Celestron VistaPix 8x32 User Manual
  1. Manuals
  2. Brands
  3. Celestron Manuals
  4. Binoculars
  5. VistaPix 8x32
  6. User manual

Celestron VistaPix 8x32 User Manual

8x32 binocular & digital camera
Hide thumbs Also See for VistaPix 8x32:

Advertisement

Quick Links

See also: Use and Care Manual
Digital Camera Specifications
Image sensor
2.0 Mega pixels, CMOS sensor
Lens
300mm(8X)
Field of View
7 -8
Image Resolution
HI -2048x1536 (3.1)
(Still Image)
MI -1600x1200 (2.0)
LO -640x480 (0.3)
Video Resolution
320x240, 12 Fps AVI format
Image Capacity
HI 36 P
MI 46 P
LO 250 P
(*Upon 16MB Flash Memory)
Image Type
MPEG format
Video measure
6~8 min
Digital Zoom
4 X
Exposure
Auto / Manual Mode
White Balance
Auto
Memory
Built-in 16MB Flash Memory
SD/MMC card socket expandable
LCD open angle
0 / 105
Language select
English
Interface
USB 1.1
TV-out
NTSC / PAL
Power Source
1.5V AAA alkaline battery x 4
Binocular specifications
Size
8 x 32 mm
Field of View
Field of View5.6°Field of view :
92.7m(304 ft) at 914m(1000 YDS)
Exit pupil
4.0 mm
Close Focusing
3.5 m
Eye Relief
12.5 mm
Coatings
Multi coating on the first surface.
Single layer for other surface, fully coated.
Package Contents
USB Cable
x 1
User Guide
x 1
Video Cable
x 1
Software CD
x 1
Pouch
x1
Binocular Dimensions
156mm x 102mm x 60mm(LCD Close)
System Requirements:
1. Window 98/ 98SE/ ME/ 2000/ XP
2. The processor above Pentium 233MHz
3. 128MB SDRAM
4. Video(VGA) card with 2MB of RAM for
minimum 16-bit (High Color) display.
U.S. Patent No. 6,088,053. Other patents pending
5. CD-ROM
6. USB port
7. 600MB of free hard
disk space.
8x32
Binocular & Digital Camera
Model #72212
