THE DEFUNC MOBILE GAMING EARBUDS MODEL
Gaming Earbuds
Thank you for choosing the Defunc MOBILE GAMING Earbuds model. Read this manual to optimize your experience.
Technical specifications
Active playtime: ≈ 16 h
Battery capacity: 270 mAh
Bluetooth® version: 5.0
Charging means: USB-C
Charging time: ≈ 2 h
Drivers: dynamic/balanced armature
Microphone:
external MEMS/mute funtion
Preset compressor: 3D/EQ/normal
Standby time: up to 200 h
Wireless range: 10 m
Rated power: 60mW
Speaker: X
Speaker frequency: 20-20 KHz
φ10mm
Speaker dimension:
94±3db @1K HZ
Speaker sensitivity:
16Ω±15%
Impedance:
Frequency response:
20-20 KHz
What's included
Defunc Mobile Gaming Earbuds
Overview and controls
1. Power on/off, play/pause answer/end call
Power on/off: Long press for 3-4 seconds
Play/pause: Short press
Answer/end call: Short press
2. LED light
3. + Volume/Next track
Turn volume up: Short press
Next track: Long press
4. - Volume/Previous track
Turn volume down: Short press
Previous track: Long press
5. MicMute
Microphone mute on/off: Short press
6. Sound modes (3D/EQ/normal)
Switch sound modes: Short press
7. USB-C port
8. FlexMic
Advertisement
Table of Contents
Related Manuals for DeFunc D028
Summary of Contents for DeFunc D028
- Page 1 THE DEFUNC MOBILE GAMING EARBUDS MODEL Gaming Earbuds Thank you for choosing the Defunc MOBILE GAMING Earbuds model. Read this manual to optimize your experience. Technical specifications Active playtime: ≈ 16 h Battery capacity: 270 mAh Bluetooth® version: 5.0 Charging means: USB-C Charging time: ≈...
- Page 2 1. Press power/play button for 5 seconds to turn on the earbuds and activate pairing mode. The LED light will flash in blue and red. 2. Activate Bluetooth on your device. Select Defunc MOBILE GAMING in the Bluetooth list. Blue LED light switches off when pairing is successful.
