4. Operation

4.1.

Activation of the video-in-motion function

The video-in-motion function is permanently active without disturbing the navigation
performance.
4.2.

Selecting the dvbLOGiC as current AV-source

Selecting the dvbLOGiC as current AV-source is activated by pressing
the "MODE"-button (depending on the current mode of the system, it
has to be pressed several times). After the first activation the system
will switch the picture after a few seconds from dvbLOGiC-video to
factory-video by itself, the audio will still sty on dvbLOGiC-audio. Use
the picture switch button to select between factory-video and
dvbLOGiC-video. You can leave the dvbLOGiC mode by pressing the "FM" or the "MODE"
button.
Note: The IR-control channel is preset to RC-Code 09 for the optional USB-AV-port (DVBU).
4.3.

Switching to internal DVB-T and AV-source

In dvbLOGiC mode longpress station button „1" to switch to the internal DVB-T tuner or
longpress station button "2" to switch to the AV-input mode.
4.4.

Picture settings

The dvbLOGiC has its own picture setting mode. In order to
enter this mode, set to "Video Set:ON" in the "VI SETTINGS"
menu. After switching to the Video/Audio level the keys
"1 <> 4" , "2 <> 5" , "3 <> 6" can be used for picture settings.
(each with short keypress).
You can deactivate the picture setting mode
in the "VI SETTINGS" or by turning off ignition.
Version 14.02.2013
MODE -
button
Contrast
Colour saturation
Brightness
picture switch
button
DVB-MK-AUX
