H-6546
INDUSTRIAL LED
MAGNIFIER
TOOL NEEDED
4 mm Allen
Wrench
1.
Locate and remove clamp from packaging.
2. Use screw mechanism to open clamp to the
thickness of the desired mounting surface.
3. Slide clamp onto desired mounting surface and
tighten screw mechanism. (See Figure 1)
Figure 1
NOTE: Clamp must be tightened completely
before attaching lamp.
4. Remove lamp from packaging.
CAUTION! Use both hands to hold lamp arms
closed when removing packaging. Open arms
slowly and carefully.
PAGE 1 OF 6
1-800-295-5510
uline.com
Pour le français, consulter les pages 5-6.
5. Lower stem of lamp into hole in clamp. (See Figure 2)
Figure 2
6. Insert plug into properly rated 120V outlet.
7.
Insert other end of plug into base of lamp.
(See Figure 3)
Figure 3
Para Español, vea páginas 3-4.
0621 IH-6546
