- Page 1 S-TEK...
- Page 2 Vertriebsgesellschaft mbH Switzerland Nova Antipolis Les Terriers Bremer Straße 4 Nord 90451 Nuremberg 175 Allée Belle Vue GERMANY 06600 Antibes - France For additional information about our distributors and dealers, see our website at: www.scubapro.com © 2008 by Johnson Outdoors Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT WARNINGS ..................4 General Warnings ...................4 Pre-Dive Warnings ....................5 Dive Warnings ....................6 EUROPEAN CERTIFICATION .................7 PRECAUTIONS ......................8 S-TEK COMPONENTS AND SPECIFICATIONS .............9 Primary Purpose of a Buoyancy Compensator ..........9 S-TEK PURE Harness - Stainless Steel Back Plate ..........9 S-TEK PURE Harness - Aluminium Back Plate ..........10 S-TEK PRO Harness - Stainless Steel Back Plate ..........11 S-TEK PRO Harness - Aluminium Back Plate ............. -
Page 4: Important Warnings
1. IMPORTANT WARNINGS 1.1 General Warnings WARNING This manual must be read and understood entirely before using the product. It is advised that you keep this manual in your possession during the entire life of your BC. FAILURE TO READ, UNDERSTAND, AND FOLLOW THE PRECAUTIONS LISTED IN THIS MANUAL COULD RESULT IN SERIOUS INJURY OR DEATH. -
Page 5: Pre-Dive Warnings
WARNING DO NOT DIVE with a BC that is damaged, leaks air or does not function properly. Terminate any dive as safely and quickly as possible if the BC becomes damaged, leaks gas or does not function properly. WARNING Special instruction in cold water diving practices and the specific use of this product in cold water is required prior to cold water diving (temperatures below 10°C/50°F). - Page 6 WARNING Keep sand and other contamination out of the mouthpiece of the TEK BPI. Under certain conditions, contamination can cause the valve not to close completely. If this occurs while diving, shake the TEK BPI while depressing the deflate button several times. If the valve leaks or remains inoperable, terminate the dive.
-
Page 7: European Certification
The CE and EN1809 marks on the product denote the conformity to said requirements. The Manufacturer of SCUBAPRO BCs is: SCUBAPRO EUROPE Via Tangoni 16 16030 Casarza Ligure (GE) Italy, or SCUBAPRO GERMANY & E. Europe Johnson Outdoors Vertriebsgesellschaft mbH Bremer Straße 4 90451 Nuremberg GERMANY... -
Page 8: Precautions
3. PRECAUTIONS For your protection while using SCUBAPRO life support equipment, we call your attention to the following: • Use the equipment according to the instructions contained in this manual and only after having completely read and understood all instructions and warnings. •... -
Page 9: S-Tek Components And Specifications
4. S-TEK - COMPONENTS AND SPECIFICATIONS Primary purpose of the Buoyancy Compensator The primary purpose of a Buoyancy Compensator is to make you more comfortable by enabling you to maintain neutral buoyancy at depth. You are neutrally buoyant when you maintain a specific depth without expending significant physical effort to prevent an ascent or descent from that depth. -
Page 10: S-Tek Pure Harness - Aluminium Back Plate
S-TEK PURE Harness with Aluminium Back Plate The S-TEK PURE Harness incorporates the D.I.R. (Doing It Right) style of continuous webbing and includes the following: • 2 x Pre-bent Shoulder Stainless Steel D-rings. • 1 x Waist Stainless Steel D-ring on the left side. -
Page 11: S-Tek Pro Harness - Stainless Steel Back Plate
S-TEK PRO Harness with Stainless Steel Back Plate The S-TEK PRO Harness is supplied with adjustable Tek-Loc Shoulder buckles making doffing and donning a breeze and includes the following: • 2 x Pre-bent Shoulder Stainless Steel D-rings. • 2 x Waist Stainless Steel D-rings. •... -
Page 12: S-Tek Pro Harness - Aluminium Back Plate
4 .5 S-TEK PRO Harness with Aluminium Back Plate The S-TEK PRO Harness is supplied with adjustable Tek-Loc Shoulder buckles making doffing and donning a breeze and includes the following: • 2 x Pre-bent Shoulder Stainless Steel D-rings. • 2 x Waist Stainless Steel D-rings. •... -
Page 13: Tek Bpi - K-Style Balanced Power Inflator/Deflator Unit
4.6 TEK BPI – K-Style Balanced Power Inflator/Deflator Unit and Elliptical Corrugated Hose All S-TEK Donut Wings are supplied with the TEK BPI – a K-Style Balanced Power Inflator/Deflator unit which is CE compliant. This style is preferred by Tech Divers worldwide. The primary benefit of a Balanced Power Inflator is exceptional, consistent, flow rate, irrespective of depth and tank pressure, which makes... -
