Summary of Contents for Kikusui PLZ-5W SR Series
-
Page 1: Table Of Contents
Product Overview 3 Large-Capacity DC Electronic Load Checking the Package Contents 3 Smart Rack System Component Names 5 PLZ-5W SR Series Preparation 7 Connecting the Power Cord 7 PLZ6005W SR Checking Whether the Power Is On or Off 8 Operating the Load Input Terminal Cover 10... - Page 2 PDF and HTML files are included in the accompanying CD- ROM. You can view the PDF files using Adobe Reader. Microsoft Internet Explorer is required to view the HTML files. KIKUSUI ELECTRONICS CORP. 1-1-3 Higashiyamata, Tsuzuki-ku, Yokohama, 224-0023, Japan Phone:...
-
Page 3: Product Overview
Windows Explorer and then double-click index.html to [M5-100-009] display the start window. The CD-ROM contains the following items. [M1-100-131] • PLZ-5W SR Series Setup Guide (PDF) M12 × 80 • PLZ-5W SR Series Specifications (PDF) [M4-100-009] [M5-101-009] • PLZ-5W Series User’s Manual (PDF) - Page 4 Release Lock Caster lock Caster lock Stopper bolt’s bottom nut (M12) • Turn the nut clockwise to lower the stopper (lock). • Turn the nut counterclockwise to raise the stopper (unlock). PLZ-5W SR Series Setup Guide...
-
Page 5: Component Names
Press the side to switch the power on, and the side to switch the power off. Model Indicates the model. – Casters Four locations on the bottom side. – Caster locks Lock casters. Stopper bolt For fixing bottom panel. PLZ-5W SR Series Setup Guide... - Page 6 USB port Remote control connector. For details on remote control, see the Communication LAN port Interface Manual on the included CD-ROM. Interface RS232C port Manual SENSING connector Remote sensing connector. p.16 AC INPUT connector Power inlet. PLZ-5W SR Series Setup Guide...
-
Page 7: Preparation
If the supplied power cord cannot be used because the rated voltage or the plug shape is incompatible, have a qualified engineer replace it with an appropriate power cord that is 3 m or less in length. If obtaining a power cord is difficult, contact your Kikusui agent or dis- tributor. -
Page 8: Checking Whether The Power Is On Or Off
If you turn the power on, the PLZ-5W SR starts in the same state as it was in the last time that it was turned off. (However, the load setting is always Load Off.) The panel setting state at startup can be changed. For details, see the PLZ-5W Series User’s Manual. PLZ-5W SR Series Setup Guide... - Page 9 When the product does not start properly If the product does not start when the power is turned on, follow the appropriate remedy shown below. If following the remedy does not solve your problem, contact your Kikusui agent or distributor.
-
Page 10: Operating The Load Input Terminal Cover
Opening the load input terminal cover Turn the POWER switch off ( ). Loosen the screws holding the load input terminal cover on the rear panel. Load input terminal cover Screw Open the load input terminal cover. PLZ-5W SR Series Setup Guide... - Page 11 Closing the load input terminal cover Close the load input terminal cover. Tighten the screws holding the load input terminal cover on the rear panel. Fasten the covers correctly to prevent them from moving. Load input terminal cover Screw PLZ-5W SR Series Setup Guide...
- Page 12 Move the lock plate to adjust the position. Example: When four flexible conductors and sensing cables are used Removed lock plates can be stored by attaching them to the side of the load input terminal cover. PLZ-5W SR Series Setup Guide...
-
Page 13: Connecting The Eut
• Risk of electric shock. Use load cables with a voltage rating that meets or exceeds the product’s isolation voltage (±500 Vdc). • Use load cables with a core diameter that is appropriate for the amount of current being CAUTION used and with sturdy, flame-resistant insulation. PLZ-5W SR Series Setup Guide... - Page 14 However, running the + (positive) and - (negative) output load cables side by side or bundling them together is more effective against unwanted noise. The Kikusui-recommended currents shown in "Current capacity of load cables"...
- Page 15 (When using the optional large current load cable DC600-2P3M-M12M12) To connect sensing cables, see "Connecting the Sensing Cables" (p.16) Adjust the positions of the lock plates for the load input terminal cover (p.12). Close the load input terminal cover (p.11). PLZ-5W SR Series Setup Guide...
-
Page 16: Connecting The Sensing Cables
Short bars must be connected to the sensing terminals when remote sensing is not in use. Store the short bars in a safe place. Adjust the positions of the lock plates for the load input terminal cover (p.12). Close the load input terminal cover (p.11). PLZ-5W SR Series Setup Guide... - Page 17 Connect the cables as shown in the figure. Connect the cables as close to the EUT as possible. Sensing terminal Twist –S White PLZ-5W SR – – For details on enabling the remote sensing function, see the PLZ-5W user's manual. PLZ-5W SR Series Setup Guide...
-
Page 18: Connection For Synchronized Operation
You can connect a mixture of various PLZ-5W SR and PLZ-5W series models (for example, PLZ15005W SR and PLZ1205W). Typical LAN cables (straight) up to 30 m long can be used. To use LAN cables more than 30 m long, please contact your Kikusui agent or distributor. Risk of electric shock. - Page 19 Connect all PLZ-5W SR and PLZ-5W series units with LAN cables. EXT SYNC IN EXT SYNC OUT LAN cable EXT SYNC IN Connection example (when connecting the PLZ15005W SR, PLZ205W, PLZ1205W) This completes the connections. PLZ-5W SR Series Setup Guide...
-
Page 20: Connecting The External Control Device
Adjust the positions of the lock plates for the load input terminal cover (p.12). Close the load input terminal cover (p.11). Connect the signal cable to the external controller. This completes the external control connection procedure. PLZ-5W SR Series Setup Guide... -
Page 21: Connecting The Remote Control Device
Connect a cable to the interface connector that you want to use. Run the cables through. Example: When a LAN cable is connected Adjust the positions of the lock plates for the load input terminal cover (p.12). Close the load input terminal cover (p.11). PLZ-5W SR Series Setup Guide... - Page 22 ○ ○ 底盘组装品 ( 含变压器 ) ╳ ○ ○ ○ ○ ○ 辅助设备 ○ ○ ○ ○ ○ ○ 本表格依据 SJ/T 11364 的规定编制。 ○ : 该部件所有均质材料的有毒有害物质的含量不超过 GB/T 26572 标准所规定的极限值要求。 ╳ : 该部件至少有一种均质材料的有毒有害物质的含量超过 GB/T 26572 标准所规定的极限值要求。 PLZ-5W SR Series Setup Guide...
