LDS Dactron FOCUS II System Manual

Dynamic signal analysis system
Hide thumbs
Table of Contents

Advertisement

Quick Links

FOCUS II
Dynamic Signal Analysis System
System
Guide
Rev. 3.05
System Installation
Maintenance
Calibration
Troubleshooting
LDS-Dactron
Phone. (408) 934-9160
Fax. (408) 934-9161
E-mail: technical.support@LDS-Dactron.spx.com
Web Site: www.lds-group.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dactron FOCUS II and is the answer not in the manual?

Questions and answers

Related Manuals for LDS Dactron FOCUS II

Summary of Contents for LDS Dactron FOCUS II

  • Page 1 FOCUS II Dynamic Signal Analysis System System Guide Rev. 3.05 System Installation Maintenance Calibration Troubleshooting LDS-Dactron Phone. (408) 934-9160 Fax. (408) 934-9161 E-mail: technical.support@LDS-Dactron.spx.com Web Site: www.lds-group.com...
  • Page 2 The user of the software assumes the entire risk of use of the software and the results obtained from use of the software. LDS shall not be liable for any incidental or consequential damages, including loss of data, lost profits, cost of cover or other special or indirect damages.

  • Page 3: Table Of Contents

    Table of Contents Introduction ......................1 System Description....................2 Options ......................... 3 System Hookups and Status Indicators ..............4 Specifications ....................... 9 Safety and Equipment Protection ..............14 Safety Summary ....................14 Danger Warnings....................15 Power and Environmental Requirements ............16 Power Requirements...................

  • Page 5: Introduction

    Introduction 1 Introduction This manual provides instructions on installing, maintaining, and calibrating a FOCUS II Dynamic Signal Analysis System. It also provides information on power and environmental requirements and safety considerations. Any person responsible for installing, maintaining or calibrating the system should be fully familiar with the contents of this manual.

  • Page 6: System Description

    The Focus II has a serial bus structure and allows for modular expansion. Board installations must be performed by an authorized LDS-Dactron representative. The basic system is configured as 4 analog input channels and 2 output channels. Extra inputs are added in 4- channel increments, by purchasing FCS-201 analog input modules.

  • Page 7: Options

    Introduction Options There are both hardware and software options available for the Focus II. These options are listed in the table below. Hardware Options Description FCS-201 4-Channel Analog Input Module FCS-202 4-Channel Strain Gage Module FCS-203 4-Channel Thermocouple Module Real-Time Software Options Description RT Pro Signal analysis and waveform source functions...

  • Page 8: System Hookups And Status Indicators

    Introduction System Hookups and Status Indicators The front of the system chassis has between 6 – 22 connectors. Connectors labeled 1 through 20 are for connection to input signals. The two source connectors supply analog output signals to drive devices such as electrodynamic shakers and acoustic speakers.
  • Page 9 Introduction STRAIN – lit green when unit is powered on and input voltage does not exceed the voltage range. They are lit red when input voltage exceeds voltage range indicating overload condition. Detailed view of the Focus II Strain Gage Connector THERMO –...
  • Page 10 Introduction Also on the front are a USB port, an AC adaptor jack, and a power switch. The AC adaptor jack is a standard single pin 2.1mm plug limited to a range of 9 to 36 Volts. On the rear of the unit is a SYNC port, which allows users to chain together two Focus II units.
  • Page 11 Introduction The Focus II is provided with rubber shock resistant bumper guards. These are designed to stabilize the enclosure on a desktop surface, stabilize a laptop PC placed on top of the enclosure and protect the system from vibration shocks. An integrated handle is available for easy transport of the Focus II.
  • Page 12 Introduction Front view of the Focus II showing Connectors for 20 Channels, 2 Output (Source) Channels, Power Switch, AC Adapter Jack, and USB Cable Port Rear view of the Focus II showing the Sync Port Focus II System Guide...

