hole in the ground where the letter box
is to be located.
3. Bolt the legs onto a concrete slab.
4. Place the concrete slab and baseplate construction into
the hole and fill the hole with sand and soil.
5. Undo the 4 screws on the baseplate and place the letter
box onto it.
6. Screw the letter box onto the baseplate from the inside.
7. Refit the shelf with the bent edge facing up.
Disposal
This product should be disposed of in accordance with
local regulations. If you are unsure how to proceed,
contact your local authority.
Specifications
Size Letter box: 35 × 24 × 100 cm (w x d x h)
Mail slot: 28 × 6 cm
