- Page 1 WÜDOMO DIMMABLE LIGHT MODULE Art. 0978 950 006 Quick installation guide...
-
Page 2: Technical Data Sheet
INTRODUCTION Compact slave module with DIN rail installation that lets you dim the lights in your home, as well manage their switching on/off. Digital inputs The module has 6 digital inputs that allow the acquisition and transmission, via BUS, of digital ON/OFF signals (dry contacts, buttons, switches). - Page 3 TECHNICAL NOTES • Installation and maintenance must be performed only by qualified personnel. • Disconnect the power supply before any maintenance operation and before accessing the internal parts of the unit. • Check the consumption of the loads driven by the outputs. •...
-
Page 4: Terminal Details
IN-OUT TERMINAL DETAILS The green 8-pole terminal is reserved for connecting the inputs. The black terminal is dedicated to the BUS connection. Next to this connector there is the selector for automatic/manual operation. The PI button is located under the front glass, while the LED indicators are next to it. - Page 5 CONFIGURATION The module can be configured for manual/automatic operation by lifting the front glass of the module (see figure below). AUTOMATIC: In this mode, control takes place exclusively via an advanced home automation system and not via a smart wifi programmable thermostat; in this mode the module must be addressed by means of the PI button, accessible on the front side of the module by lifting the front glass;...
-
Page 6: Wiring Diagram
MANUAL WIRING DIAGRAM An example of single module manual connection is shown in the figure. In manual mode, the buttons connected to inputs 1, 2, 3 and 4 can control outputs 1, 2, 3 and 4 (light line) in dimmer mode. While the buttons connected to 5 and 6 allow you to activate the scenarios all on and all off. - Page 7 The figure shows an example of manual connection of several modules in the same system. In this mode, the scenarios can be controlled not only by the individual modules but also by the Wüdomo programmable thermostat and the app.
- Page 8 AUTOMATIC WIRING DIAGRAM An example of module in automatic mode connection is shown in the figure. In this mode the control of the outputs and the management of the inputs is delegated to the home automation programming. Home automation...
-
Page 9: Normal Operation
INDICATOR To reduce consumption during normal operation, the LEDs are off. In case of anomalies or pressing the PI, the indicators are activated for 5 minutes. In the front part a multicolour LED (SL) is installed to indicate the various status listed below. NORMAL OPERATION BOOT PHASE START UP During normal operation the device... - Page 10 This product falls within the scope of Directive 2012/19/EU concerning the management of waste electrical and electronic equipment (WEEE). The device must not be disposed of with domestic waste as it is made up of different materials that can be recycled at appropriate facilities.
- Page 11 Notes...
- Page 12 WÜDOMO DIMMABLE LIGHT MODULE We reserve the right to modify the products at any time and without notice if the modifications result in a quality improvement.The images and Würth Srl, photos shown are purely indicative and may via Stazione, 51 not exactly represent the product described.
