- Page 1 English OPENSKY Zhaga IoT Installation Manual PR166202 TVILIGHT PROJECTS BV / Beechavenue 162-180, 1119 PS, Schiphol-Rijk, the Netherlands info@tvilight.com / www.tvilight.com Copyright Tvilight B.V. | PR 00-1662-02 | Rev. D | 24/01/2021...
- Page 2 NOTE: Some dimmable drivers/ballasts must be programmed/set to DALI mode. Also, select the correct configuration (i.e. DALI) from the CMS. If this has not been done, OPENSKY Zhaga IoT will not be able to dim the connected armature. DALI (logarithmic) dimming mode is recommended.
- Page 3 In box: In box: OpenSky Zhaga IoT 50.83 mm 50.83 mm Zhaga IoT Input: 18-30 Vdc Beechavenue 162-180, 1119 PS, Schiphol-Rijk, the Netherlands Output: 0 - 10V/ DALI/ SR/ D4I Designed in the Netherlands. Assembled in PRC. RF: EGPRS/LTE Cat M1/Cat NB2 ta : -40˚C...
- Page 4 2. Login with your Username and Password. 3. Use the ‘Add device’ function in the Scan&Go app to add the device to CityManager. 4. The Device Name (OpenSky Zhaga IoT), Serial Number/ QR Code (UID) and Com- ments can be added manually.
- Page 5 NOTE: The receptacle, and threfore the OpenSky Zhaga, must be mounted on the top side of the luminaire. 2. Connect OpenSky Zhaga IoT Press OpenSky Zhaga IoT onto the Zhaga Receptacle and twist to lock in place. www.tvilight.com R 166202...
- Page 6 3. Apply Pole ID Label to the pole Ensure that the Product and Pole ID Labels match. Beechavenue 162-180, 1119 PS, Schiphol-Rijk, the Netherlands Designed in the Netherlands. Assembled in PRC. 740215000AC 740215000AC www.tvilight.com R 166202 | Rev. D | Page 6 of 13...
- Page 7 The location of the hole must be on the top side of the luminaire. Receptacle assembly with pre-installed gasket Top Side of the Luminaire housing Mounting hole Lock washer Mounting nut www.tvilight.com R 166202 | Rev. D | Page 7 of 13...
- Page 8 Excessive movement could result in reduced system performance. An absolute maximum hole diameter of 22.0mm should be used. www.tvilight.com R 166202 | Rev. D | Page 8 of 13...
- Page 9 Positive pole for DALI or DALI based protocol LSI sensor input Please ensure to connect the DALI+ and DALI- wires correctly. DALI- is shared with the Device GND line. www.tvilight.com R 166202 | Rev. D | Page 9 of 13...
- Page 10 Movement of the insulation will result in variation of the wire strip length which can lead to incorrect wire termination. www.tvilight.com R 166202 | Rev. D | Page 10 of 13...
- Page 11 Extreme caution to ensure there is no power in the system prior to insertion of wire extraction device. Electrical shock or system damage can result if care is not taken. www.tvilight.com R 166202 | Rev. D | Page 11 of 13...
-
Page 12: Getting Started
Getting started 1. Ensure that the device is pre-registered through Tvilight Scan & Go App 2. Ensure that the device is installed properly as per the steps mentioned previously 3. Turn ON the power 4. The device starts to initialize, and the red LED (visible inside the device window) will flash (blink). -
Page 13: Further Support
This means that the device is not able to connect to the CMS server. This can be due to the following reasons: 1. The device is not yet registered in the Tvilight CMS. Please get it registered using the Scan & Go app (see instructions above).
