Installing the Cisco 805 Router
This chapter provides information on the following topics:
Safety
Required Equipment
Unpacking the Box
Installing the Router
Where to Go Next
Safety
This section contains information on warnings associated with using your router and on
electrostatic discharge (ESD).
Warnings
Before installing the router, read the following warnings:
Warning
replace this equipment.
Warning
power source.
Only trained and qualified personnel should be allowed to install or
Read the installation instructions before you connect the system to its
C H A P T E R
Installing the Cisco 805 Router 2-1
2
