- Page 1 BRAVO 18X SERIES COMPUTERS 46718001 46718011 46718301 46718311 46718501 46718511 Software rel. 2.1X InSTAllATIOn, USE And MAInTEnAnCE...
-
Page 2: Legend Symbols
This manual is an integral part of the equipment to which it refers and must accompany the equipment in case of sale or change of ownership. Keep it for future reference; ARAG reserves the right to modify the specifications and instructions regarding the product at any time and without prior notice. -
Page 3: Table Of Contents
COnTEnTS • Legend symbols ..........................2 • Foreword and use of this guide ....................5 • Using the manual .......................... 5 • Limitations ............................5 • Liability ............................. 5 1 Product description ........................6 2 Bravo DSB ............................6 3 Risks and precautions before assembly ................ - Page 4 11.15 Pressure reckoning ......................21 11.16 Nozzle number (only if "Pressure reckoning" = YES) ..........21 ..............................22 12 User programming ........................22 12.1 Setting the dosage ......................22 12.2 Wheel constant setting ...................... 23 12.2.1 Manual wheel constant setting ..................
-
Page 5: Foreword And Use Of This Guide
If, as a consequence of the above recommendations, the computer or other ARAG components installed in combination with components provided by other manufacturers should suffer damage of any kind, no form of liability, whether direct or indirect, will be recognized by ARAG. -
Page 6: Product Description
DSb ARAG has designed and manufactured a diagnostics system for Bravo series computers and the systems to which they may be connected. BRAVO DSB (article code 467003) provides reliable computer diagnostics (not of the control unit to which it is connected) so as to enable the resolution of any potential problems experienced with the system. -
Page 7: Contents Of The Package
cONTENTS OF THE PAckAGE The following table lists the components contained in the BRAVO computer package: BRAVO 18X SERIES Legend: Computer Instruction booklets Inductive speed sensor Mounting kit Complete cabling for connection to the valves and sensors Gaskets for section valve connectors Power connector Power cable Tab. -
Page 8: Location On The Machine
lOcATION ON THE mAcHINE Recommended system configuration Assembly diagram for crop sprayers with membrane pump BRAVO 18x MODE "M" (CODE 46718X11) 15/54 Legenda: 12Vdc Control panel Starter key Speed sensor Flow meter Drain valve Control valve Foam marker 1-5 Section valves Tab. -
Page 9: Locating The Computer
continues par. 6.1 - Recommended system configuration Assembly diagram for crop sprayers with centrifugal pump BRAVO 18X MODE "M" (CODE 46718X11) 15/54 Legend: 12Vdc Control panel Starter key Speed sensor Flow meter 1 2 3 4 5 Control valve Foam marker 1-5 Section valves Tab. -
Page 10: Mounting The Bracket
Mounting the bracket The computer and control unit must be mounted on a bracket installed at the desired location (the previous paragraph shows the bracket drilling template). The bracket installs with the supplied bolts (A, fig. 2). Make sure the bracket is securely mounted, fit the computer to it and push it in until it locks in place (B, Fig. -
Page 11: Power Connection
Power connection Inside the package (component 7 - Tab. 1) you will find the power connector required for the connec- tion to the machine’s battery; Fig. 7 shows the drilling template for installing the power connector. Connect the power connector to the battery poles using two 6 mm faston connectors, as shown in Figs. -
Page 12: Connecting The Cable To The Control Unit And Services
• Use of unsuitable cables or cables not provided by ARAG automatically voids the warranty. • ARAG is not liable for damage to the equipment, persons or animals caused by failure to observe the above instructions. Connecting the multi-pin connector Connect the multi-pin connector to the panel and connect the other end of its cable to the control unit. -
Page 13: Connecting The Sensors And Other Services
Use ARAG sensors: use of unsuitable sensors or sensors not provided by ARAG automatically voids the warranty. ARAG is not liable for damage to the equipment, persons or animals caused by failu- re to observe the above instructions. - The speed sensor connection instructions are provided with the product. -
Page 14: Accessory Connections
AccESSORy cONNEcTIONS Foam marker The foam marker ONLY operates correctly if connected to the computer with the ARAG foam marker control kit, code 520004C.100. All information for connecting the foam markers is given in the manual provided with the device. -
Page 15: Computer Controls And Display
cOmPUTER cONTROlS AND DISPlAy 10.1 Control panel - Computer spraying control keys. (par. 10.2 - Using the control keys) - Control unit valve switches Tab. 9 10.2 Using the control keys Control, selection and modification keys Control key: Resets the increment / decrement percentage of delivery value or sets its value. Control key: Activates the LH side foam marker. -
Page 16: Using The Switches
10.3 Using the switches Control unit valve switches Control valve / drain valve switch (depending on system): control valve: • to open the control valve, move the switch up (led on). • to close the control valve, move the switch down (led off). Drain valve: •... -
Page 17: Preliminary Programming
PRElImINARy PROGRAmmING The computer can be programmed with the parameters required to ensure correct distribution of the treatment product. This must be done once only, when installing the computer. In the following paragraphs, the screen shots only show the key points of the pro- gramming procedure: the display may change when the keys described in the text are pressed. -
