This printer is compatible with Android, Windows and IOS.
Do I have an Android or Windows till system?
A Windows till system will have the clock in the bottom right corner of the desktop, as well as the
Windows icon in the bottom left corner. An Android till system will have the clock in the top right
corner of the screen.
Setting up the printer
What's in the box?
In the box find the following items:
POS80Gx printer
Power supply
IEC cable (kettle lead)
Ethernet cable
Manual
CD (as your hardware does not contain a CD drive, this can be discarded and won't form part of
the setup process)
Plugging in the printer
1. Plug the IEC cable (kettle lead) into the power supply and plug into a wall/plug socket
2. Plug the end of the power supply into the back of the POS80Gx printer, in the port on the
far right (pictured below)
3. Plug the cash drawer's cable into the black 'cash drawer' port, next to the power port on
the back of the POS80Gx printer (the cash drawer will click when fully pushed into place)
4. Plug the ethernet cable into the ethernet port, this is the middle port
5. Plug the other end of the ethernet cable into your router
6. Turn the printer on at the wall/power socket and then at the front of the printer
POS80Gx Ethernet Guide
Front
Back

Advertisement

loading
Need help?

Need help?

Do you have a question about the POS80G Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EPOS POS80G Series

  • Page 1 POS80Gx Ethernet Guide This printer is compatible with Android, Windows and IOS. Do I have an Android or Windows till system? A Windows till system will have the clock in the bottom right corner of the desktop, as well as the Windows icon in the bottom left corner.
  • Page 2 Configuring the printers IP Address The following steps apply to Android, Windows and iOS till systems. The printer’s IP Address In order to connect the printer to the till over your network connection, you will need to know the printer's unique IP Address, and make sure this IP Address doesn’t change. Finding the printer’s IP Address Your printer makes finding the IP Address nice and easy, follow the steps below to identify what the printer’s IP Address is:...
  • Page 3 4. Select App Settings 5. Select Setup Printer under ‘Receipt Printer’ 6. Select Epos Now as the ‘Manufacturer’ for the printer 7. Enter the IP Address into IP Address field (including the dots, I.e “192.168.1.100”) - leave the ‘Port’ as 9100 8.
  • Page 4 8. Select the ‘Printer Name’ you wish to use within the Printer Name drop down. I.e bar/kitchen/front depending on what you added during your back office set up. 9. Select Epos Now as the Manufacturer for the printer 10. Enter the IP Address into IP Address field (including the dots, I.e “192.168.1.100”) - leave the ‘Port’...
  • Page 5 17. Select Order/Layaway 18. Select Order Anyway the order will now print to your selected printer...
  • Page 6 Windows Till System Setting the IP Address to Static From the Windows Desktop screen, follow the below steps: 1. Select the Windows icon at the bottom left corner of the screen 2. Select Google Chrome 3. Enter the IP Address (that you found earlier) into the URL bar along the top (including the dots, i.e “192.168.1.100”) 4.
  • Page 7 To test the printer and cash drawer, we need to make sure that the correct printer is selected within the Epos Now till app settings. Login to the till app and then follow the steps below starting from the Staff Login page: 1.
  • Page 8 9. Adjust the font and number of copies depending on your preference 10. Select Save 11. Select the Back Arrow (top left) to return to the till front You can now test this printer by processing an order, or paying the transaction off. Use products from categories with the relevant Order Type setup.
  • Page 9 Your printer’s IP Address is now set to static and you are ready to move onto the next stage Epos Now till app - Receipt & order printing Login to the till app and then follow the steps below starting from the till front:...
  • Page 11 FAQ’s Why is my printer printing blank receipts? Check that you are using the correct paper (thermal paper) if you are unsure run your fingernail over the top of the paper and see if it leaves a black mark. If it does, this means you are using the correct paper, try turning it over to make sure that it is in the correct way (shiny side up).
