- Page 1 U S E R M A N U A L SDI Scaler Converter (3G / HD/ SD–SDI TO HDMI & SDI) Model No: SDI-HDM Enjoy the vivid world!
- Page 2 INTRODUCTION Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of HDMI converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost- efficient.
- Page 3 PACKAGE CONTENTS: 1、5VPower Adaptor 1PCS 2、one pc of Manual 1PCS Physical Connection Showing Picture： Picture 1.0 Front Panel View HDMI OUT：HDMI output port STATUS：Led Status Light POWER：Power Led Status Light DC 5V~12V：5V~12V DC-DC Power Adaptor Interface. Picture 1.1 Back Panel View 720/1080P：Output resolution switch, 720P/ 60Hz、1080P/ 60Hz、PASS three modes for choose.
- Page 4 Operating and Connecting： 1. To use the coaxial cable to connect the SDI source with the SDI input port of the converter. 2. To use the HDMI cable to connect the Display with the HDMI output port of the converter. 3.
- Page 5 SPECIFICATIONS: SDI-HDM Support SDI Input Format………………………………………….SD-SDI、HD-SDI and 3G-SDI Max Resolution …………………………………………………………….……………1080P/60Hz Audio Signal………………………………………………………………….…………… SDI Built-in HDMI output…………………………………………………………………720P 60Hz/1080P 60Hz SDI baud rate…………………...……………………..………270Mb/s、1.485Gb/s and 2.97Gb/s Output DDC signal………………………………………………………..….………5Volts p-p (TTL) Max working current……………………………………………………..…..………...700mA/DC 5V Power adapter format……….….…Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V~12V/1A Operating Temperature range……..…………….……….……………….….…………...
- Page 6 Before power on, pls check the connection line carefully. And make sure that all interfaces are normally connected. The common trouble shooting way shows below: Before power on, pls check the connection line carefully. And make sure that all interfaces are normally connected.
