Celestron VistaPix 10x25 User Manual

10 x 25 binocular integrated with a digital camera
Hide thumbs Also See for VistaPix 10x25:
Table of Contents

Advertisement

Quick Links

See also: Use and Care Manual
VistaPix 72202 10x25
Contents
1.Introduction .......................................................P.1
2.Notice to User ....................................................P.2
3.Product Part Identification...................................P.3
4.Digital Camera Modes.........................................P.4
5.How to use the Binocular......................................P.5
6.Using the Camera.................................................P.6
7.System Requirements...........................................P.8
8.Basic Maintenance.............................................. P.9
9.Driver Software and Image
downloading procedure................................P.10~P.14
10. Steps to View Images on TV ................................P. 15~P.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VistaPix 10x25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Celestron VistaPix 10x25

Summary of Contents for Celestron VistaPix 10x25

  • Page 1: Table Of Contents

    VistaPix 72202 10x25 Contents 1.Introduction ...P.1 2.Notice to User ...P.2 3.Product Part Identification...P.3 4.Digital Camera Modes...P.4 5.How to use the Binocular...P.5 6.Using the Camera...P.6 7.System Requirements...P.8 8.Basic Maintenance... P.9 9.Driver Software and Image downloading procedure...P.10~P.14 10. Steps to View Images on TV ...P. 15~P.19...

  • Page 2: Introduction

    1. Introduction VistaPix is a 10 x 25 binocular integrated with a digital camera that is great for sporting events, concerts and wildlife activities such as hunting or bird-watching. Main Features: A fully functioning binocular. View images on your computer screen or on your TV.

  • Page 3: Notice To User

    Eye damage is often painless, so there is no warning to the observer that damage has occurred until it is too late. Do not point the binocular at or near the Sun. Children should always have adult supervision while observing.

  • Page 4: Product Part Identification

    3. Product part identification 1.Diopter Knob(on underside) 2.Center Focus Knob 3.Objective Lens 4.Mode/Power Button [M] 5.Shutter/Set Button [S] 6.USB Port 7.TV out Eyepiece 9.Camera Lens 10.LCD display 11.Battery Compartment Lid 12.Objective Barrel 13.TV Scroll Buttons Port...

  • Page 5: Digital Camera Modes

    4. Digital Camera Modes Press the left button Mode/Power Button (4) to scroll through the Modes. 4-1. Press right button Shutter/Set Button (5) to select a mode or to take images. Full display of mode icon. 4-2. Explanation on mode icon. High Resolution mode (1280x960)VistaPix will store up to 40 images.

  • Page 6: How To Use The Binocular

    5. How to use the binocular Adjustment eye-relief for eyeglass wearers Fold down the rubber eyecups and place them against your glasses to get the best viewing result. Adjusting the eyepieces The distance between your eyes is called interpupillary distance.
  • Page 7 6-1-2. Press the Mode/Power Button (4) to select the resolution mode ("hi" or"lo"). 6-1-3. Select a target to view with the binocular, and aim at the target. 6-1-4. Press the Shutter/Set Button (5) to take an image. A short beep will sound indicating the picture has been taken 6-1-5.
  • Page 8 6-1-9. 2X Zoom Mode. Press the Mode/Power button (4) to display the 2X icon. Then, press the Shutter/Set button (5) once to select 2X mode. Press the Shutter/Set button again to take an image at 2 times the normal magnification level. 6-1-10.

  • Page 9: System Requirements

    7. System requirements 7 - 1 . W i n d o w s 9 8 S E / 2 0 0 0 / M E / X P P e n t i u m 2 3 3 M H z o r h i g h e r - 2 .

  • Page 10: Basic Maintenance

    8.Basic maintenance Operating Environment: 41 to104 F(5 to 40 C). 20%-85% relative humidity, non-condensing Care of your VistaPix 8 -1.Never immerse VistaPix into any fluid or liquid. Remove dust or stains with a soft cloth dampened with water or neutral detergent. Keep in a dry and cool dust-free environment when not in use.
  • Page 11 Steps to install VistaPix driver software 1. Insert the CD included with your VistaPix. 2. Click the mouse on "Installation Driver" to begin installation. 3. Begin "InstallShield Wizard" and your computer will automatically execute the installation of driver program. 4. Follow the "InstallShield Wizard" steps to guide you through the driver installation.
  • Page 12 Steps to install VistaPix driver software 5. Computer will automatically install the driver. 6. Installation complete. Please . press "Finish" button. P.11...
  • Page 13 Steps to install Photo Manager 1. Insert the CD ROM 2. Select "Install Photo Manager" 3.Choose the language and press "OK" button 4.Enter installation scree 5.After confirming, please press "Next" button 6.After confirming, please press "Yes" 7.Enter serial number (located on the CD cover).

  • Page 14: Uninstalling The Software

    8. Choose "Custom" or "Typical" form 9.Please confirm the file location of installation. 11.Software installation finished, please 10. Begin installing software press "Finish" for confirmation After installing VistaPix software. Please restart your computer. Un-installing the Software To un-install the software, simply insert the CD and re-install the program. The screen will ask if you would like to remove the program and all of its components.
  • Page 15 1. Start "Photo Manager" program. Select the buttons as indicated. 3. In " Dcim " file, open" 100scope " data file. 5. Images download finished. Steps to download images 2. Enter " Removable Disk" to open " Dcim " file. 4.

  • Page 16: Steps To View Images On Tv

    Steps to view images on a TV 1. VistaPix shown with Video cable. cable 3. Connect the Video to t h e AV terminal of the TV (video side). 5. Press TV scroll buttons (13) to view stored images. P.15 2.

  • Page 17: Playback Menu

    1. Select NTSC/PAL mode Use the video cable to connect VistaPix with TV. Press the Power button for 3 seconds to turn on VistaPix. You can take images by aiming at a target at least 10 meters (30 ft) away. Then press Mode/Power button (4) again to enter Image view function.

  • Page 18: Image Display

    Steps to view TV images IMAGE DISPLAY Enter "PLAYBACK MENU" screen , then press TV Scroll Button (13) (up or down) to select the "IMAGE DISPLAY" functio n. Press the Shutter/Set button (5) to confirm. Choose from either "SINGLE" or "3 X 3": [SINGLE] image view mode - Single picture displayed on screen, press TV scroll button (up or down) to select pictures.
  • Page 19 DELETE / LOCK Enter "PLAYBACK MENU" screen , press the TV scroll button (up or down) to select the "DELETE / LOCK" function and press Shutter/Set button to confirm. Select one of the following three modes: CURRENT, (deletes last picture); ALL(deletes all pictures); UN/LOCK(to lock and unlock). [CURRENT] mode to delete last picture.
  • Page 20 Steps to view TV images [FORMAT] Enter "PLAYBACK MENU" screen , press the TV scroll button (13) to select the "FORMAT" function and press the Shutter/Set button (5) to confirm. A warning message will be displayed. Press the TV scroll button (up or down) to select "YES"...
