STA-RITE Calypso Owner's Manual
  1. Manuals
  2. Brands
  3. STA-RITE Manuals
  4. Lighting Equipment
  5. Calypso
  6. Owner's manual
STA-RITE Calypso Owner's Manual

STA-RITE Calypso Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Calypso
Pool Cleaner
TM
O
W
N
E
R '
S
M
A
N
U
A
L
INSTALLATION, OPERATION & PARTS
MODEL GW7000
Sta-Rite Pool/Spa Group
293 Wright Street, Delavan, WI 53115
International: 262-728-5551, FAX: 262-728-7550
www.starite.com
Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA
S384 (Rev. 1/21/05)
© 2005, Sta-Rite Industries
Printed in U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Calypso and is the answer not in the manual?

Questions and answers

Related Manuals for STA-RITE Calypso

Summary of Contents for STA-RITE Calypso

  • Page 1 INSTALLATION, OPERATION & PARTS MODEL GW7000 Sta-Rite Pool/Spa Group 293 Wright Street, Delavan, WI 53115 International: 262-728-5551, FAX: 262-728-7550 www.starite.com Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA S384 (Rev. 1/21/05) © 2005, Sta-Rite Industries Printed in U.S.A.

  • Page 2: Table Of Contents

    2. Identify the filter valves that control water flow through the intakes in your pool. When you install the Calypso Hose can trip or entangle swimmers. Do not you will adjust the valves (if your system has valves) of allow swimmers in pool while cleaner is operating.

  • Page 3: Unpack And Assemble Your Calypso

    1. Open the box and make sure that you have the follow- on the Pipe and Nut Assembly as shown in Figure 2B. ing items. Note that the Calypso’s unique bumper and When the Pipe and Nut Assembly is installed, the bumper roller assembly may have been attached prior to ship- and roller won’t swing loosely from the cleaner.

  • Page 4: Install Your Calypso

    For best results and to retain your warranty, use only gen- uine Calypso hoses. Join the Calypso hose sections one to another by fitting the male end to the female end of the added section (see Figure 3). Make sure the connections are snug. The num- ber of lengths that you will need depends on the size of your pool.
  • Page 5 (Figure 10). base of the sliding cylinder aligns with or moves into Stop the pool filtration pump. Place the Calypso in the the yellow area. If the yellow band is completely cov- pool and allow it to sink to the bottom, pulling the at- ered, you may have excessive suction.
  • Page 6 Dedicated Vacuum Port: Locate the valve cover that you NOTE: When attaching the hose to a skimmer, do not at- set aside earlier and attach it to the male end of the regula- tach the valve cover which you set aside earlier. Instead at- tor valve (Figure 11A).

  • Page 7: Optimizing Performance

    Step 1: Check the Hose Length; Remove any Loops. Using a pool brush and pole, gently pull the Calypso to the area of the pool furthest from the vacuum connection. Make sure that any loops in the hose are pulled out.

  • Page 8: Maintenance

    The water flow from the return lines can push the to the top, before turning towards the floor again. In Calypso’s hose and cause it to turn away from an area in some cases, the cleaner will lose its grip on the wall the pool.

  • Page 9: Troubleshooting

    In fact, to ensure a random pattern of travel that will enable the Calypso to reach all areas of your pool, it is better to use less suction, not more.
  • Page 10 • S and check that the flapper valve is 5. If the Calypso is being trapped in a corner or near the TOP THE PUMP not worn or damaged. steps: • S and check that the foot-pad is not • Make sure that the bumper and roller are properly TOP THE PUMP worn through.

  • Page 11: Parts And Disassembly

    PARTS AND DISASSEMBLY Figure 19B - Pipe and Nut Assembly, Part No. 41101-0126. Figure 19A - Loosen nut to remove the Connecting Tube. Figure 20B - Detach the Flapper Valve by Figure 20A - Unclip the Flapper Valve sliding out the retaining ends. and Lid/Float from the steel pin.
  • Page 12 PARTS AND DISASSEMBLY Figure 21A - Pull to remove the Bumper and Roller assembly. Figure 21B - Bumper and Roller Assembly, Part No. 41101-0127. Figure 22C - Vacuum Seal, Figure 22A - Pull the Vacuum Seal out of Figure 22B - Detach Foot Pad. Part No.
  • Page 13 PARTS Figure 24A - 11 M/F Sectional Hoses, Part No. 41101-0123 (sold as set of 25 only, Part No. GW7007). Accessory Kit , Part No. 77705-0450; Includes: Figure 24C - Regulator Valve Cover, Part Figure 24D - Connector with 2 Male Figure 24B - Regulator Valve, No.
  • Page 14 Ladder Deflector Clips on to Pipe and Nut Assembly 4334 0203 Repair Parts List Part Part Description Qty. Number Lid and Float 41101-0128S Flapper Valve 41101-0102S Foot Pad 41101-0101S Vacuum Seal 41101-0122S Main Housing 41101-0125S Bumper and Roller Assembly 41101-0127S Pipe and Nut Assembly 41101-0126S Accessory Kit (Includes Key Nos.

  • Page 15: Warranty

    The foregoing warranties relate to the original consumer pur- NESS FOR A PARTICULAR PURPOSE, SHALL NOT EXTEND chaser (“Purchaser”) only. Sta-Rite shall have the option to re- BEYOND THE DURATION OF THE APPLICABLE EXPRESS pair or replace the defective product, at its sole discretion.