Page 14: S-Tek Donut 30 Wing
S-TEK Donut 30 Wing The S-TEK Donut 30 Wing is ideal for single tank use and incorporates the following features: • 1000 Denier Air Textured Outer Bag with industry leading abrasion resistance and Eco- friendly Dope-Dyed fabric. • 500 Denier Air Textured Inner Bag. •... -
Page 15: S-Tek Donut 60 Wing
S-TEK Donut 60 Wing The S-TEK Donut 60 Wing is designed exclusively for Twin Tank use and offers the following features: • 1000 Denier Air Textured Outer Bag with industry leading abrasion resistance and Eco- friendly Dope-Dyed fabric. • 500 Denier Air Textured Inner Bag. •... -
Page 16: Single Tank Adaptor
4.10 S-TEK Single Tank Adapter (S.T.A) The S-TEK Single Tank Adapter makes attaching a single cylinder a cinch! The S.T.A. offers the following features: • Marine Grade 5182 Anodized Aluminium plate. • Single cinch band for easier attachment and better vertical adjustability. •... -
Page 17: S-Tek Set Up And Adjustments
5. S-TEK - SETUP AND ADJUSTMENTS S-TEK PURE Harness (Stainless or Aluminium) Setup The S-TEK PURE Harness offers two separate modes of use: Extender Mode on Shoulder Straps to provide easier doffing and donning (All • S-TEK PURE Harnesses are shipped in this mode). Fixed Mode on Shoulder Straps provides the most simple, secure attachment for •... - Page 18 Fixed Mode Although the S-TEK PURE Harness is shipped in Extender Mode, a spare Tri-Glide is included, should you want to convert your harness to the Fixed Mode. In this mode, the Tri-Glide already supplied in Extender Mode on the right Waist Strap needs to be moved to the traditional position at the back of the back plate.
- Page 19 5.1.2 Shoulder Strap and D-Ring Location While standing, don your harness. Lift your elbows ensuring your arms are parallel to the ground and point your thumb toward the shoulder strap (fig. 3) to get an indication of the correct D-ring placement. This placement is important for having easy access to items clipped onto the D-rings, including Stage...
-
Page 20: S-Tek Pro Harness (Stainless Or Aluminium) Setup
S-TEK PRO Harness (Stainless or Aluminium) Setup 5.2.1 Shoulder Strap and D-Ring Location While standing, don your harness. Lift your elbows ensuring your arms are parallel to the ground and point your thumb toward the shoulder strap (fig.5) to get an indication of the correct D-ring placement. - Page 21 5.2.2 Waist D-Ring’s Position The S-TEK PRO Harness is supplied with 2 x Waist D-rings, one on each hip. As a general rule, both D-rings should be located in line with an outer leg trouser seam (fig. 6). These D-rings are normally used for clipping off your SPG, Stage Cylinders and any other accessories.
-
Page 22: Front Buckle Location And Trimming Excess Webbing (Pure And Pro)
Front Buckle Location and Trimming Excess Webbing (PURE and PRO Harnesses) The placement of the Stainless Steel Waist buckle does depend on diver configuration but generally should be off-set slightly to the right (fig. 7), so it is unhindered by the crotch strap which is centrally aligned with your navel but still allows easy reach to release the buckle. -
Page 23: Rear Crotch D-Ring Position (Pure And Pro)
Rear Crotch D-ring Position (PURE and PRO Harnesses) The Rear Crotch D-ring is used for clipping off gear such as Reels, Delayed Surface Marker Buoys (DSMB) or Lift Bags – items that are not used often. As a general rule the D-ring should be about a hand width below the botton end of the back plate (fig. -
Page 24: S-Tek Cylinder Attachment Systems
6. S-TEK - ATTACHING CYLINDER SYSTEMS 6.1 S-TEK Ergo Nuts (fig. 10) fig. 10 All S-TEK PRO and PURE Harnesses are supplied with 2 x Ergo Nuts. The Ergo Nuts provide the following benefits: • Suit friendly - prevent abrasion. • Flush-mounted and ergonomically designed to allow easier tightening and loosening of cylinder systems, especially with cold, wet hands or... -
Page 25: Single Tank Adapter
S-TEK Single Tank Adapter (S.T.A.) for both PURE and PRO Harnesses For this procedure you will require the following three S-TEK components (fig. 11): • S-TEK PURE or PRO Harness (Stainless Steel or Aluminium) with included Ergo Nuts (x2) • S-TEK Wing (normally an S-TEK 30 Wing or 40 Wing for use with an S.T.A.) •... - Page 26 Step 5 Place your PURE or PRO harness face-down while aligning the top webbing mounting eyelet (PURE Harness) with the mounting hole of the back plate (fig. 11-7). The PRO Harness has no top webbing mounting eyelet. Step 6 Place your S-TEK wing face-down on a flat surface while aligning the two fig.
