- Page 1 Giotto/Giotto Plus GIOTTO GIOTTO PLUS u se an d m ainte nance i n struc tions m anu al...
-
Page 3: Table Of Contents
Gi o tto/ Gi otto Plus Use and maintenance instructions Table of contents Introduction ..................4 1.1 ▪ Symbols used in the manual ....................4 Safety ....................4 2.1 ▪ General safety information .......................4 2.2 ▪ Safety devices ..........................5 2.3 ▪ Residual risks ...........................5 Awning description ................5 3.1 ▪... -
Page 4: Introduction
G io t to/G io t to Pl us Use and maintenance instructions Introduction This manual is an integral part of the awning and is intended for the user; it is the basic instrument for a proper use and maintenance of the product. IT IS forbidden to remove, rewrite or in any change the pages of this manual or its contents. -
Page 5: Safety Devices
Gi o tto/ Gi otto Plus Use and maintenance instructions Safety devices ▪ (OPTIONAL) WIND GAUGE SENSOR: in the event of strong winds, the awning closes automatically. The intervention level of the wind sensor (anemometer) is registered during the initial start-up procedure, as described in the Installer’s Manual. -
Page 6: Foreseen Use And Context Of Use
IT is forbidden to install or place ladders or other fixed items near to the awning, as much as the space needed for awning is limited. Technical data ▪ Overall dimensions and weight GIOTTO GIOTTO PLUS Width (cm) Projection (cm) Approx. weight (kg) 120-130 120-130 Blind roller Ø... -
Page 7: Technical Plate
Gi o tto/ Gi otto Plus Use and maintenance instructions Performance and safety in accordance with UNI EN13561:2004 GIOTTO GIOTTO PLUS Wind resistance class Nominal test pressure p (N/m ) α=1 Motor (if installed) Type see manual relative to the installed motor Features EC marked;... -
Page 8: Use Of Awning
G io t to/G io t to Pl us Use and maintenance instructions Use of awning WARNING Before using the awning, read Chapter 2 “Safety” and Chapter 3.2 “Foreseen use and context of use” carefully. WARNING Make sure that while opening/closing the awning, nobody is near to the awning’s range of action. -
Page 9: Awning Cleaning
Gi o tto/ Gi otto Plus Use and maintenance instructions In the event of any problems not listed in the tables, contact Technical Assistance. without electronic control centre PROBLEMS CAUSES SOLUTIONS Conical winding of canvas Incorrect guide alignment Contact Assistance. Non-uniform canvas thickness Fully rewind canvas The awning does not rewind com-... -
Page 10: Routine Maintenance
G io t to/G io t to Pl us Use and maintenance instructions Routine maintenance ▪ WARNING All maintenance and cleaning operations must be carried out with the power supply detached. The operations described below, if carried out within the timescales indicated, allow the product to be maintained in a good condition. -
Page 11: Dismantling And Disposal Of The Awning
Gi o tto/ Gi otto Plus Use and maintenance instructions Dismantling and disposal of the awning WARNING The awning must be dismantled by professionally qualified and trained staff. Request specialist intervention from Technical Assistance. Operations must be carried out with the awning fully pulled up. Remove the power supply to the system, disconnect the system downstream of the switch, disconnect the motor, unblock the supports and remove the awning from the supports. - Page 12 BAT S.p.A. Via H.Ford, Z.I. Est 30020 Noventa di Piave (VE) Italy tel +39 042165672 fax +3900421659007 info@batgroup.com www.batgroup.com...
