- Page 1 All manuals and user guides at all-guides.com...
- Page 2 All manuals and user guides at all-guides.com IMPORTANT SAFETY INSTRUCTIONS READ BEFORE OPERATING EQUIPMENT Read these instructions and keep them for future reference. Carefully follow instructions and take heed to all warnings. Do not use this apparatus near water. Clean amplifier housing only with a slightly damp cloth. Do not block any of the ventilation openings.
- Page 3 All manuals and user guides at all-guides.com CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage "...
- Page 4 All manuals and user guides at all-guides.com Contents............Page Number Important Safety Instructions..........02 Amplifier Warnings / Cautions..........03 Amplifier Usage Guidelines..........05 Amplifier Specifications............05 Included Accessories............05 Amplifier Operation - Front Panel........06 - 07 Amplifier Operation - Rear Panel........08 - 09 Remote Control............10 Optional Base Stand..........11 Contact Information........Back Cover Warranty............Back Cover...
-
Page 5: Amplifier Specifications
All manuals and user guides at all-guides.com Amplifier Usage Guidelines This amplifier is designed for use with the following ButtKicker ® transducer models only: BK-GR....(quantity 1 max) BK-mini-LFE....(quantity 2 max) BK-mini-CT....(quantity 1 max) BK4-4....(quantity 2 max) BK4-2....(quantity 1 max) Amplifier Specifications Dimensions: 9.5”... -
Page 6: Front Panel
All manuals and user guides at all-guides.com Front Panel... - Page 7 All manuals and user guides at all-guides.com Amplifier Operation - Front Panel (From Left to Right) POWER BUTTON The Power Button engages and disengages amplifier circuits. Check all amplifier connections and verify the AC line power source before engaging the Power Button. If in Standby mode, the amplifier will be brought into full On mode automatically when an input signal is reapplied, or manually by pressing the Power Button twice to turn the amplifier off, and then back on.
-
Page 8: Rear Panel
All manuals and user guides at all-guides.com Rear Panel... - Page 9 Used for attaching speaker wire to the ButtKicker Unit(s). NOTE: Please see the ® Amplifier Usage Guidelines on page 5 for a list of ButtKicker models that can be used with this amplifier. Turn the amplifier off before connecting to the Speaker Output.
-
Page 10: Remote Control
All manuals and user guides at all-guides.com Remote Control Connection Plug the Remote Control into the front of the BKA-130-C Power Amplifier where it says “Remote”. Please note the correct side up on the connector. Operation POWER BUTTON The Power Button duplicates the Power Button on the front panel of the amplifier. - Page 11 All manuals and user guides at all-guides.com Optional Base Stand The BKA-130-C can also be set in an upright, vertical position by placing it in the optional Base Stand (included).