  • Page 13: Specifications

    Introduction Specifications Inputs Analog Four standard, expandable to forty simultaneous channels. All are differential inputs with 220k Ω impedance. Each input channel has overload detection before both the analog and digital anti-alias filters. Setup allows per channel selection of input voltage range (0.1V, 0.3V, 1V, 3V, 10V), transducer sensitivity, sensor type (e.g., acceleration, force, pressure, etc.), and coupling selections for DC, AC (high pass cutoff at 0.7 Hz, 3 Hz, or 22.4 Hz defined as - 0.1dB amplitude attenuation), ICP and TEDS.
  • Page 14 Introduction Strain Gage Four channel signal conditioning module for full bridge and half bridge strain gages, maximum of 16 simultaneous channels per unit. Input format Differential Input Connector 6 pin LEMO 0B Impedance 2 MΩ, 1MΩ each pin to GND Excitation voltage 2.5V, 5.0V, 10.0V, selectable per module Excitation Current...
  • Page 15 Introduction Thermocouple Four channel signal conditioning module for thermocouples, maximum of 16 simultaneous channels per unit. Input format Differential Input Connector Omega Miniature Impedance 20 MΩ between input pins, 10MΩ between each pin to GND ± 40Vpeak Max. input voltage Coupling 24 Bit Sample rate...
  • Page 16 Introduction Outputs Analog Waveform Source with 2 channels standard Output connector Electronics 24-bit Digital to Analog Converter (DAC) with analog and digital anti-imaging filters. Filtering A 160 dB/octave digital filter plus an analog filter prevent imaging and phase distortion. Frequency range Up to 42 kHz output frequency (96k samples per second) with extended frequency option.
  • Page 17 Operation of this equipment in a residential area is likely to cause harmful interference, in which case, the user will be required to correct the interference at his own expense. Any changes or modifications to this equipment not expressly approved by LDS-Dactron could void the user's authority to operate this equipment.

  • Page 18: Safety And Equipment Protection

    Because of the danger of introducing additional hazards, do not install substitute parts or perform any unauthorized modification to the system. Return the system to LDS-Dactron for service and repair to ensure that safety features are maintained. Focus II System Guide...

  • Page 19: Danger Warnings

    Safety and Equipment Protection Danger Warnings The warning messages below, and throughout this guide, are important notices regarding safe system operation and system protection. Instructions given by these warnings must be followed to ensure safety for both personnel and equipment. Warning Dangerous voltages may be present in the system.

  • Page 20: Power And Environmental Requirements

    The Focus II requires a DC source with a voltage between 9 and 36 Volts DC. This is provided by the external AC to DC adaptor supplied by LDS-Dactron or from any DC power source including an optional battery pack available from LDS-Dactron.

  • Page 21: Environmental Requirements

    Power and Environmental Requirements Environmental Requirements Operation When powered, the allowable ambient temperature for operation of the Focus II is from 32 to 122 ºF (0 to 50 ºC). The relative humidity range for operation is from 10 to 90% under non-condensing conditions. In accordance with International Standards IEC 1010-1 (EN61010-1) the following statements are also applicable: 1.

  • Page 22: Packaging For Shipment

    Original Packaging Use the original factory packaging containers to return ship the system to LDS-Dactron for Calibration or service. If the system is being returned to LDS-Dactron for service, attach a tag indicating the return merchandise authorization (RMA) number provided by LDS-Dactron customer support, type of service required, return address, system model name, and serial number.

  • Page 23: System Installation

    System Installation 4 System Installation Step 1: Focus II Driver Installation Instructions The Focus II communicates with the PC through a USB connection. This requires Windows driver software to enable the USB connection. The USB is a “plug and play” device, which means that after the driver is initially installed, the configuration of the driver is automatically launched every time the device is plugged into the USB port.
  • Page 24 System Installation 1. Turn on the PC and launch Windows. Your PC must use either the Windows 2000 or XP operating system. If you are using Windows 2000, you must be logged on with administrator privileges to install a new driver. 2.
  • Page 25 System Installation 5. Select, “Search for the best driver in these locations.” Specify a location, and enter the path to the CD drive. For example if the CD drive is the d:\ drive, you would type d:\ as the path. Windows remembers the path to the previous USB device installation so you may need to delete the old path and re-type the path to the CD drive.
  • Page 26 For Windows XP, after the driver installation starts the following dialog may open. Click on “Continue Anyway” to complete the installation. This dialog indicates that LDS-Dactron has not registered the driver with Microsoft Corporation. The driver installation should now be complete.

