Bringing music and movies to life
Custom installation guide – AV8/9
Later versions will be made available on the Arcam dealer extranet at:
www.arcam.co.uk
Page 1 of 7
CI Guide AV8/9 V1
Pembroke Avenue, Waterbeach, Cambridge, CB5 9QR, England
Tel +44 (0) 1223 203200 Fax +44 (0) 1223 863384

Advertisement

loading

Summary of Contents for Arcam AV8

  • Page 1 Bringing music and movies to life Custom installation guide – AV8/9 Later versions will be made available on the Arcam dealer extranet at: www.arcam.co.uk Page 1 of 7 CI Guide AV8/9 V1 Pembroke Avenue, Waterbeach, Cambridge, CB5 9QR, England Tel +44 (0) 1223 203200 Fax +44 (0) 1223 863384...
  • Page 2: Software Version

    TUNER TAPE DVDA DISPLAY MENU The latest version of software for the AV8 and AV9 products is available from the Arcam dealer extranet – this is password accessible from the Arcam customer website at www.arcam.co.uk Page 2 of 7 CI Guide AV8/9 V1...
  • Page 3 Exit menu Rear panel trigger lead configuration This lead allows the AV8/9 to power toggle on/off the P7 Amplifier and Zone 2 as well (The menu must be setup) AV8 trigger output Zone 1 and Zone 2 - 3.5mm configuration.
  • Page 4 Zone 2 on screen menus when viewed from Zone 2 The AV8 will supply a Composite or S-video feed to a Zone 2 location and will also provide a Zone 2 on-screen menu to the second location, below you will see an explanation of the menu and the various control options available.
  • Page 5 MENU Set-up menu lock (available from V3 software onwards) When working with the AV8/9 you have access to a Menu Lock function, this is a particularly useful function and allows the installer to safe guard his calibrations and system set-up configurations.
  • Page 6 Enter the set-up code <1213> the led will blink twice. Press <SET> to lock in the set-up code. You may now reassign either Zone 1 or 2 as RC5 19 within the AV8 engineering menu please see page 7 Please note: Only major functions are available from the AUX RC5 19 page of the...
  • Page 7 Connector wiring diagrams FMJ AV8 Processor remote input. Remote in 0v or screen +12v from AV8 (100mA max) stereo FMJ AV8 Processor remote output. Remote out 0v or screen +12v from AV8 (100mA max) stereo FMJ AV8 Processor trigger output.

This manual is also suitable for:

Av9