-
Page 27: Twin Tank Kit
S-TEK Twin Tank Kit for both PURE and PRO Harnesses For this procedure you will require the following three S-TEK components (fig.12): • S-TEK PURE or PRO Harness (Stainless Steel or Aluminium) with included Ergo Nuts (x2) • S-TEK Wing (normally an S-TEK 40 Wing or 60 Wing for use with a Twin Tank Kit) •... - Page 28 Step 1 Remove the 2 x Ergo Nuts from the back plate (fig.12-5) and discard the triangular cardboard tabs (fig.12-6) Step 2 fig. 12-5 fig. 12-6 Using a small flat screwdriver, lever the retaining tabs (fig.12-7) on both Ergo Nuts to remove the covers (fig. 12-8).
- Page 29 Step 4 Place the wingnuts from the Twin Tank Kit into the disassembled Ergo Nuts (fig.12-12), replace the snap-on covers onto the Ergo Nuts and engage the tabs to ensure they are secure. Tighten firmly onto the protruding mounting bolts (fig.12-13). Your Twin Tank Kit is now installed! (fig.12-14) fig.
-
Page 30: Bc Examination And Procedures
7. BC EXAMINATION AND PROCEDURES Pre-dive, dive and post dive BC examination helps to identify equipment problems before unsafe conditions exist, helping to prevent diving accidents. All equipment must be regularly inspected by an authorized SCUBAPRO equipment repair facility to maintain its safe operation. -
Page 31: Operation
8. OPERATION SCUBAPRO S-Tek BC’s are supplied with the TEK BPI (K-Styled Inflator/Deflator Unit). The TEK BPI, when connected to the tank and regulator by a Low Pressure hose, makes it possible to control buoyancy in the water (inflation and deflation of the BC) by using the inflate and deflate buttons. -
Page 32: Power Inflating The Bc With The Inflate Button
3. Release the collar when the coupling is fully sealed on the inlet fitting of the TEK BPI. Pull gently but firmly on the hose to check for a secure connection (fig. 14-3). 4. To disconnect, pull the Quick Disconnect Coupling collar back and disengage the LP Hose from the inlet fitting. -
Page 33: Orally Inflating The Bc With The Deflate Button
8.3 Orally Inflating the BC with the Deflate Button The Oral opening is found at the open end or mouthpiece of the TEK BPI (fig. 16). It allows you to inflate your BC with your exhaled breath while depressing the DEFLATE button. Use of this method for inflation is recommended on the surface or on land prior to diving. -
Page 34: Deflating The Bc With The Deflate Button
8.4 Deflating the BC with the Deflate Button Assume a head-up position in the water. Raise the TEK BPI unit above and in front of your face (this ensures the unit will be postioned above the aircell of the BC). Depress the Deflate button and visually confirm that gas is escaping from the unit. For best control, let gas out in a series of short, measured amounts, while observing the effects on your buoyancy. -
Page 35: Post Dive
POST DIVE Cleaning, Inspection, Transport and Storage Correct servicing and maintenance guarantees you many years of reliable function of your SCUBAPRO® S-TEK BC. Keep the following instructions for care: • Fill the wing with fresh water (preferably luke warm) and shake so the water rinses the entire internal aircell. -
Page 36: General Specifications And Warranty
10. GENERAL SPECIFICATIONS AND WARRANTY Shelf life is seven years for a new, unused BC when deflated and stored in a sealed container or bag at typical room temperature, with no exposure to UV. Operating temperature range -20°C / -4°F +50°C / 122°F Water -2°C / 28°F... - Page 37 Note...
- Page 40 Manual and Declarations of Conformity on: Benutzerhandbuch und Konformitätserklärung auf: Manuel et déclarations de conformité sur : Manuale e Dichiarazioni di Conformità su: Manual y declaraciones de conformidad en: Handleiding en Conformiteitsverklaringen op: O Manual e as Declarações de Conformidade estão disponíveis em: Руководство...
