PC to TV Converter Box
Display on TV the materials from your laptop
Model:PT-100
Thanks for your purchasing this product.
Please read the Manual carefully before
using it, and keep this manual for further
reference.
Note: Before Using this product, Please
check
the content of package,
includ
ing: PT-100 Main unit,
Remo
te Controller, VGA Cable,
AAA B
atteries X2, Video Cable.
S-Video cable
Note: For Safety reason, never open the
housi
ng of PT-100. There is no user serviceable part.
Functon:
Show PC Presentation on TV
PT-100 PC to TV converter box is a palm size universal VGA to TV converter box.
Supporting
the VGA resolution up to 1024X768, it converts the VGA signal into Composite
Video, S-Video.
There is also a VGA output port for loop through application. It is good for
presentation, Web-Browsing, PC online Game, PC pictures, Surveillance and
movies down-load from Internet
1
Advertisement
Table of Contents
Related Manuals for Space Television PT-100
Summary of Contents for Space Television PT-100
- Page 1 PT-100. There is no user serviceable part. Functon: Show PC Presentation on TV PT-100 PC to TV converter box is a palm size universal VGA to TV converter box. Supporting the VGA resolution up to 1024X768, it converts the VGA signal into Composite Video, S-Video.
- Page 2 There are aIso adjustment buttons on the body of PT-100, for your convenience to adjust the picture output on the screen. Auto-Save function When you finish the setting of PT-100, all the data will be auto-saved. No need to reset again when you use it next time. System Requirements...
- Page 3 Note: If you want to loop out the VGA signal to another monitor please follow the Step2. Step 2 Connect the VGA cable of Monitor to the "VGA OUT" on the Rear Panel of PT-100. Step 3 Connect one end of the attached Video RCA cable to the "VIDEO OUT" of the PT-100 and the other end to the VIDEO input of your TV set.
- Page 4 Then you should see the picture on your TV Screen. Front View Step7 After completing Step 1 to 7, you will finish all set-up procedures for PT-100. Functions of buttons on the main unit: 1. POWER: On/off switch for this unit.
- Page 5 Functions of Remote Controller Tech of the 9 present Power 1/9 portion of screen Power on/off of PT-100 (enlarged 9 times of original), you can push the Tech of the 9 present desired key to show the 1/9 portion of screen...
- Page 6 4 to activate) Output Video Selection 3 port DIP switch Remote Control Full Functioned IR Remote Control Power By PC USB port or Via DC adaptor Package Content PT-100, VGA Cable, IR Remote(option), AAAx2.(option), RCA Video Cable S-Video Cable...
