Hardware Inventory; Assembly Hardware; Installation Hardware; Safety Reversing Sensor Installation Hardware - Chamberlain Security + 9902C Owner's Manual

Separate all hardware from the packages in the rail carton and the opener carton and group as shown below, for
the assembly and installation procedures.
Bolt
1/4-20x1-3/4" (8)
Lag Screw
5/16"-9x1-5/8" (2)
Lag Screw
5/16"-18x1-7/8" (2)
Carriage Bolt
5/16"-18x2-1/2" (2)
Clevis Pin
5/16"x2-3/4" (1)
Lag Screw
#14-10x1-1/2" HH (4)
Hex Screw
1/4-20x1-1/2" (2)
Hardware

Assembly Hardware

1/4" - 20 x 5/8"
Hex Screw (4)

Installation Hardware

5/16"-18x7/8" (4)
Handle

Safety Reversing Sensor Installation Hardware

1/4"-20x1/2" (4)
#10-32x3/8" (4)
Lock Nut
1/4"-20 x 7/16 (12)
Hex Screw
Ring
Fastener (3)
Screw
6ABx1-1/4" (2)
Clevis Pin
5/16"x1-1/4" (1)
Carriage Bolt
Screw
5
Sprocket Coupling Sleeve
Nut 5/16"-18 (6)
Lock Washer 5/16" (6)
Insulated
Staples (10)
Dry Wall Anchors (2)
Clevis Pin
5/16"x1" (1)
Wing Nut (2)
Lock Nut
1/4"-20 x 7/16 (4)
Lock Nut Insulated
#10x32 (4) Staples (20)
Rope
