Jefftron Leviathan Installation Manual

For gearbox v2
Hide thumbs

Advertisement

Quick Links

Download this manual
INSTALLATION MANUAL
FOR GEARBOX V2

Advertisement

loading
Need help?

Need help?

Do you have a question about the Leviathan and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jefftron Leviathan

Summary of Contents for Jefftron Leviathan

  • Page 1 INSTALLATION MANUAL FOR GEARBOX V2...

  • Page 2: Safety Warning

    Because the device drains small amount of current from it all the time. - Don‘t connect battery when gun pointing towards you, another person or an animal. - Don‘t modify, repair, put into any kind of liquids or thermal shock the Leviathan - V2. Package contents...
  • Page 3 3. Take out these parts out of the gear- 4. If your gearbox has high screw box (not used with Leviathan - V2). mounting, cut it off to flat surface. 5. Insert Leviathan-V2 in the place of the original trigger contacts. Check if it is laid flat on the gearbox shell and transparent foil covers socket contacts.
  • Page 4 9. Stick the foam to the right gearbox aren‘t any short circuits with gearbox. shell (included in the package). 10. Place wires from the Leviathan-V2 11. Wires under motor have to stick on in order: blue, -battery, -motor. the wall. Use super glue to fix position.
  • Page 5 14. Insert into the gearbox sector gear 15. Make sure the gear does not touch and trigger from Leviathan package. micro switch body. Spin the gear slowly (avoid micro switches break). to check right Cycle detection in the app 16. Put together the gearbox shell.
  • Page 6 Testing micro switches 1. Install „Leviathan by JeffTron“app from iOS store or Google play into your smartphone. https://www.jefftron.net/application You can also use link 2. Connect battery to Leviathan - V2 and pair smartphone with the password „1234“.
  • Page 7 3. Change password to your 4 digit. 5. Check if every micro switch respon- ding. Grey color is OFF, blue is ON. There is slight delay in change micro 4. Set 2x new password and push SAVE. switch status because of BT commu- Don‘t tell new password to anybody! nication.
  • Page 8 On pic. 8. is SAFE lector plate on red line. Otherwise add metal plate or different material on it. 10. If cycle is not detected move Leviathan-V2 slightly higher to be micro switch closer to sector gear. If trigger doesn‘t press micro switch move Leviathan-V2 front slightly lower.
  • Page 9 WARNING - Disconnect battery, when you don’t use the gun! Otherwise it will lead to destroy battery or its fire. Because Leviathan - V2 drains small amount of current from it all the time. - Change name visible on the Bluetooth list, max.
  • Page 10 Change parameters page 1/2 Orange stripe = not green stripe = paired paired, Paired = loads parameters from Leviathan - V2. Change parameter -> shows „writting...„ in the green stripe. Text dissapear -> parameter is saved Fire modes with Selector on safe/semi/auto: - SAFE: no responding on the trigger pull.

  • Page 11: Change Parameters

    Change parameters page 2/2 Active Brake: It uses the excess energy from the motor to stop it. Lower braking intensity spares the motor coils. Spring is fully released, parts in gearbox aren‘t under strain. Higher power braking is suitable for weapons with high RoF. The effect is the most powerful with torque motor.
  • Page 12 Error log: It shows errors made during the device life. Error at the top of list is the newest one. More info at page 12. Battery voltage: It shows actual value. Red color line indicates when gun won‘t shoot. In yellow it will shoot with war- ning vibration.
  • Page 13 Startup codes After connecting battery Leviathan - V2 does a power up self check, which lasts a 1s. It results the motor vibration or error beeps with the error log record: 1 short vibration - All systems are OK. This vibration is about half second long.

  • Page 14: Troubleshooting

    Troubleshooting ISSUE: Weapon doesn‘t react at all after battery connection. SOLUTION: Check if the battery is properly connected and charged. Also check motor contacts and motor functionality. Check if the safety fuse hasn’t been blown. ISSUE: Weapon doesn‘t make shots after trigger pull (start-up vibration was made). SOLUTION: Damaged or misplaced micro switch for trigger, check it‘s proper function.
  • Page 15 Check if the safety fuse hasn’t been blown. ISSUE: Leviathan - V2 is not visible in the device list in the application. SOLUTION: Click t orefresh button in the app. Check if it is charged and connected battery into the Leviathan-V2.
  • Page 16 MANUFACTURER Ing. Filip Němec Zahradní 599, 538 03 Heřmanův Městec ID: 87936062, TAX ID: CZ8503013475 Made in Czech Republic www.JeffTron.net VERSION 5.19 Warranty does not cover: water immersion, defects or damage from accident, misuse, opposite battery polarity, abuse, damaged wires, wrong installation, bad handling, any modification by user, unusual physical, electrical or electromechanical stress.

This manual is also suitable for:

Leviathan v2
