Caraudio-Systems dvbLOGi Manual

For bmw professional navigation systems ccc and cic with idrive

Advertisement

Quick Links

dvbLOGiC DVB-T Tuner
for BMW Professional navigation systems
Product features
• Full plug and play vehicle-specific dual DVB-T Tuner + USB-AV-Player
• DVB-T-Tuner MPEG4 compatible (HD)
• USB-AV-Player for USB-media (audio, video, photo) up to 2TB (FAT32 and NTFS)
• Support of all common Audio & Video formats (e.g MKV, MOV, MPEG-1/2/4, H.264)
• USB-AV-Player with last position memory for Audio and Video playback
• with two antenna adapters and USB extension with installation socket
• integrated into and controllable by vehicle infotainment
• AV-input with IR-control channel
• control of after-market devices, e.g. DVD-player, DAB+ tuner
• after-market rear-view camera input
• automatic or manual switching to after-market rear-view camera input (only from
dvbLOGiC mode)
• rear-seat-entertainment AV-output for AV-sources connected to the dvbLOGiC
• optional remote control for full DVB-tuner and USB AV-Player functions/rear-seat-
entertainment
• power-on remote-out trigger-signal (+12V max 1A) to switch on connected devices
• video-in-motion
Version 22.07.2014
DT1-CXC-TV1
CCC and CIC with iDrive
Vehicles with factory TV-tuner port
(Factory TV-tuner must be uninstalled)
DT1-CXC-TV1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the dvbLOGi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Caraudio-Systems dvbLOGi

  • Page 1 dvbLOGiC DVB-T Tuner DT1-CXC-TV1 for BMW Professional navigation systems CCC and CIC with iDrive Vehicles with factory TV-tuner port (Factory TV-tuner must be uninstalled) Product features • Full plug and play vehicle-specific dual DVB-T Tuner + USB-AV-Player • DVB-T-Tuner MPEG4 compatible (HD) •...
  • Page 2: Table Of Contents

    Contents 1. Prior to Installation 1.1. Delivery contents 1.2. Check compatibility of vehicle and accessories 1.3. Setting the dip switches of the CAN-box TV-436 1.4. Setting the dip switches of the tuner-box DT1C-M736 1.4.1. Automatic switching to rear-view camera 1.4.2. Deactivating dvbLOGiC AV input 2.
  • Page 3: Prior To Installation

    Legal Information By law, watching moving pictures while driving is prohibited, the driver must not be distracted. We do not accept any liability for material damage or personal injury resulting, directly or indirectly, from installation or operation of this product. This product should only be used while standing or to display fixed menus or rear-view-camera video when the vehicle is moving, for example the MP3 menu for DVD upgrades.
  • Page 4: Check Compatibility Of Vehicle And Accessories

    1.1. Check compatibility of vehicle and accessories Requirements Vehicle 1series (E87) only CCC, 3series (E90/91/92), 5series (E60/61), 6series (E63/64), 7series (E65/66), X5 (E70), X6 (E71), Z4 (89) Navigation Navigation system Professional CCC (older 1/2-button iDrive or CIC (newer 8-button iDrive) Vehicles with TV-tuner port Limitations Factory-TV-tuner...
  • Page 5: Deactivating Dvblogic Av Input

    1.3.1. Automatic switching to after-market rear-view camera If an after-market rear-view camera shall be connected or a factory rear-view camera is connected, in order for the dvbLOGiC to automatically switch to its camera input when reverse is engaged, Dip switches set dip2 = ON (up).
  • Page 6: Removal Of Navigation Computer Ccc/Cic

    2.1. Removal of navigation computer CCC/CIC Example 5series (E60/61). Remove trim strip step by step using a plastic wedge. Do not proceed to quickly to avoid breaking clamps of the trim strip. Remove screws 1 and 2 (see picture). Remove climate control panel. Remove CD/DVD drive trim.
  • Page 7: Installation Of Can-Box Tv-436

    2.2. Installation of CAN-box TV-436 Disconnect female Quadlock connector from the back of the navigation computer. Remove MOST®-insert from the factory harness female Quadlock connector. Plug MOST®-insert into male MOST®-connector shell of harness C3C-BMW0x. Plug female Quadlock connector into male Quadlock socket of harness C3C-BMW0x.
  • Page 8: Installation Of Tuner-Box Dt1C-M736

    2.3. Installation of tuner-box DT1C-M736 The fibre optical interface installation is made at the navigation computer, which is located at the left side in the trunk behind a cover and has to be removed. The factory TV-tuner must be uninstalled. Remove the factory optical leads of the factory TV-tuner port (blue female connector) and connect it to the black male MOST®-connector enclosed to...
  • Page 9: Antennas And Optional Ir-Remote Control Set

    2.4. Antennas and optional IR-remote control set Mount antennas ANT-12 and connect them to the female f-plug connectors on front of tuner-box DT1C-M736. We strongly recommend to first test the reception quality of the chosen mounting position of the antennas before final installation! See “Appendix C – Antenna positioning”...
  • Page 10: Usb-Av-Player

    2.5. USB-AV-Player Connect the USB extension USBC-EXT to the USB-port on the rear of the tuner-box DT1C-M736. Connect USB-media (up to 2TB, FAT32 and NTFS) to the USB-port of the USB- extension USBC-EXT. 2.6. Connecting peripheral devices It is possible to connect an after-market AV-source, an after-market rear-view camera and rear-seat-entertainment to the dvbLOGiC Tuner.
  • Page 11: Av-Source

    2.6.1. AV-source The dvbLOGiC has the possibility to connect and remotely control by navigation buttons a pre-programmed device. The device list in the device control table shows the pre- programmed remote channels and the related IR-remote cables STA-xxx which must be ordered separately for the control of the device.
  • Page 12: After-Market Rear-View Camera

    2.6.3. After-market rear-view camera Connect the video RCA of the after-market rear-view camera to the the female RCA connector RVC of tuner-box DT1C-M736. Connect the green wire of C2C-BMW01 to the camera power supply (+12V max. 1A). The green wire is high (+12V) when reverse gear is engaged. On some vehicles the reverse light signal doesn’t exist on the CAN-bus.
  • Page 13: After-Market Rear-Seat-Entertainment

    2.6.4. After-market rear-seat-entertainment Using RCA-cables, connect the rear-seat-entertainment to the female RCA-connector VIDEO OUT of harness C3C-AVIR. Note: As the output is a full output, not shared with the video signal for the navigation system, splitting the video with an RCA Y-cable might give a good enough picture for two rear-seat-entertainment monitors.
  • Page 14: Assigning Device Control For Connected Av-Source

    3.3. Assigning device control for connected AV-source After selecting the dvbLOGiC as current AV source, push iDrive knob to open the dvbLOGiC control menu. Select control levels setup “AV: RCxx” and assign related IR-code as described in device control table. Note: If the AV-input is deactivated (see chapter 1.4.2.), the menu items “AV”...
  • Page 15: Button Assignment Table Idrive

    3.5. Button assignment table iDrive The button assignment table shows which functions of dvbLOGiC and additionally connected devices can be executed by iDrive. Once DVB-T or AV-input mode are activated the iDrive action in the left column will execute the function described in the corresponding device column.
  • Page 16: Specifications

    Temperature range -30°C to +80°C Weight 333g Measurements (box only) B x H x T 140 x 30 x 105 mm 5. Technical Support Caraudio-Systems Vertriebs GmbH NavLinkz GmbH manufacturer/distribution corporate sales/tech dealer-support Rheinhorststr. 22 Eurotec-Ring 45 D-67071 Ludwigshafen am Rhein...
