Summary of Contents for Newentor Weather Station
- Page 1 Weather Station (Save the Instructions For Future Reference) Email Facebook service@newentor.com Search: Newentor WhatsApp Telegram +8613410031201 NEWENTOR Weather station is a functional product, if you have any questions of using it, contact us through above ways to get support.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. WEATHER STATION FEATURES 1.1 Pakage List ······················································· 1.2 Appearance Description ·········································· 1.3 Button Function ·················································· 2. INITIAL OPERATION ········································ 3. TIME SETTING 3.1 Set Time Manually ················································ 3.2 Set Time Automatically ··········································· 4. ALARM CLOCKS 4.1 Setting the Daily Alarms ···········································... -
Page 3: Weather Station Features
WEATHER STATION FEATURES 1.1 Pakage List ITEM NO PART NAME FIGURE Weather Station Outside Sensor Stickers User Manual The device will consume a lot of battery power when the backlight is on. Like most other black-and-white screen devices, to extend... -
Page 4: Appearance Description
1.2 Appearance Description 1. Ice alert ( 11th） 13th） 11. Battery signal ( 2. Air pressure Trend ( 12th） 13th） 12. Temperature ( 9th） 12th） 3. Alarm clock 2 ( 13. Comfort level ( 8th） 13th） 4. WWVB searching signal ( 14. - Page 5 A1: Remote sensor temperature A2: Emission symbols A3: Channel number A4: Remote sensor humidity A5: Remote sensor low battery indicate（ 12th） B1: °C /°F unit transfer button B2: Manual transmitter button B3: Channel switch C1: Transmit indicating lamp C2: Wall mounting hole C3: Stand cover C4: Battery compartment cover C5: Battery compartment...
-
Page 6: Button Function
1.3 Button Function Button LIGHT ALARM °C/°F/－ /SNZ Function MAX/MIN Turn Alarm Wake up on/off tempera- °C/°F Select time Press backlight ture & Switch channel alarm display for 15s humidity Normal Mode Re-record Start/- MAX/MIN Wake up Time Channel cancel Hold Alarm tempera-... -
Page 7: Initial Operation
3 seconds, and you will hear a beep tone, then detect indoor temperature & humidity. · The Weather Station will start to make a connection to the outdoor remote sensor. This process lasts for a maximum of 3 minutes and will displayed by a flashing reception antenna symbol... -
Page 8: Time Setting
TIME SETTING 3.1 Set Time Manually · Press and hold the【SET】button for 2 seconds, the “ ON/OFF ” starts to flash. Now use【 】and【°C/°F/－】buttons to set the radio control function ON or OFF. · Press【SET】button to confirm your setting, the 12/24HR start to flash. -
Page 9: Set Time Automatically
· A continuously displayed radio mast icon indicates that the WWVB signal was received successfully. · We recommend Placing weather station at a minimum distance of 2.5 meters (8.2Feet) to all sources of interference, such as televisions or computer monitors or switching power adapter. -
Page 10: Alarm Clocks
ALARM CLOCKS 4.1 Setting the Daily Alarms · Press once【 】button, LCD will display , press again to display , press again to display , each to represent Alarm1ON (Alarm2 OFF), Alarm2 ON (Alarm1 OFF), Alarm1&Alarm2 ON. Press 【 】button again to Alarm1 and Alarm2 all OFF (no“ ”and “... -
Page 11: Snooze Function
Query Maximum/minimum numerical value · When the temperature / humidity are shown in the LCD, the weather station begins to record temperature/humidity maximum and minimum numerical value. · Press【MEM】button, the LCD will display the maximum value of temperature/ humidity. Press【MEM】button again, the LCD will display the minimum value of temperature/humidity. -
Page 12: Ice Alert
· The weather forecast is calculated from evaluation of fluctuations in the barometric pressure and may deviate from the actual weather conditions. · The weather station displays the following weather symbols:... -
Page 13: Comfort Level
COMFORT LEVEL The temperature and humidity is dry (When the humidity is below 40%). The temperature and humidity is comfort (When the temperature in 20~28℃ and the humidity is 40~70%). The temperature and humidity is wet (When the humidity is above 70%). F.Y.I. -
Page 14: Low Battery Indicate
· Temperature measurement range（1°C deviation）: --Indoor: -9.9°C(14.2°F)~50°C(122°F) --Outdoor: -25°C(-13°F)~50°C(122°F) · Wireless Outdoor Sensor: --433.92MHz RF transmitting frequency --60m/200ft transmission rang in an open area · Power Supply: --Weather Station: Battery: 2 x LR06AA (Not including) --Wireless Outdoor Sensor: 2 x LR06AA (Not including)
Need help?
Do you have a question about the Weather Station and is the answer not in the manual?
Questions and answers
my model Q9 remote has quit sending new batteries did not help
If your Newentor Weather Station model Q9 remote has stopped working even after replacing the batteries, try the following steps:
1. Bring the remote sensor indoors and place it near the base station.
2. Wait about 10 minutes for the remote to warm up and reconnect.
3. Once the remote signal is picked up and readings appear, move the sensor to a warmer outdoor location (above 30°F) like a garage.
4. Avoid placing the sensor in very cold areas, as extreme cold may cause the signal to stop.
These steps can help restore the connection between the base and remote sensor.
This answer is automatically generated
Model FJ3391 is not receiving transmissions from the weather station in Denver. The date displayed is wrong.
occasionally the reading on the projection is upside down
this is model FJ3391-WWVB
The Newentor Weather Station allows the projection to be flipped 180°. If the projection reading appears upside down, it is likely because the projection has been flipped. Adjusting the projection settings should correct the orientation.
This answer is automatically generated
What is the setting for Mountain Time zone. Can’t find a list in the book
The Mountain Time zone setting for the Newentor Weather Station is MST (Mountain Standard Time).
This answer is automatically generated
The indoor temp and humidity has been stuck at the same settings for a few days. How do I fix this?
To fix the indoor temperature and humidity readings on your Newentor Weather Station that have been stuck, try the following steps:
1. Reset the base station: Remove the backup battery and unplug the unit. Wait a few minutes, then reinstall the battery and plug it back in.
2. Check the indoor sensor: If it’s a separate unit, ensure it has fresh batteries and is within range of the base station.
3. Move the unit: If the base station or sensor is in a very cold or hot area, try relocating it to a more moderate temperature zone (e.g., above 30°F).
4. Wait for signal: After resetting and relocating, give it some time (up to 10 minutes) to re-establish the signal and display readings.
These steps help re-establish communication and restore accurate readings.
This answer is automatically generated
How do I cancel alarms on weather station. I have one for 6AM & one for 7AM. Very anoying!
hi there - how do i change the time zone on my FJ3378?
The time on my unit is about 5 minutes ahead. Seems that it is not syncing with wvvb. It just started this about a month agao. At that time it was about 1 mininute ahead of all times (TV, PC, and Cell Phone). What could be wrong?
How so I stop the alarm ringing every day at 9:30 AMr
The model FJ3391 is not receiving transmissions from the Denver atomic clock and the displayed date is wrong.