  • Page 27: Step 2: Installing Application Software On The Pc

    Analysis Series” User Guide, “Installation and Setup Procedure”, for complete details on installation of application software. The Focus II is now ready to run. Start the LDS-Dactron application software from the host PC and then you will be ready to use the application software.

  • Page 28: Step 3: Running The Rt Pro Software

    System Installation Step 3: Running the RT Pro Software When the Focus II is combined with RT Pro Dynamic Signal Analysis Software, the result is a full featured dynamic signal analyzer. 1. If your Focus II is not already connected to the PC’s USB connector, please do so now.
  • Page 29 System Installation 4. Insert the 3.5 inch floppy diskette that came with your Focus II system in the floppy drive of your PC. This diskette contains the calibration file that was generated for your Focus II prior to shipment. You must load this file in order to have a calibrated and accurate Focus II.

  • Page 30: Updating The Device Driver

    Focus II device driver. To update the LDS-Dactron Focus II device driver follow these instructions. The figures are for Windows XP and may vary for Windows 2000.
  • Page 31 System Installation 2. Scroll down to “Universal Serial Bus controllers”, click the “+” icon to expand the selection and right click on “LDS-Dactron Focus (USB 2.0 device).” Select “Update Driver…” from the pop up menu. Select, “Install from a list or specific location (Advanced)”. And click on the Next button.
  • Page 32 System Installation 3. Select, “Search for the best driver in these locations”. Specify a location and enter the path to the CD drive. The updated driver files are named Focus.sys and Focus.inf and are located on the root directory of the installation CD ROM. For example, if the CD drive is the d:\drive, you would type d:\ as the path.
  • Page 33 For Windows XP, after the driver installation starts the following dialog may open. Click on “Continue Anyway” to complete the installation. This dialog indicates that LDS-Dactron has not registered the driver with Microsoft Corporation. 4. Click on the Finish button to close the Hardware Update Wizard.

  • Page 34: Uninstalling The Device Driver

    Uninstalling the Device Driver Under rare circumstances you may need to uninstall the device driver for the LDS-Dactron Focus II. Follow these steps carefully. Failure to follow the instructions can result in damage to the operating system or other software. It is recommended that a network administrator or other computer expert perform this operation.
  • Page 35 System Installation 2. Scroll down to Universal Serial Bus controllers, click the “+” icon to expand the selection and right click on LDS-Dactron Focus (USB 2.0 device). Select Uninstall from the pop up menu. The Focus II will only be listed if it is connected via the USB cable.
  • Page 36 5. Scroll down to Universal Serial Bus controllers, click the “+” icon to expand the selection. If an unknown LDS-Dactron Focus (USB 2.0 device), Focus, or USB Device appears in Universal Serial Bus controllers, right click on the unknown LDS-Dactron Focus (USB 2.0 device), Focus, or USB Device.
  • Page 37 System Installation Optional: After you remove the device, you must manually delete the following files: C:\WINDOWS\INF\Other\Focus.inf C:\WINDOWS\SYSTEM32\DRIVERS\Focus.sys C:\WINDOWS\SYSTEM32\DRIVERS\Renum.hex C:\WINDOWS\INF\oem#.inf - There may be several #s, e.g., oem0.inf, oem1.inf, oem2.inf, etc... You can open each oem#.inf file and find the one that lists “FOCUS” at the top of the file. There may be more than one.
  • Page 38 Hardware tab and then the Device Manager button. 2. Scroll down to Universal Serial Bus controllers, click the “+” icon to expand the selection and right click on LDS-Dactron Focus (USB 2.0 device). Select Uninstall from the pop up menu.
  • Page 39 System Installation 3. Click OK to confirm the device removal. 4. After you remove the device, you must manually delete the following files: C:\WINNT\inf\Other\Focus.inf C:\WINNT\system32\drivers\Focus.sys C:\WINNT\system32\drivers\Renum.hex C:\WINT\inf\oem#.inf - There may be several #s, e.g., oem0.inf, oem1.inf, oem2.inf, etc... You can open each oem#.inf file and find the one that lists “FOCUS”...
  • Page 40 Hardware tab and then the Device Manager button. 7. Scroll down to Universal Serial Bus controllers, click the “+” icon to expand the selection and right click on the unknown LDS-Dactron Focus (USB 2.0 device). Select Uninstall from the pop up menu.
  • Page 41 System Installation 8. Click OK to confirm the device removal. The driver should now be completely uninstalled. Please be very careful when you delete files from your PC’s Windows system folder. If other files are deleted accidentally, your PC or programs may not function correctly.

