  • Page 1 PRO AS300D/500D (Digital) USER MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENT 1. Safety Precautions 2. Device Identi cation 3. System Overview 4. Control Panel Identi cation 5. Getting Started - Display Screen Menu - Changing the Settings - Fault Indicator on the control panel - Controlling the Active Oxygen emission rate - Installation of device - Installation of nozzle 6.

  • Page 3: Safety Precautions

    Any subsequent fault in the operation of the device will not be covered by the Warranty, and repair and maintenance service will be chargeable. 10. If the power cable is damaged, contact an authorized Medklinn Service Centre for repairs immediately. 11. Do not wipe the device with benzene or paint thinner.
  • Page 4 NOTE – Radio, TV or sensitive equipment interference: If the device should cause interference to radio, television reception or any sensitive equipment, try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the distance between the device and radio/TV receiver/sensitive equipment.

  • Page 5: Device Identi Cation

    Active Oxygen Outlet for the generated Active Oxygen Outlet Controls/Monitors the entire Control Panel system Door Door of the device Door Lock Locks the device’s door Filter O2 Control Control Panel Medklinn O3 Hydro 5 (Front View)
  • Page 6 Supplies power to the fan Cools internal compartment temperature Filters dust from entering the Fan Filter Filter inner compartment HVPS Supplies power to the ozone module HVPS Ozone Module Ozone Module Generates the Active Oxygen Medklinn PRO AS300D/500D (Inner Compartment View)
  • Page 7 DEVICE IDENTIFICATION Power Cable Connector Medklinn PRO AS300D/500D (Back View) Functional parts Power Cable Connector: Connector port for the power cable...
  • Page 8 Air Ventilation Holes for air to ow in/out of the inner compartment Holes Ozone Sensor Adjustable feet to control Leveling Feet Port height of device on a surface Leveling Feet Air Inlet Air Ventilation Holes Medklinn PRO AS300D/500D (Bottom View)

  • Page 9: System Overview

    When the Medklinn PRO AS300D/500D operates, the air is taken in by the compressor through the air inlet into the HEPA lter. This air is forced through a ne mesh lter that traps pollutants before passing into the oxygen tower, which compresses the air and removes nitrogen from it, thus increases the purity of oxygen (O2) up to 90%.

  • Page 10: Control Panel Identi Cation

    CONTROL PANEL IDENTIFICATION Functional parts Display Screen Displays information status of Display Screen the device FAULT INDI C ATORS OZONE GENERATOR Shows that the device is Power Indicator ON/OFF OXYGEN CHAMBER AIR FLOW To switch the device ON/OFF ALARM BYPASS Power Button and works as BACK button in the menus...
  • Page 11 CONTROL PANEL IDENTIFICATION Fault indicators Display Screen Ozone Points to a problem with the ozone generator Generator FAULT I ND I C ATO RS Oxygen Points to a problem with the OZONE GENERATOR oxygen chamber Chamber OXYGEN CHAMBER Air Flow Points to a problem with the AIR FLOW air ow...

  • Page 12: Getting Started

    GETTING STARTED 1. Plug the power cord into the connector of the device and 110V-240V AC power outlet. NOTE: Proper grounding for international plugs: For safety precaution, international plugs must have proper grounding wire connected to the device. 2. Press the Power Button on the Control Panel to switch on the device 3.
  • Page 13 Shows that the device has an issue to be addressed and has 30 REMAIN: 30 days days remaining of operating time before it shuts down. Make a call to the nearest Medklinn’s service center to address the issue. (c) MODE: STOPPED MODE: STOPPED Shows that the device has stopped operating.
  • Page 14 4. P2 12:00 - 14:00 Shows the setting of Program 2. It includes the start time, end time and shows that this current program is being disabled. Disabled 5. P3 15:00 - 17:00 Shows the setting of Program 3. It includes the start time, end time and shows that this current program is being disabled.
  • Page 15 8. O3 LVL at ROOM1 (Optional. Activated when ozone sensor is O3 LVL at ROOM1 installed) Shows the ozone level detected by ozone sensor 1. 0.00PPM 9. O3 LVL at ROOM2 (Optional. Activated when ozone sensor is O3 LVL at ROOM2 installed) Shows the ozone level detected by ozone sensor 2.

