American Gourmet
600 Series
Product Guide
Model 10301567
Tools needed for assembly:
Phillips Screwdriver
Flat Head Screwdriver
Two adjustable wrenches
Hammer
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
CAUTION:
Read and follow all safety statements, assembly instructions,
and use and care directions before attempting to assemble
and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal inside
homes, vehicles, or tents.
The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; America's Legendary Barbeque Company®; American Gourmet®;
Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Everybody Outside®; FastStart®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared Grilling That's
All About U®; Keepers of the Flame®; New Braunfels Smoker Company®; Patio Bistro®; Patio Caddie®; Patio Kitchen®; Pro-Sear®; RED®; Quantum®; Santa Fe®; Sear and Grill®; Sierra®; Signature
Series®; Sure2Burn®; The Big Easy®; Trentino®; U®; Wild West Tradition®; and the following marks:
The following are trademarks of W.C. Bradley Co.: Advantage Series™; Auto-Clean™;Chef Tested™; Commercial Series™; Designer Series™;; Diamond Flame™; Double Chef™; Fireball™; Firenzy™;
FlavorMaster™;Front Avenue™; Grill 2 Go® Advantage™; Hog and Yard Bird™; H20 Smoker™; Infrared. Grilling's Juicy Little Secret™; Incredible Taste. Infallible Results™; Infrared Inside™; Insure™; Let's
Grill Something Together™; Lev-Alert™; Longhorn™; Magneto™; Precision Flame™; Quick2Burn™; QuickSet™; Ready When You Are™; Season, Set, And Savor™; Sizzle On The Grill™; Signature Series™;
SureFire™; The Minute Grill™;Torchfork™; Universal Grill Parts™; You Bring the Party™
Protected under one or more of the following U.S. Patents: 5,421,319; 5,458,309; 5,579,755; 5,996,573; 6,135,104; 6,279,566; 6,331,108; 6,484,900; 6,526,876; 6,595,197; 6,640,799; 6,640,803; 6,729,873; 6,739,473; 6,749,424; 6,792,935; 6,951,213;
7,047,590; 7,516,693; D364,535; D372,637; D373,701; D377,735; D383,035; D397,910; D405,643; D406,005; D406,009 ; D413,043; D413,229; D414,982; D415,388; D416,164; D416,441; D417,587; D417,588; D422,516; D423,274; D423,876;
D428,303; D430,772; D435,396; D436,004; D438,059; D438,060; D438,427; D439,110; D442,505; D443,179; D443,354; D443,464; D447,384; D447,385; D447,909; D448,610; D448,614; D448,615; D448,616; D448,975; D449,492; D450,544; D451,759;
D454,028; D454,031; D455,205; D455,206; D456,202; D456,222; D456,223; D457,789; D458,520; D458,760; D458,802; D459,088; D459,148 D459,149; D459,161; D459,163; D459,586; D459,943; D460,312; D460,313; D460,318; D461,359; D465,123;
D465,693; D466,307; D466,439; D466,752; D473,414; D474,371; D477,498; D477,501; D477,504; D477,506; D477,746; D478,471; D478,472; D480,914; D491,410; D494,009; D494,413; D498,523; D500,359; D504,048; D530,098; D535,000;
Canada:D97,504;D99,355; D102,037; D104,200;D108,377; 2,315,567; France:D010,231;D010,422;D010,590;D010,849; 1,089,646; South Korea: 384,565; United Kingdom: 2,099,402. Other Patents Pending. © 2009 W.C. Bradley Company
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register
Estimated Assembly Time: 1 Hour
FOR OUTDOOR USE ONLY
®
TEC™ is a trademark of Tec Infrared Grills.
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
CAUTION:
THIS UNIT IS HEAVY! DO NOT attempt to
assemble without a helper.
®
1-800-241-7548
.