Page 18: Switching On The Computer For Advanced Programming
11.3 Switching on the computer for advanced programming Power ON 1) With the computer switched off, hold down the keys together and press key 2; release key 2 immediately after the device switches on. The device runs a display self-test, displays the software version, and then displays the advanced menu. -
Page 19: Language
11.5 Language This parameter sets the computer’s display language. Available languages are the following: Italian, English, Spanish, Portuguese, French, German, Polish, Russian, Croatian. 11.6 Unit of measure This parameter sets the units used to display data on the computer. • = European units •... -
Page 20: Section Valve
continues 11.8 - Total boom width This parameter represents the effective spray coverage achieved by the nozzles: for example, if there are 3 nozzles spaced 50 cm apart, the boom section width will be 1,5 m. The displayed value represents the sum of the section widths. To modify the data, set the value for each individual boom section: the sum of the widths is automatically recalculated. -
Page 21: Tank Volume
IMPORTANT: BRAVO 18x computers can only calculate the flow and delivery rates correctly if the flow meter has been installed to the control unit and the flow meter constant has been set. 11.12 Tank volume This parameter sets the amount of liquid which can be contained by the tank: this is thus the ma- ximum amount to which the tank can be filled. -
Page 22: Use
• This section of the manual explains how to use the BRAVO 18x computer. The keys and their descriptions are given in Chapter 10 - Computer controls and display. USER PROGRAmmING Before starting a treatment, a number of settings are required to ensure that the treatment is implemented correctly. -
Page 23: Wheel Constant Setting
Nozzle type to be matched with spray rate can be selected only if pressure reckoning is ENABLED: When "Pressure reckoning" is ENABLED, nozzle type and spray rate will alternati- Rate vely flash in the lower display line. USER1 Press OK to select one of the two items. Press UP and DOWN keys to set as required. -
Page 24: Automatic Wheel Constant Setting
Wheel constant calculation example: the calculation supposes that the wheel has effected 20 rotations (over a measured distance of 7536 cm). The wheel has 8 sensing points. 7536 WheelK = 8 x 20 WheelK = 47,10 This is the value to be entered in the BRAVO 18x. 1) Press to confirm modification of the wheel constant. - Page 25 1) When the menu Rates setup displays, select the Wheels setup menu 2) Press to confirm modification of the wheel constant 3) Press to confirm the modification of the value, indi- cated at the top right of the display. Press A to select the wheel constant for the next wheel.
-
Page 26: Selecting The Wheel Type (Constant)
12.3 Selecting the wheel type (constant) Once the wheel constants have been stored (up to 3), they can be called up as required for the wheels in use. 1) When the Rates setup menu displays, press twice to access the Wheel Selection menu. -
Page 27: Nozzle Menu
12.4 Nozzle menu This menu allows to set selected nozzles. 1) When displaying , menu, the fol- Nozzle data Nozzle data lowing parameters will alternatively flash in the lower line: 0,40 l/min. - Flow rate (e.g. - Pressure (e.g. Press OK to enter the submenu. ISO11001 0,40 l/min. -
Page 28: Treatment
TREATmENT Once the preliminary configurations described above have been completed, it is possible to start the treatment in MANUAL or AUTOMATIC mode. In the following paragraphs, the screen shots only show the key points of the setting procedure: the display may change when the keys described in the text are pressed. 13.1 Operating modes •... -
Page 29: Field Selection
13.2 Field selection When treating a field, the BRAVO 18x collects the data for the current job (treated surface, liquid delivered, treatment time, distance traveled) and stores up to 4 different treatments. These data can be called up with the "FIELD" function. 300 l/ha Fig. -
Page 30: Job/Spray Rate Program Selection (For Automatic Control Only)
13.4 Job/spray rate program selection (for automatic control ONLY) Before starting treatment, select the right dosage from those provided in the (par. 12.1). Menu User 300 l/ha 1) Hold down the key for 1 second to 9.1 Km/h enter the dosage selection menu. 2) Press to scroll through the dosage settings. -
Page 31: Automatic Treatment Control
13.5 Automatic treatment control Refer to Chapter 10 - Computer controls and display - for information on operating the keys and switches. 1) Press to enable automatic mode: the letter "A" 300 l/ha (automatic) displays. 2) Open the section valves by setting the control pa- nel switches to the up position: their leds will turn on*. -
Page 32: Distribution Menu
13.7 Distribution menu This menu provides the treatment options. Almost all parameters have a submenu which can be accessed by holding down the UP and DOWN keys together for 1 second; this opens the function associated with the selected menu. In all submenus, pressing OK confirms entry or modification of a parameter, while pressing ESC cancels the operation or quits the menu option. - Page 33 Liquid distributed count Reset? This function resets the liquid distributed 300 l/ha count for the field indicated at the right Sprayed qty. corner of the display. Field treated Press to select the field to be treated. Field selection After the field selection has been confirmed, the computer will prompt for 300 l/ha the operator to reset the parameters for...
