Chauvet LED-CHVA Supplementary Manual

DMX Channel Values

D
EFAULT
1
2
3
4
LED-CHVA User Manual
V
ALUE

Programs

000 011 Black
012 023 Red
024 035 Green
036 047 Blue
048 059 Yellow
060 071 Purple
072 083 Light Blue
084 095 White
096 114 Color Change
115 119 Slow Flow 1
120 131 Slow Flow 2
132 143 Roll Chase 1
144 155 Roll Chase 2
156 167 Multi Color
168 179 Fast Flow 1
180 191 Fast Flow 2
192 203 Fast Flow 3
204 215 Fast Flow 4
216 227 2 Color Chase
228 239 2 Color Flow
240 251 Color Fade
252 255 Auto Run

Run Speed

000 255 Slow > Fast, (1 step/Minute) > (100 steps/Second)

Flash Speed

000 002 Always On
003 255 Slow > Fast (1 – 20Hz)

Color Combinations

000 011 Red & Green
012 023 Red & Yellow
024 035 Red & Blue
036 047 Red & Purple
048 059 Red & Cyan
060 071 Red & White
072 083 Green & Yellow
084 095 Green & Blue
096 107 Green & Purple
108 119 Green & Cyan
120 131 Green & White
132 143 Yellow & Blue
144 155 Yellow & Purple
156 167 Yellow & Cyan
168 179 Yellow & White
180 191 Blue & Purple
192 203 Blue & Cyan
204 215 Blue & White
216 227 Purple & Cyan
228 239 Purple & White
240 255 Cyan & White
10
F
UNCTION
Appendix
2007-03-22/17:11
