Bio-logic
AuDX
®
®
QUICK START GUIDE
OAE screening

Advertisement

loading

Related Manuals for natus Bio-logic AuDX

Summary of Contents for natus Bio-logic AuDX

  • Page 1 Bio-logic AuDX ® ® QUICK START GUIDE OAE screening...

  • Page 2: Start Menu

    Bio-logic AuDX ® ® QUICK START GUIDE Turning On/Off, and charging the device On/off button on Power supply right side connector Start menu Battery status Select patient Current time Additional Turn off device information about options for current screen...
  • Page 3 Bio-logic AuDX ® ® QUICK START GUIDE Testing Connect the probe to the white connector. Select either DPOAE Quick: 3 out of 4 button or DPOAE Quick: 4 out of 4 button Select the appropriate ear tip size and place it on the probe tip. Insert the probe in the ear making sure that the ear tip fits tightly into the ear canal.
  • Page 4 Bio-logic AuDX ® ® QUICK START GUIDE The device will check if the probe fit is correct prior to measurement. If the probe fit is correct (indicated by a green light), the test will start automatically. Progress for each tested frequency Test progress Ear being tested Noisefloor level...
  • Page 5 Bio-logic AuDX ® ® QUICK START GUIDE Test results (bar graphs) Overall screening test result Green check marks indicate valid response. Red circles indicate no valid response Red (right ear) or blue (left ear) bars show response amplitude. Grey bars show noise amplitude Retest frequencies that did not pass...
  • Page 6 Bio-logic AuDX ® ® QUICK START GUIDE Test results (simple) If the required criteria were met, the result will be PASS. If not, it will be REFER. Test other ear Print results to a label or to a pdf file or full page report on PC.

  • Page 7: Copyright Notice

    Internet: www.pathme.de Healthcare solutions with one thing in mind. You. ©2020 Natus Medical Incorporated. All Rights Reserved. All product names appearing on this document are trademarks or registered trademarks owned, licensed to, promoted or distributed by Natus Medical Incorporated, its subsidiaries or affiliates. 7-26-1383-EN Rev01 Natus Medical Incorporated natus.com...