42804501 - 07/13/09
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Char-Broil 10301567
Summary of Contents for Char-Broil 10301567
-
Page 1: Product Record Information
Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Everybody Outside®; FastStart®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared Grilling That’s All About U®; Keepers of the Flame®; New Braunfels Smoker Company®; Patio Bistro®; Patio Caddie®; Patio Kitchen®; Pro-Sear®; RED®; Quantum®; Santa Fe®; Sear and Grill®; Sierra®; Signature Series®;... -
Page 2: Table Of Contents
Preparing to use your Grill ......3 Grill Maintenance ........3 Cooking Tips . -
Page 3: Preparing To Use Your Grill
Rust can appear on the inside of your grill. Maintaining a light coat of vegetable oil on the interior surfaces will aid in the protection of your grill. Exterior surfaces of the grill may need occasional touch up. We recommend the use of commercially available black high temperature spray paint. -
Page 4: Cooking Tips
Raise or lower the adjustable charcoal grate. Partially close the vents in the grill, which reduces the amount of oxygen that feeds the fire. Use the indirect grilling method, with coals to either side of a drip pan and the food over the pan rather than directly over the coals. - Page 5 For more control, pile some of the coals on one side of the grill where they will emit intense heat. You can move the food around on the grill, setting it over the very hot coals when you want to sear it or when a thick piece needs to cook a little more quickly.
-
Page 6: Limited Warranty
LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*. -
Page 7: Parts List/ Parts Diagram
PARTS LIST Key Qty Description Lid Assembly Swing-Away Grate Cooking Grate Fire Grate Hanger Butterfly Damper Ash Pan/Fire Grate Front Shelf Bracket, RH Front Shelf Bracket, LH Cart Brace Long Leg Short Leg Wheel Cap Axle Leg End Caps Key Qty Description Heat Indicator Wheel... -
Page 8: Assembly
ASSEMBLY FIRST, GET A HELPER! This unit is heavy and requires a second person for lifting and moving. NEXT, pick a suitable location to work. Open the carton and slit the corners so that the carton lays flat. This will give you a protective surface during assembly. - Page 9 Lay the leg assembly on its side with leg braces pointing upward. insert the wood rack hooks into leg holes and swing rack upward, parallel to leg braces. With aid of a helper, place leg holes of remaining leg assembly over wood rack and rotate leg assembly unitl it meets the leg braces.
- Page 10 Insert a small Hair Pin Clipinto the hole at one end of the axle and bend the ends of the pin back so that it cannot be removed. Slide a wheel onto the axle. Slide the axle through the holes at the ends of the short legs. Slide the remaining wheel onto the axle and secure with the remaining Hair Pin Clip.
- Page 11 • Attach LH and RH Front Shelf Brackets to the firebox using 4 each 1/4-20" Shoulder Bolts and 4 each 1/4-20 flange nuts. • After the front shelf brackets are secured, attach the front shelf slats to the brackets using 4 each 1/4-20x1 1/4 screws and 4 each 1/4-20 flange nuts.
- Page 12 Place Grill Lid on top of firebox assembly. Align hinge holes on back of unit. With the aid of a helper, attach Grill Lid to firebox using 2 each Hinge Pins. Once Hinge Pins are in place, insert Large Hair Pin Clip into hole in Hinge Pin.
- Page 13 Place the 3 Cooking Grates into the firebox. The Cooking Grates will rest on the front and rear ledges of the firebox. Next, Attach the Grease Cup Clip as shown. Your grill is now completely assembled. Please refer to page 3 for instructions on how to prepare and season your grill prior to cooking. Place Cooking Grates into the firebox.
-
Page 14: Assembly
Hardware is shown actual size. You may have spare hardware after assembly is complete. 1/4-20 Shoulder Bolt Qty. 4 1/4-20x1/2” 1/4-20x3/4” Hex Screw Hex Screw Qty. 4 Qty. 5 Wheel Cap Qty. 2 Page 14 HARDWARE LIST 1/4-20 1/4” Flange Nut Lock Washer Qty. -
Page 16: Registration Card
Warranty Registration Department P.O. Box 1240 Columbus, GA 31902-1240 REGTEMP REV02...
