ERROR
ERROR 24. MIC KEY STUCK.
ERROR 25. SW VER ERROR
ERROR 26 - 34. Processor Fault.
ERROR 35. Processor Fault.
ERROR 36. Processor Fault.
ERROR 38. Invalid Configuration.
ERROR 39. High Temperature.
ERROR 40. Processor Fault.
ERROR 41. Processor Fault.
ERROR 42. Processor Fault.
Heading flag indicator (FLG) appears in
weather screens.
WX-950
Installation Manual
Table 4-1. Error Messages (Continued)
PROBABLE CAUSE
Mic key (inhibit line) has been
asserted for at least 60 seconds.
Incompatible software versions
Main processor
Main or DSP processor
Main or DSP processor
The system configuration is set up
for synchro and stepper heading
signals instead of synchro or
stepper.
Processor temperature is outside of
specifications (i.e., >80°C for
approximately five minutes).
Main processor
Main or DSP processor
Main processor
Heading Flag
CORRECTIVE ACTION
Weather mapping is inhibited.
a. Press any key to continue.
b. Check inhibit line wiring.
c. If inhibit line not used, leave it
unconnected.
d. Check power to comms radio; if
off, the radio may be asserting the
inhibit line.
e. Contact Customer Service.
Continued operation is not possible.
Contact Customer Service.
Continued operation is not possible.
Contact Customer Service.
Weather mapping is inhibited.
a. Press any key to continue.
b. Contact Customer Service.
Weather mapping is inhibited.
a. Press any key to continue.
b. Contact Customer Service.
Stepper & XYZ Selected.
Heading Stabilization is not available.
a. Press any key to continue.
b. Check jumper selections in mating
connector assembly (refer to
paragraph 2.8, table 2-6). Make
sure only one heading type is
selected (jumper open).
c. Contact Customer Service.
a. Press any key to continue.
b. Make sure WX-950 internal fan is
operating.
c. Check for adequate ventilation.
d. Perform user initiated self-test
from Menu to determine if
condition still present. May occur
briefly under very hot conditions.
e. Contact Customer Service.
Press any key to continue.
Contact Customer Service.
Continued operation is not possible.
Contact Customer Service.
Continued operation is not possible.
Contact Customer Service.
a. It is normal for the heading flag
indicator to be present if the
heading flag line is asserted
b. The heading flag indicator will also
be present if a heading related
fault is present (Error 22,23).