  • Page 16: Changing The Settings

    Changing the settings 1. Switch on the device by pressing Power on the Control Panel. 2. Wait until the information on the Display Screen is shown. 3. Press Set to enter into the main menu. Except the Display Screen, the other components stop operating while in this mode.
  • Page 17 (ii) Changing the operation time 8. From step 3, press Down to go onto the next option in the Program Setting main menu. The display Program Setting will be shown. 9. Press Set to change the Program Setting. 10. To set a single operation time for the entire 24 hours, press Down until Program 24h is shown and follow steps 12 - 16 only.
  • Page 18 14. Press Up/Down to toggle the time interval wanted. Disable 10minON, 10minON, 10minON, 10minON, 10minON, 10minOFF 20minOFF 30minOFF 40minOFF 50minOFF Disable Program Time 1 Time 2 Time 3 Time 4 Time 5 20minON, 20minON, 20minON, 20minON, 20minON, 30minON, 10minOFF 20minOFF 30minOFF 40minOFF 50minOFF...
  • Page 19 15. Press Set to select. There will be an asterisk beside the values *10min ON, to show that this particular time is selected. 30min OFF 16. Press Power twice to go back to main menu. Program 1 Program 1 17. Press Set to con gure settings of Program 1. 18.
  • Page 20 19. Press Up/Down to toggle the time interval wanted. Disable 10minON, 10minON, 10minON, 10minON, 10minON, 10minOFF 20minOFF 30minOFF 40minOFF 50minOFF Disable Program Time 1 Time 2 Time 3 Time 4 Time 5 20minON, 20minON, 20minON, 20minON, 20minON, 30minON, 10minOFF 20minOFF 30minOFF 40minOFF 50minOFF...
  • Page 21 20. Press Set to select. There will be an asterisk beside the values *10min ON, to show that this particular time is selected. 30min OFF 21. Press Power to go back to the previous menu. Edit Program 1 22. Press Down and then Set to enter Start Time con guration. Start Time Edit Value 23.
  • Page 22 NOTE - This is to set the cut-o limit of Active Oxygen production into the surrounding air. Once it reaches the limit, the ozone sensor will automatically stop the device from operating. The device starts operating again when the Active Oxygen is below the cut-o limit. Only change the O3 Threshold setting under direct supervision from Medklinn.
  • Page 23 32. From step 3, press Down until you see O3 Threshold in the O3 Threshold menu. 33. Press Set to enter O3 Threshold settings. O3 Threshold 34. Press Set to con gure settings for Sensor 1 (Sensor 1) 35. Press Up/Down to increase/decrease parts per million (ppm) Edit Value levels by 0.01.
  • Page 24 NOTE - Only applies to Medklinn PRO AS300D/500D devices which have more than 1 sensor. 41. Press Power to go BACK to the previous menu. 42. Press Power again to exit from the setting menu. NOTE - The Medklinn PRO AS300D/500D device will continue operating after exiting from the setting menu.

  • Page 25: Fault Indicator On The Control Panel

    Fault Indicators on the Control Panel Fault indicators appear to notify the user that there is a problem with the device. It is also accompanied with a buzzer sound. It directs the user to which component has failed. Ozone Generator Fault Condition: Buzzer sound emitted, red light on Ozone Generator, Display Screen shows ALARM: O3, Press v (Down) to mute.
  • Page 26 Steps to take: 1. Press Down to switch o the alarm. 2. Contact the nearest Medklinn service centre to arrange for maintenance service immediately. FAULT INDI C ATORS Call dealer for service OZONE GENERATOR OXYGEN CHAMBER AIR FLOW ALARM BYPASS 3.
  • Page 27 Alarm O2 OZONE GENERATOR Press V to mute OXYGEN CHAMBER AIR FLOW ALARM BYPASS 2. Contact the nearest Medklinn service centre to arrange for maintenance service immediately. FAULT INDIC ATORS Call dealer for service OZONE GENERATOR OXYGEN CHAMBER AIR FLOW...
  • Page 28 3. Meanwhile, the device will still continue to operate for the time stated on the Display Screen. FAU LT I ND I C ATOR S Mode: Temporary OZONE GENERATOR Remain: 30 days OXYGEN CHAMBER AIR FLOW ALARM BYPASS Air ow fault Condition: Buzzer sound emitted, red light on Air Flow, Display Screen shows Mode: Stopped, Call for service, device has stopped operating.

  • Page 29: Controlling The Active Oxygen Emission Rate

    (without the fault status above). The fault is resolved when the device is operating in normal mode after 40 seconds. 3. If it is not, press Power to switch the device o and contact the nearest Medklinn service centre to arrange for maintenance service immediately.

  • Page 30: Installation Of Device

    2. Programming the ON/OFF Time Using the programs P1, P2, P3 and/or P24h in the main menu to set the intervals of ON/OFF timing for the device. Refer to the section of Changing the operation time on page 15. 3. Ozone Sensor Cut-O Using the ozone sensor and the program O3 Threshold to cut-o the generation of Active Oxygen at a level which is set by the user.

  • Page 31: Installation Of Nozzle

    2. The Medklinn PRO AS300D/AS500D is secured to the brackets using its 4 leveling feet. NOTE – Make sure the air inlet is clear from any blockages Installation of Nozzle Electrical Conduit Protects the FEP tubes which ½” /(12.7mm) runs through it...
  • Page 32 Active Oxygen ow through the FEP Tubes. 5. Connect multiple Straight Nozzles along the FEP Tube path each with a T-joint. 6. Connect the FEP Tubes to the Straight Nozzles and device’s Reservoir outlet. FEP tube inside the ½ inch electrical conduit PRO AS300D/500D Straight Nozzle...

  • Page 33: Basic Maintenance

    7. The Straight Nozzle is secured to the ceiling by using the Nylon Butter y Anchor and two Stainless Steel screws. Screws 3.5 x 40 mm (stainless steel) Nylon Butter y Anchor Ceiling BASIC MAINTENANCE Cleaning the Fan Filter 1. Turn o the AC power outlet. Make sure the light at the ON/OFF Button is not lit. 2.
  • Page 34 3. Brush the Filter Mesh with a soft bristle brush. Rinse and dry the Filter Cover. Wipe the Fan gently with a dry cloth. Filter Mesh Filter Cover 4. Assemble the Fan Filter in proper order and reattach it to the Fan. 5.
