Chauvet LED-BOSS Operating Instructions

DMX Control Mode

The COLORboss™ will respond to 4 channels of DMX control. The same functions that are
accessible manually are also accessible remotely using an external universal DMX controller. It is
important to remember that when controlling the COLORsplash™ fixtures through the COLORboss™
you are no longer controlling the pars individually, only the COLORboss™ controller.
1. Press the MENU repeatedly until you reach "15 DMX Control".
2. Press SETUP button to enter mode.
3. Press UP or DOWN buttons to change the DMX starting address for the controller.
4. You must leave this menu selection on screen in order for this mode to remain active.

DMX Channel Values

D
EFAULT
1
2
3
4
LED-BOSS User Manual
V
ALUE

Programs

000 019 Black
020 039 Red
040 058 Green
059 078 Yellow
079 098 Blue
099 117 Purple
118 137 Cyan
138 156 White
157 176 Color Change
177 196 Slow Flow 1
197 215 Slow Flow 2
216 235 Flash
236 254 Chase
255 Sound

Qty of Fixtures

000 255 1 par can > 20 par cans
Color Change
Slow Flow1
Slow Flow2

Run Speed

000 255
1 > 100%

Chase Speed

000 255 1 > 100%
8
F
UNCTION
Flash Chase
Sound

Flash Speed

Chase Program

1 > 100% 1 > 16
