Attaching The Repair Device; Mounting The Magnifying Glass; Use; Using The Precision Engineer's Led Magnifying Glass - Powerfix Profi 60114 Operation And Safety Notes

Before Initial Use / Use

Attaching the repair device

Push the fixing clamp
the desired height and tighten the fastening screw
clockwise.
Insert the ball joint of the repair device
corresponding recess of the fixing clamp
Fix the repair device
ing screw

Mounting the magnifying glass

Push the fixing clamp
set the desired height. Tighten the fastening screw
turning it clockwise.
Insert the ball joint
and tighten the fastening screw
clockwise (Fig. A).

Use

Using the Precision Engineer's LED
Magnifying Glass
Turn the retaining screws
clockwise direction. Clamp the item to be repaired with
the alligator clips
