Summary of Contents for Citiwell OR9000
- Page 1 OR6000 Series 6” Reflector Telescope (Model 9000) Instructions Owner’s Manual Made in China Manual Part # 262481 Revised September 2003...
- Page 2 Parts of your new telescope: NEVER aim your telescope at the sun or even close to the sun! Instant and irreversible damage can occur, Do not let children use any telescope without adult supervision. NOTE: Actual parts and components may vary slightly in style or color from CHOKING HAZARD Small parts.
- Page 3 Introduction Congratulations on your purchase of a new OR9000 telescope. With proper care and handling of your telescope, you will enjoy the pleasure of looking at nature’s wondrous sights through the eye of this instrument for many years. Your telescope has been designed to provide views of the moon’s craters, Jupiter’s major moons, and Saturn’s rings, in addition to dozens of galaxies, star clusters, and...
- Page 4 Keep your box for storage or in case you ever need to ship your telescope. 2) Extend the tripod legs, and lock each one at the desired height with the tripod leg adjustment knobs.
- Page 5 (Fig. 6) (Fig. 7) 7) The counterweight balances your telescope and makes it easy to adjust and position. Hold the counterweight in your hand so you can see through the hole in the weight. Make sure that the black tightening knob on the counterweight is facing down.
- Page 6 10) Remove the finder scope (with attached bracket) from the box. Slide the finder scope bracket into the finder scope base on the telescope. (See Fig. 15) Apply a gentle pressure until the finder scope bracket is firmly secured to the mount. (See Fig.
- Page 7 In viewing situations where very high magnifying powers are desired, insert the 2X Barlow lens between the eyepiece and the focusing tube. (See Fig. 18) 13) The equatorial motor supplied with the OR9000 is designed to provide accurate tracking of celestial objects, reducing the need for making constant manual readjustments in order to follow and keep a subject in view.
- Page 8 ‘ON’, move the lever to the ‘engaged’ position (See Fig. 22) to connect the motor to the RA axis of the telescope’s equatorial mount and begin motorized tracking. Move the lever to the ‘disengaged’ position (See Fig. 23) to disconnect the motor and stop motorized tracking.
-
Page 9: Finder Scope Alignment
FINDER SCOPE ALIGNMENT Since a telescope has a narrow field of view by design, it can be challenging to locate a particular star or planet. For this reason the telescope is fitted with a low-power, wide- field miniature telescope called a finder scope. Always use your finder scope to locate the object you want to view FIRST. -
Page 10: About Magnification
North Star. Loosen the altitude adjustment and suppot knobs (See Fig. 27) and raise or lower the angle of the telescope until you can see Polaris centered in the finder scope. Be certain that your finder scope is properly aligned. -
Page 11: Using Your Telescope
10 mm of objective lens diameter. Magnification of around 450X or less is ideal for a telescope with a 152-mm diameter objective lens and is best for observing most celestial objects. A lower magnification power and a wider field of view are advisable for observing galaxies and nebulae. - Page 12 CARE AND CLEANING OF OPTICS Optical components of a telescope get dirty over time. Dirt or dust on a lens should be removed with the utmost care. A considerable amount of dirt or dust would have to accumulate on the optical surface before your view would be compromised.
- Page 13 If, after several attempts, you cannot remove the particles, take the telescope to an optical professional for cleaning. If you keep the dust caps on your telescope when it is not in use and avoid handling the lenses or mirrors, only minimal optical maintenance of your telescope should be required.
-
Page 14: Frequently Asked Questions
The planet and its rings appear pale yellow. The major division in the rings, the Cassini division, is possible to see if you keep the telescope firmly in position. Uranus and Neptune are the last of the solar system’s gas giants. They do not provide as spectacular a sight as Jupiter or Saturn, but are nonetheless rewarding to see. - Page 15 4) As I look through my telescope, objects in the sky appear to move. Why is that? When you observe an astronomical subject through a telescope, the constant rotation of the Earth makes things appear as though they are moving across the viewing area. The...
- Page 16 Please Read this Important The aiming point of your new telescope can be either MANUALLY controlled or ELECTRONICALLY controlled. This function is controlled by a small switch located on the equatorial motor. (See page 8 in your instruction manual). To turn on the MANUAL control function, set the small slide switch to the “ON”...