  • Page 42: Maintenance

    Focus II System. There are no operator settable controls or adjustments inside the Focus II. Any hardware expansion must be performed by an authorized LDS- Dactron representative. Focus II System Guide...

  • Page 43: Calibration

    Once this calibration data is stored, the input measurement and the signal source can be adjusted back to the most accurate value. The LDS-Dactron system uses sigma-delta A/D and D/A converters and an anti-aliasing filter with a very high cutoff frequency. As a result, the amplitude characteristics of the input and signal source are not frequency dependent.

  • Page 44: Calibration Tools

    This provides a visual comparison of channel levels and is helpful in diagnosing problems if calibration fails. Calibration Two Pane Display Screen Calibration Tools To calibrate the Focus II with the LDS-Dactron calibration software, you will need the following items for: (1) Output Module Calibration a. 1 BNC cable.

  • Page 45: Installing The Calibration Software

    Voltmeter with a valid calibration certificate. The accuracy of the voltmeter should be 0.25% or better in order to ensure that the LDS-Dactron system is calibrated to an accuracy of ±1% (~ ±0.1dB). Generally, the accuracy of the calibration meter should be four times higher than the system being calibrated.

  • Page 46: Calibration Procedure

    Calibration This will invoke the dialog box shown below: Installation Dialog Box Follow the step-by-step instructions to install the software. This process will require your Calibration Passcode. Calibration Procedure Calibration involves the following major steps: (1) Connect cables to the Focus II. (2) Start the calibration software.
  • Page 47 Calibration Cable Connection Output Module Cable Connection for Output Module Calibration Connect a BNC cable to Signal Output 1. Connect the open end of the BNC cable to a voltmeter that is certified to the accuracy standard noted in the calibration tool requirements section (0.25% or better). Note during the calibration process, the operator will be prompted to disconnect and relocate BNC cables, as necessary.
  • Page 48 Calibration Attenuator Module Cable Connection for Attenuator Module Calibration Connect a BNC cable to Signal Output 1. Connect the open end of the BNC cable to Attenuator Input. Connect a BNC cable from Attenuator Output to a voltmeter that is certified to the accuracy standard noted in the calibration tool requirements section (0.25% or better).
  • Page 49 Calibration Input Module Cable Connection for Input Module Calibration Connect BNC cables to Input Channels 1-4 and Signal Output 1. Chain together the open ends of the BNC cables with BNC T Connectors. Focus II System Guide...
  • Page 50 Calibration Strain Gage Module Cable Connection for Strain Gage Module Calibration Connect a BNC cable from Signal Output 1 to Attenuator Input. Connect the Strain Gage to BNC Y adaptor cable to Strain Gage Channels 1-4. Connect a BNC cable from the Input BNC of the Strain Gage to BNC Y adaptor cable to Attenuator Output.
  • Page 51 Calibration Thermocouple Module Cable Connection for Thermocouple Module Calibration Connect a BNC cable from Signal Output 1 to Attenuator Input. Connect the Thermocouple to BNC adaptor cables to Thermocouple Channels 1-4. Connect a BNC cable to Attenuator Output. Chain together the open ends of the BNC cables with BNC T Connectors. Focus II System Guide...
  • Page 52 Calibration Start the Calibration Software Start the calibration software by clicking the Calibration icon. Select under the File menu: The user will be prompted to enter information pertaining to operator name and the voltage meter to be used during calibration. Select OK after the appropriate information has been entered.
  • Page 53 Click OK to acknowledge warning. This will open the normal LDS- Dactron Control System screen. LDS-Dactron Calibration Control System Screen...
  • Page 54 Calibration Click the “Start” button on the Control Panel and a “Board Selection” dialog box will appear highlighting the board to be calibrated. Follow the step-by-step instructions to begin calibration of the highlighted board. Focus II System Guide...
  • Page 55 Calibration Signal Output Calibration The first step is to measure the DC offset of the Output channel. A dialog box will appear. The operator should read the DC measurement from the voltmeter and type the value in the edit box. Please allow enough time for voltmeter readings to stabilize.
  • Page 56 Calibration Signal Output Calibration Verification After the signal output is calibrated, the software verifies the calibration results. During this verification, it requires measuring again the DC offset and RMS values. A dialog box will ask for a measurement and entry of the DC reading from the voltmeter.
  • Page 57 Calibration Attenuator Calibration - applicable to calibration of Strain Gage and Thermocouple modules The first step is to measure the DC offset of the attenuator Output channel. A dialog box will appear. The operator should read the DC measurement from the voltmeter and type the value in the edit box. Please allow enough time for voltmeter readings to stabilize.
  • Page 58 Calibration Attenuator Output Calibration Verification - applicable to calibration of Strain Gage and Thermocouple modules After the attenuator output is calibrated, the software verifies the calibration results. During this verification, it requires measuring again the DC offset and RMS values. A dialog box will ask for a measurement and entry of the DC reading from the meter.
  • Page 59 Calibration Input Module Calibration After completing calibration of the signal outputs, a dialog box will appear prompting the operator to calibrate additional modules within the system. DC Measurement for Gain Verification Follow the step-by-step instructions to continue. The system will now use the calibrated Output as the signal output.
  • Page 60 Calibration Strain Gage Module Calibration After completing calibration of the signal and attenuator outputs, a dialog box will appear prompting the operator to calibrate additional modules within the system. DC Measurement for Gain Verification Follow the step-by-step instructions to continue. The system will now use the calibrated attenuator Output as the signal output in conjunction with the calibrated output of Output 2.
  • Page 61 Calibration Thermocouple Module Calibration After completing calibration of the signal and attenuator outputs, a dialog box will appear prompting the operator to calibrate additional modules within the system. DC Measurement for Gain Verification Follow the step-by-step instructions to continue. The system will now use the calibrated attenuator Output as the signal output.
  • Page 62 At the end of the calibration process, a dialog box showing the calibration report will be opened for review. The calibration data file and a text report are saved in the “LDS-DactronCalib” directory. You can view the calibration report in text mode at any time. This Calibration Report is the basis for any calibration certification requirement.