-
Page 34: Fault Warnings (For Automatic Control Only)
13.8 Fault warnings (for automatic control ONLY) If distribution errors occur during treatment, the computer warns the operator by sounding a buzzer and displaying a message describing the problem. Speed alarm The computer does not detect the tractor speed and the control unit is supplied (control valve open or drain valve closed). -
Page 35: Maintenance / Diagnostics / Repairs
mAINTENANcE / DIAGNOSTIcS / REPAIRS 14.1 Troubleshooting FAUlT cAUSE REmEDy • Turn the ignition key to "Ignition". The display does not turn on No power • Check the power cable connections. • Press the power button. The valves do not respond The valves are not connected •... -
Page 36: Test Menu
14.2 Test menu This menu tests that the computer is operating correctly. To access the menu, turn the computer on with the AUTO and RATE keys held down. All tests are READ ONLY; the parameters cannot be modified. Display test Tractor battery voltage test Switches test Operate the switches to test that they are working correctly. - Page 37 Speed sensor input test The frequency reading in Hz of the speed sensor displays. Flow meter input test The frequency reading in Hz of the flow meter displays. Keyboard test Press the keys to display the respective text. Key texts: RATE: RATE KEY LH foam marker: TFSX KEY OK: OK KEY...
-
Page 38: Problems Due To The Type Of System And Computer's Mode Of Operation
14.3 Problems due to the type of system and computer’s mode of operation All work intended to partially or completely modify the operation of the computer or any components connected thereto is done at the user’s full and exclusive liability. If there is any doubt regarding alternative computer cable hookups, please contact your nearest service center for further information. -
Page 39: Technical Data
TEcHNIcAl DATA 15.1 Units of measurement • Advanced menu Datum min. max. Description Notes Language options: Display Language Italian, English, French, German, Spanish, language Portuguese, Polish, Russian, Croatian. Units of measu- Units of mea- Available options: rement used to surement EU, US, US TURF display data Number of... - Page 40 Delivery values Datum min. max. Description Notes 1990 EU: l/ha Liquid delivered Volume Displays on the first line of the display 199,9 US: gpa per unit surface applied during treatment area 199,9 US TURF: gpk 199,9 EU: km/h Vehicle’s speed of Speed US - US TURF: travel...
-
Page 41: Computer Technical Data
User menu Datum min. max. Description Notes EU: l/ha Desired distribution Dosage 600,0 US: gpa rate 60,00 US TURF: gpk Number of settable Up to 5 values can be set; dosages dosages zero settings are not displayed 99,99 EU: cm/imp* Wheel Wheel constant Used to calculate the tractor speed;... -
Page 42: Guarantee Terms
GUARANTEE TERmS 1. ARAG s.r.l. guarantees this apparatus for a period of 360 day (1 year) from the date of sale to the client user (date of the goods delivery note). The components of the apparatus, that in the unappealable opinion of ARAG are faulty due to an original defect in the material or production process, will be repaired or replaced free of charge at the nearest Assistance Centre operating at the moment the request for intervention is made. - Page 43 C o n f o r m i t y D e c l a r a t i o n ARAG s.r.l. Via Palladio, 5/A 42048 Rubiera (RE) - Italy P.IVA 01801480359 Dichiara che il prodotto descrizione: Computer modello: bravo 180 serie: 46718xxx e 467110W risponde ai requisiti di conformità...
- Page 44 ARAG accessories and spare parts, to maintain safety conditions foreseen by the constructor. Always refer to the ARAG spare parts catalogue. 42048 RuBieRA (Reggio emilia) iTALY Via Palladio, 5/A Tel. 0522.622011 Fax 0522.628944 info@aragnet.com http://www.aragnet.com...
