- Page 1 HDXS450-IR HDMI 4-way splItter extenDer KIt wItH pOe Over Cat 5e/6/7 HELPLINE 0861 40 41 42 • www.spacetv.co.za...
- Page 2 Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. 1. IntRoDuctIon The Splitter is a product for splitting and extending your HDMI signal over long distances to a compatible display.
- Page 3 4. SPecIFIcatIonS Maximum Pixel Clock 165 MHZ Supports video resolutions up to 1080p@60Hz HDMI Splitter: Input Ports 1x HDMI, 1xMini USB Output Ports 1xHDMI, 4xRJ45, 1xIR out Receiver : Input Ports 1xRJ45, 1x IR in Output Ports 1x HDMI Power Supply DC 12V 2.5A ESD Protection ±...
- Page 4 5. oPeRatIon contRolS anD FunctIonS 5.1 SPlItteR PoWeR leD: The red LED illuminates when the device is connected with power supply. cat out1-out4: Four RJ45 Jacks provide signal output. HDMI out: Local HDMI loop output port. HDMI In: HDMI Input port. Connecting source with HDMI cable. IR out: Connecting the IR Blaster cable included in the package for IR signal transmission.
- Page 5 * DeScRIPtIon 1 eDID control Under normal circumstances, a source device (digital and analog) will require information about a connected device/display to assess what resolutions and features are available. The source can then cater its output to send only resolutions and features that are compatible with the attached device/ display.
- Page 6 * DeScRIPtIon 2 EDID TABLE: RX equalizer distance adjust POSITION EDID DESCRIPTION If you see flickering or blinking image on the display, adjust the EQ switch to improve the 1080p, 2CH AUDIO cable skew. MAX stands for the strongest HDMI signal level for the longest possible 1080p, DOLBY/DTS 5.1 transmission length while MIN stands for 1080p, HD AUDIO...
- Page 7 WIDebanD IR(30kHz---60kHz) IntRoDuctIon IR cable PIn aSSIgnMent Control local device (Blu-ray player or DVD player, etc) from remote: The IR Receiver is connected to the receiver IR in port. The CAT output connector on the HDMI Splitter is connected via CAT6 cable to an HDMI receiver. The IR Transmitter is connected to the HDMI Splitter IR OUT port.
- Page 8 aPPlIcatIon eXaMPle HDTV HDMI SOURCE HDTV HDTV HDTV HDTV Connect a source such as a Blu-Ray Player, game console, A/V Receiver, Cable or Satellite Receiver, etc. to the HDMI input on the Transmitting unit. Connect a display such as an HDTV or HD Projector to the HDMI output on the Receiving unit. Connect a single Cat5e/6 up to 164ft/50m to the output of the Transmitting unit, and the other end to the input of the Receiving unit.