  • Page 63: System Troubleshooting

    System Troubleshooting 7 System Troubleshooting The diagram below shows the structured layers of the LDS-Dactron Focus II System. Each layer generates and sends a message to the system user interface in the event of an error condition. These messages aid in diagnosing and resolving problems.

  • Page 64: Usb Not Connected At Application Startup

    System Troubleshooting USB not connected at application startup The Focus II must be connected to the PC via the USB cable before the application software is started. If you start the application software before making the proper connections, you will receive the following error message.

  • Page 65: Failure To Initialize The Focus Ii

    Focus II is not connected, then it will not be listed in the Device Manager list. If the LDS-Dactron Focus (USB 2.0 device) driver is not listed and the Focus II is plugged in then the drive may not be installed correctly.

  • Page 66: Usb Cable Disconnected While Operating Software

    System Troubleshooting USB cable disconnected while operating software If the USB cable is inadvertently disconnected between the Focus II and the PC while the application software is running the following error message will be displayed. Follow the instructions provided to re-establish communication with the Focus II.

  • Page 67: Limited Warranty Statement

    Limited Warranty Statement 8 Limited Warranty Statement LDS warrants to you that LDS software will not fail to execute its programming instructions, for a period of one year from date of shipment, due to defects in material and workmanship when properly installed.
  • Page 68 Limited Warranty Statement ASSISTANCE If you are unable to solve a problem with your LDS-Dactron product, contact your LDS Representative. To locate the LDS Representative in your area refer to LDS web site www.lds-group.com. You can also contact LDS-Dactron directly at using the contact information on the cover page.

  • Page 69: Manual Revision History

    Manual Revision History 9 Manual Revision History Date Manual Revision Notes Jul 2004 3.00, 66 pages Product Release Focus II System Guide...

  • Page 70: Index

    10 Index Calibration ............39 Power Requirements ........16 Danger Warnings..........15 Safety ............. 14 Shipment ............18 Software Option ..........3 Specifications ........... 9 Environmental Requirements ......17 Storage ............17 System Description .......... 2 System Installation ......... 19 Hardware Option ..........
